6.9.8

LPSS Configuration

Feature
CAM1 I2C Controller
Set CAM1 I2C Speed
CAM0 I2C Controller
Set CAM0 I2C Speed
LPSS HSUART #1 Support
(D24:F0)
LPSS HSUART #2 Support
(D24:F1)
LPSS IOSF PMCTL S0ix
Enable
LPSS CAM1 I2C Clock
Gating Configuration
LPSS CAM0 I2C Clock
Gating Configuration
LPSS HSUART #1 Clock
Gating Configuration
LPSS HSUART #2 Clock
Gating Configuration
MSC C6C-AL
Options
Description
Disabled
Enable/Disable the CAM1 I2C Controller
PCI Mode
Standard Mode
Select CAM1 I2C Speed
Fast Mode
Fast Plus Mode
High Speed Mode
Disabled
Enable/Disable the CAM0 I2C Controller
PCI Mode
Standard Mode
Select CAM0 I2C Speed
Fast Mode
Fast Plus Mode
High Speed Mode
Disabled
Enable/Disable LPSS HSUART #1 Support
PCI Mode
Disabled
Enable/Disable LPSS HSUART #2 Support
PCI Mode
Enable
Enable LPSS IOSF Bridge PMCTL Register S0ix Bits
Disable
Enable
Enable/Disable LPSS CAM1 I2C Clock Gating
Disable
Enable
Enable/Disable LPSS CAM0 I2C Clock Gating
Disable
Enable
Enable/Disable LPSS HSUART #1 Clock Gating
Disable
Enable
Enable/Disable LPSS HSUART #2 Clock Gating
Disable
MSC C6C-AL User Manual
91 / 128
