Summary of Contents for Santak CASTLE Series

  • Page 1 RACK 1-3K(S) UPS...
  • Page 3 Thank you for selecting a SANTAK product to protect your electrical equipment. This manual contains important instructions that you should follow during installation and maintenance of the UPS and batteries. Please read all instructions before operating the equipment and save this manual for future reference.
  • Page 4 Solemn Declaration SICPA PRODUCT SECURITY In order to ensure the safety of your electricity and help you purchase the real Santak UPS, please pay attention to the following items： 1. Santak registered trademark： 、 、 ； 2. Santak Electronics (Shenzhen) Co., Ltd. has never authorized any other company to produce UPS in any form in China；...
  • Page 5 Safety Instructions Please read carefully the following user manual and the safety instructions before installing or operating the unit! Operation Safety Please read all instructions before operating the equipment and connecting to mains power, save this manual for future reference. Please pay attention to all the warning indication, understand and follow all the instruction.
  • Page 6 2. If UPS requests moving to another place or reconnecting power wire, it is imperative to disconnect all the power connections of UPS, and turn off UPS. 3. Please used the UPS accessories specified by SANTAK. 4. Shock Risk. If equipment powered by UPS require any type of maintenance, it is imperative to disconnect it from UPS before maintenance.
  • Page 7 B. Use only tools with insulated grips and handles. C. Wear rubber gloves and boots. D. Do not lay tools or metal parts on top of batteries. E. Disconnect the charging source prior to connecting or disconnecting battery terminals. 4. Do not attempt to dispose of batteries by burning them. It could cause explosion.

  • Page 8: Table Of Contents

    CONTENT SOLEMN DECLARATION........... - 2 - 1. INTRODUCTION ............- 7 - 1.1 Introduction ..................- 7 - 1.2 Description of Commonly Used Symbols ........- 8 - 1.3 Safety Instructions ................. - 9 - 1.4 Features ..................- 10 - 1.5 Product Specification..............

  • Page 9: Introduction

    Introduction 1.1 Introduction This On-Line-Series is an uninterruptible power supply incorporating double-converter technology. It provides perfect protection specifically for Novell, Windows NT and UNIX servers. The double-converter principle eliminates all mains power disturbances. A rectifier converts the alternating current from the socket outlet to direct current.

  • Page 10: Description Of Commonly Used Symbols

    1.2 Description of Commonly Used Symbols Some or all of the following symbols may be used in this manual. It is advisable to familiarize yourself with them and understand their meaning: - 8 -...

  • Page 11: Safety Instructions

    1.3 Safety Instructions Safety Rules Read the safety rules in this manual, which must be strictly observed during the installation, use and maintenance of the UPS 。 Note : • UPS has high pressure inside. • UPS can supply power by battery, and output may have high voltage even if the input power line is not connected Battery voltage and external battery box for each model：...

  • Page 12: Features

    1.4 Features Rack1K(S)/Rack2K(S)/Rack3K(S) Front Panel Rack1K Rear Panel Rack1KS Rear Panel - 10 -...
  • Page 13 Rack2K Rear Panel Rack2KS Rear Panel Rack3K Rear Panel - 11 -...
  • Page 14 Rack3KS Rear Panel Rack1K(S)/Rack2K(S)/Rack3K(S) EBM Front Panel Rack1K(S) EBM Rear Panel - 12 -...
  • Page 15 Rack2K(S) EBM Rear Panel Rack3K(S) EBM Rear Panel - 13 -...

  • Page 16: Product Specification

    1.5 Product Specification Model Rack1K Rack1KS Rack2K Rack2KS Rack3K Rack3KS Dimensions 438*420*87 438*570*87 438*420*87 438*570*87 438*420*87 W*D*H(mm) Net Weight(kg) 11.0 17.5 21.6 1KVA/800W(Default) 2KVA/1600W(Default) 3KVA/2400W(Default) Power 1kVA/900W 2kVA/1800W 3kVA/2700W Rating(VA/W) (Ambient temperature (Ambient temperature＜ (Ambient temperature＜ ＜30℃) 30℃) 30℃) Input Input mode Single phase grounding Rated voltage...
  • Page 17 Backup time PF=0.8 100% load ≥ 3mins (25℃) Recharge time 5 hours to 90% (Standard) Depend on external battery capacity（Time release） - 15 -...
  • Page 18 Model Rack1K Rack1KS Rack2K Rack2KS Rack3K Rack3KS EMC Standard GB7260.2 IEC 62040-2-2005 National standard GB 4943.1-2011 GB 7260.1-2008，EN62040-1 Industry standard YD/T 1095-2008 CQC 3108-2011 Operation PF=0.8 0℃～40℃ PF=0.9 0℃～30℃ Store temperature -25℃～55℃ Relative humidity 20%～90%（non-condensing） Altitude <1000m ① When ambient temperature＜30℃, Output power factor can be changed to 0.9 through the serial command，Default power factor is 0.8.

  • Page 19: Install

    Install 2.1 Unpacking and Check Open the package. Firstly check that whether the appearance of the UPS device is damaged. If damaged, please don't turn on the machine and contact the supplier. Then check whether the random attachments are completely：a pair of ears, one of power cords, one of manual，one of the battery wires（the standard does not contain）.
  • Page 20 Rack-mount installation： Remove screw Align the mounting ears with screw holes on the side of the UPS, and tighten the screw.（Pay attention to the installation direction of lug， concave downward） Slide in the UPS into the rack rail and lock it in the Rack-mounting， Tighten the screw, and then the load can be connected.
  • Page 21 The installation dimensions are as follows： UPS maximum outline size=481.0mm Center distance of mounting hole =465.0mm UPS box width =465.0mm The install dimensions of mounting ears, available for M6 screw - 19 -...

  • Page 22: Operation

    Operation 3.1 Panel Description 1#Indicator light ： Trouble lamp 2# Indicator light ： Load/Battery 3# Indicator light ： Load/Battery 4# Indicator light ： Load/Battery 5# Indicator light ： Load/Battery 6# Indicator light ： Load/Battery 8# Indicator light : Utility 7# Indicator light : Bypass 10# Indicator light : Battery 9# Indicator light : Inverter Operation display panel...
  • Page 23 Switch key The main functions of the switch keys： Turn On：Press the switch button, more than 1 seconds to boot，UPS will issue a tweet when the boot is successful. Turn Off：When the UPS is in the utility mode and battery mode, press the switch button for more than 1 second to turn off the power Clear fault：Press the switch key for more than 3 seconds to clear the fault state.

  • Page 24: Operation Mode

    load / battery capacity Orange Indication of load capacity or battery indicator capacity： 1. On utility / bypass load / battery capacity Green mode, just indicate load capacity, as load capacity indicator 2.On battery indicator mode, just indicate battery capacity, load / battery capacity Green as battery capacity indicator...
  • Page 25 self-check. Make sure the connection is correct. It may be battery fault or aging. Please refer to the sixth chapter troubleshooting table. - 23 -...
  • Page 26 NOTE：If the generator is connected, follow the following procedure： • When the generator is stable, the generator output power will be connected to the UPS input (at this time to determine the UPS is no-load), and then press the boot program to start UPS, UPS start, and then join the load one by one.

  • Page 27: Operation

    UPS has no backup function when working on bypass mode. 3.3 Operation 3.3.1 Turn on/off operation 1. Turn on NOTE: Although the battery is full of electricity at the factory, the power will be lost after transportation and storage. It is recommended that the battery should be charged for 10 hours before the first use of the UPS, so as to ensure sufficient spare time.
  • Page 28 will start self-check. Then the load / battery capacity indicator on panel light on all and then finally extinguished, then panel has no display, UPS has no output voltage. 3.3.2 Battery self-check operation During UPS operating, the user can manually check the battery status by battery self- check.
  • Page 29 3.3.3 LED Display and Alarm Working Condition Panel Light Display 1# 2# 3# 4# 5# 6# 7# 8# 9# 10# 0%--35% Load ● ● ● 36%--55% Load ● ● ● ● Utility mode 56%--75% Load ● ● ● ● ● 76%--95% Load ●...
  • Page 30 continuously beep Charge board or battery break ● ↑ ↑ ★ continuously beep Output short-circuited ● ● ● ↑ 1 beep per sec Fan working abnormal ● ● ● ↑ ↑ ↑ continuously beep Inverter capacitor open circuit ● ● ● ● ● ↑...

  • Page 31: Communication Interface

    Intelligent slot and optional Webpower card, AS400 card, CMC card are optional. Downloadable graphical WinPower monitoring software and USB drivers are available free of charge from SANTAK web site. NOTE：USB line shall not be parallel with the input and output lines to prevent interference.

  • Page 32: Maintenance

    Maintenance ●This series UPS only requires minimal maintenance. The battery used for standard models are value regulated sealed lead-acid maintenance free battery. These models require minimal repairs. The only requirement is to charge the UPS regularly in order to maximize the expected life of the battery. When being connected to the mains power, whether the UPS is turned on or not, the UPS keeps charging the batteries and also offers the protective function of overcharging and over-discharging.

  • Page 33: Trouble Shooting

    Trouble shooting NOTE：If the UPS does not operate correctly, please press the "switch machine" button for a long time to clear the trouble, prevent the battery from long-term discharge damage, forbid to turn on the machine again, so as to avoid greater damage to the machine.
  • Page 34 1＃Fault indicator and UPS overcharge UPS charger fault，please 3＃light on，buzzer protection action contact your supplier beeps continuously 8＃utility indicator The utility voltage or UPS is working in the battery flashing frequency is beyond the mode, saving data and closing UPS input range the application to ensure that the utility is in the input voltage or frequency range that UPS...
  • Page 35 Warning & Fault Possible cause Method 10＃battery light The battery voltage is too Check the UPS battery section flashing low or the battery is not and connect the battery. connected Contact your supplier if the battery is damaged 1＃Fault light on， UPS charging fault please contact your supplier 10＃battery light...
  • Page 37 SANTAK ELECTRONIC（SHENZHEN）CO.,LTD No.8 Baoshi Rd, Block 72 Baoan, Shenzhen, Guangdong, China www.santak.com 614-08133XS1-00...
