96Boards ON Semiconductor Dual
Camera Mezzanine: Getting Started
Guide
10 September 2020
© 2019 Avnet. All rights reserved. All trademarks and registered trademarks are the property of their respective owners. All specifications are subject to change without notice.
NOTICE OF DISCLAIMER: Avnet is providing this design, code, or information "as is." By providing the design, code, or information as one possible implementation of this
feature, application, or standard, Avnet makes no representation that this implementation is free from any claims of infringement. You are responsible for obtaining any rights
you may require for your implementation. Avnet expressly disclaims any warranty whatsoever with respect to the adequacy of the implementation, including but not limited to
any warranties or representations that this implementation is free from claims of infringement and any implied warranties of merchantability or fitness for a particular purpose.
Advertisement
Table of Contents
Related Manuals for Avnet AES-ACC-U96-ONCAM-MEZ
Summary of Contents for Avnet AES-ACC-U96-ONCAM-MEZ
- Page 1 10 September 2020 © 2019 Avnet. All rights reserved. All trademarks and registered trademarks are the property of their respective owners. All specifications are subject to change without notice. NOTICE OF DISCLAIMER: Avnet is providing this design, code, or information "as is." By providing the design, code, or information as one possible implementation of this feature, application, or standard, Avnet makes no representation that this implementation is free from any claims of infringement.
- Page 2 • microSD adapter (to full-size SD or USB) that is compatible with your host machine • Ultra96-V2 • 96Boards Power Adapter, such as Avnet AES-ACC-U96-4APWR • ON Semiconductor Dual Camera Mezzanine • 2 image sensors installed (included from the factory) •...
- Page 3 WARNING – This procedure will erase everything on the microSD card, so backup anything important prior to running performing this operation. 1. Download the image archive from http://avnet.me/DualCameraMezz 2. Decompress the archive to extract the .img file. You should have a file named OnSemi_mezz_2020_1_1080p_OOB_yymmdd.img where yymmdd is the datecode of the image.
- Page 4 5. Click Select Image. Browse to the OnSemi_mezz_2020_1_1080p_OOB_yymmdd.img previously extracted and click Open. Figure 2 – Etcher with Ultra96-V2 Image Loaded 6. Plug in the microSD card + adapter into your host and note the drive letter. Etcher may find your drive automatically.
- Page 5 WARNING – This procedure will erase everything on the microSD card, so backup anything important prior to running performing this operation. 7. Click Flash! to flash the microSD card. Figure 4 – Flashing in Progress When complete, Etcher will display “Flash Complete!” Figure 5 –...
- Page 6 Running Petalinux Out of Box Design After the SDcard has been properly imaged, insert the card into your Ultra96-V2. You will also need to connect a USB keyboard to Ultra96-V2 as well as a 1080p monitor, using the display port connector. Power up the board.
- Page 7 Running this command will display the two cameras capture data side by side on a 1080p monitor: To exit the camera display routine reset the board using the reset button: The board will reboot and return you to the Petalinux prompt. Revision History Date Version...
