1.7

Module Photos

1
6
7
3
Top Side View
MSC C6C-AL
2
4
5
8
9
10
MSC C6C-AL User Manual
1
Top Side Memory Socket
2
MAC Address Label
3
Layout Revision
4
Board Identification Number (BID)
5
Board ID Label
6
BIOS Label
7
Camera Interface Connector
8
System On Chip (SOC)
9
Micro SD Card Connector
10
Fan Connector
10 / 128
