Feature
SATA Drives
SCC Configuration
USB Configuration
Miscellaneous Configuration
6.9.7

HD Audio Configuration

Feature
HD-Audio Support
HD-Audio DSP
HD-Audio PME
MSC C6C-AL
Options
Description
Submenu
SATA Drives
Submenu
SCC Configuration Settings
Submenu
USB Configuration
Submenu
Enable/Disable Misc. Features
Options
Description
Enabled
Control Detection of the Azalia device.
Disabled
Disabled = Azalia will be unconditionally disabled
Enabled = Azalia will be unconditionally Enabled
Auto = Azalia will be enabled if present, disabled otherwise.
Enabled
Enable/Disable HD-Audio DSP
Disabled
Enabled
Enables PME wake of HD Audio controller during POST.
Disabled
MSC C6C-AL User Manual
90 / 128
