Avnet Azure Sphere Guardian-100 Manual

Azure Sphere

Guardian-100

Thank you for selecting

GUARDIAN-100. Key links and

installation steps are provided

here to enable you to develop

Azure Sphere applications

that securely connect your

equipment to the internet.

STEP 1: Download Microsoft Azure Sphere SDK from:

aka.ms/AzureSphereSDK

STEP 2: Install Azure Sphere SDK on a Windows 10 computer, by

following the detailed instructions located at:

http:/ /avnet.me/ms_sphere_docs

STEP 3: Connect the provided cables and power-up Guardian:

- Connect the Ethernet cable from Guardian to the equipment

- Connect USB cable type-A connector to the on-site equipment

- Connect USB cable type-B connector to Guardian

- Once connected, the Guardian LEDs should indicate as follows:

1, 2, 3 LEDs: Amber

Power LED : Green

STEP 4: Complete the Microsoft installation instructions to:

- Set up an Azure Sphere account (and subscribe to notifications)

- Claim your device

- Configure Wi-Fi settings of your device

STEP 5: View documentation and download

example applications for the Guardian-100 from:

http:/ /avnet.me/mt3620-guardian
