diagram is shown in Figure 2-6-2:
Figure 2-6-2: Passive Crystal Oscillator for RTC
Clock pin assignment:
PS_PADO_503
PS System Clock Source
The X1 crystal on the core board provides a 33.333MHz clock input for the
PS part. The clock input is connected to the PS_REF_CLK_503 pin of
BANK503 of the ZYNQ chip. The schematic diagram is shown in Figure 2-6-3:
Clock pin assignment:
PS_REF_CLK
27 / 68
ZYNQ Ultrascale + FPGA Board AXU7EV User Manual
Signal Name
PS_PADI_503
Figure 2-6-3: Active Crystal in PS part
Signal Name
Amazon Store: https://www.amazon.com/alinx
Pin
M25
L25
Pin
R24
