Avnet COM Express MSC C6C-AL User Manual page 93

Feature
FER
NFER
CER
CTO
SEFE
SENFE
SECE
PME SCI
Hot Plug
PCIe Speed
Transmitter Half Swing
PCH PCIE LTR
Snoop Latency Override
MSC C6C-AL
Options Description
Enabled PCI Express Device Fatal Error Reporting Enable/Disable.
Disabled
Enabled PCI Express Device Non-Fatal Error Reporting Enable/Disable.
Disabled
Enabled PCI Express Device Correctable Error Reporting Enable/Disable
Disabled
Default Setting PCI Express Completion Timer TO Enable/Disable.
16-55 ms
65-210 ms
260-900 ms
1-3.5 s
Disabled
Enabled Root PCI Express System Error on Fatal Error Enable/Disable.
Disabled
Enabled Enable or disable Root PCI Express System Error on Non-Fatal
Disabled Error
Enabled Root PCI Express System Error on Correctable Error
Disabled Enable/Disable.
Enabled PCI Express PME SCI Enable/Disable.
Disabled
Enabled PCI Express Hot Plug Enable/Disable
Disabled
Auto, GEN1, GEN2 Configure PCIe Speed. CHV A1 always with Gen1 Speed.
Enabled Transmitter Half Swing Enable/Disable.
Disabled
Enabled PCH PCIE Latency Reporting Enable/Disable
Disabled
Disabled Snoop Latency Override for PCH PCIE. Disabled: Disable override.
Manual Manual: Manually enter override values. Auto (default): Maintain
default BIOS flow.
Auto
MSC C6C-AL User Manual 93 / 128
