NOTE: The original factory‑installed firmware is always available on the DTP2 211
unit. If the attempted firmware upload fails for any reason, the unit reverts to the
factory version.
On the Add Device... window, the path to the new firmware file is displayed in the
Path field (see figure 23,
DTP2 T 211
DTP2 T 211
1
DTP2T211\dtp2t211_A_v1.00_081518.S19
3
2
Figure 23. Path to New Firmware File on the Add Device Window
10. If this is the only device uploading firmware, click Add (
added to the Device section of the Firmware Loader window and the Add Device
window closes.
If firmware is uploading to multiple devices, do the following:
a. Click Add Next (
3
Firmware Loader window, and the Add Device... window remains open.
b. For each additional device that needs to be added to the Firmware Loader
window, repeat steps 4 through 9, then click Add Next(
c. For the last device, click Add (
close the Add Device... window.
1 1 1
60-1631-52
DTP2 T 211
Figure 24. Firmware Loader Screen with a DTP2 T 211 Added
To remove a device from the Device section, do the following:
11.
a. Click on the names of the devices to be deleted, highlight them (see figure 24,
).
1
). The first device is added to the Device section of the
), instead of
2 Add Next
1.00.001
dtp2t211_A_v1.00.00...
DTP2 T/R 211 • Remote Control
). The device name is
2
).
3
( ), to add the device and
3
2 2 2
Extron USB Devi... Connected
).
1
