7. OPERATION AND MAINTENANCE
5) Press ▼to continue
INPUT PARAMETER
VOLT: 220
FREQ: 50.0Hz
*R-phase inputs when being single-phase
7) Press ▼ to continue (utility power mode)
BATTERY PARAMETER
BAT VOLT: 137V
VOLUME: 100%
STATUS: CHARGING
*The battery status will be "CHARGING", "DISCHARE" ,"BATT LOW" or "BATT OPEN" etc.
7.1.5 Startup of the UPS system
1) Startup menu
press "ESC" and press ▲ or ▼ to
select "UPS ON"
5) Select "YES, TO CONFIRM"
to start up the UPS system
UPS IS TURNING ON
PLEASE WAIT...
*The status will be"3PHASE I/P(R PHASE I/P)" or "BATTERY MODE".
RN
SN
TN
220
221
UPS ON
SETUP
INQUIRE
6) Press ▼ to continue
POWER PARAMETER
TOTAL: 0.00
UPS1: 0.00
UPS2: 0.00
*The status of Each UPS-Module will be
shown circularly in the last two lines
↵ ↵ ↵ ↵
2) Press
CONFIRM
TURN UPS ON
NO, CANCEL
YES, CONFIRM
4) Normal startup
LOAD: 0% BATT: 137
I/P VOLT:
O/P VOLT: 220
O/P FREQ: 50.0Hz
STATUS: R PHASE I/P
19
kW
kVA
0.00
0.00
0.00
220 220 221
