980 User Guide – MHL Compliance Tests
Rev. B29
1.5

980 User Interface

The 980 Protocol Analyzer provides a graphical user interface for operation. This GUI can run both on the 980 itself
through the built-in color touch screen display or as a standalone application running on a PC. The look and feel
and functions are similar but not identical.
1.5.1 980 GUI Manager
The external 980 GUI Manager provides easy access to the captured data on your PC for sharing with others. Also
the external 980 GUI Manager enables you to operate the 980 through a larger interface which allows you to use
multiple panels at the same time. There are two key features that are not available in the external 980 Manager
GUI however: 1) viewing the video in real time, 2) viewing the MHL video/audio metadata and DDC (MHL C-Bus)
transactions in real time using the Real Time mode.
1.5.2 980 Embedded GUI Manager – Real Time Monitoring
You can operate the 980 fully through the built-in color touch screen display. In addition to the basic operation of
the 980 Protocol Analyzer the touch screen display GUI also enables you to view the incoming video from a source
Page 5 July 26, 2011
