6.8.10 Network Stack Configuration

Feature
Network Stack
IPv4 PXE Support
Ipv4 HTTP Support
IPv6 PXE Support
Ipv6 HTTP Support
PXE boot wait time
Media detect count

6.8.11 CSM Configuration

Feature
CSM Support
GateA20 Active
MSC C6C-AL
Options Description
Enabled, Disabled Enable/Disable UEFI Network Stack
Enabled, Disabled Enable Ipv4 PXE Boot Support. If disabled IPV4 PXE boot option
will not be created
Enabled, Disabled Enable Ipv4 HTTP Boot Support. If disabled IPV4 HTTP boot option
will not be created
Enabled, Disabled Enable Ipv6 PXE Boot Support. If disabled IPV6 PXE boot option
will not be created
Enabled, Disabled Enable Ipv6 HTTP Boot Support. If disabled IPV6 HTTP boot option
will not be created
1-5s Wait time to press ESC key to abort the PXE boot
1-50 Number of times presence of media will be checked
Options Description
Enabled Enable/Disable CSM Support
Disabled
This module is able to emulate legacy BIOS environment and allow
booting legacy operating systems or new operating systems which
were installed without UEFI boot loader. If CSM is disabled, only
EFI partitions can be booted.
To disable CSM, first set Video Oprom to UEFI
UPON Request – GA20 can be disabled using BIOS services.
Upon Request
Always – do not allow disabling GA20; this option is useful when
Always
any RT code is executed above 1MB
MSC C6C-AL User Manual 71 / 128
