6.7.2

Hardware Monitoring

Feature
CPU Temperature
Memory Temperature
Board Temperature
VCore
3.3V
5V
5V Standby
12V
Vbat
CPU Fan Speed
System Fan Speed
MSC C6C-AL
Options Description
Informative Shows CPU temperature
Also supported in EAPI
Note: CPU temperature is measured close to the CPU and does
not reflect CPU die temperature
Informative Shows CPU temperature
Informative Shows the board temperature
Informative Shows the VCore voltage
Informative Shows the 3.3V voltage
Informative Shows the 5V voltage
Informative Shows the current 5V Standby voltage
Informative Shows the 12V voltage
Informative Shows the voltage of the RTC
Informative Shows the current CPU fan speed
Informative Shows the current System fan speed
