6.8.15 Security Configuration

Feature
TXE HMRFPO
TXE EOP Message

6.8.16 SIO WB627/ SMSC 3114 Configuration

Feature
WB627 COM A-B:
WB627 COM A-B Setting:
WB627 LPT:
Change Settings
MSC C6C-AL
Options Description
Enabled Enable or disable TXE Host ME Region Flash Protection Override
Disabled
Enabled Send EOP message before enter OS
Disabled
Options Description
Enabled Enable or disable COM A-B on Winbond SIO
Disabled
Auto Resource setting for COM A-B on Winbond SIO
I/O 3F8h, IRQ 4
I/O 3F8h, IRQ 3, 4, 5, 6, 7,
10, 11, 12
I/O 2F8h, IRQ 3, 4, 5, 6, 7,
10, 11, 12
I/O 3E8h, IRQ 3, 4, 5, 6, 7,
10, 11, 12
I/O 2E8h, IRQ 3, 4, 5, 6, 7,
10, 11, 12
Disabled Enable or disable LPT on Winbond SIO
Enabled
Auto Resource setting for LPT A on Winbond SIO
I/O 378h, IRQ 5, 7
I/O 278h, IRQ 5, 7
