Snmp Granular Trap Packets - DPS Telecom NetGuardian 216 G4 User Manual

Tbl. B3 (.3)
ControlGrid points
ControlGrid
(1.3.6.1.4.1.2682.1.2.3)
Port (.1)
Address (.2)
Display (.3)
Point (.4)
Action (.5)
16.3

SNMP Granular Trap Packets

The tables below provide a list of the information contained in the SNMP Trap packets sent by the
NetGuardian.
SNMP Trap managers can use one of two methods to get alarm information:
1.Granular traps (not necessary to define point descriptions for the NetGuardian) OR
2.The SNMP manager reads the description from the Trap.
Tbl. B6 (.6) Analog
Channels
Channel Entry
(1.3.6.1.4.1.2682.1.4.6.1)
Channel Number (.1)
Enabled (.2)
Description (.3)
Value (.4)
Thresholds (.5)*
*If Mj, Mn is assumed
UDP Header Description
1238 Source port
162 Destination port
303
0xBAB0 Checksum
UDP Headers and descriptions
Tbl. B5 (.5) AlarmEntry
(1.3.6.4.1.2682.1.2.5.1)
AAddress (.2)
APntDesc (.5)*
* For specific alarm points,
see Table B6
Length
points
AlarmEntry
Aport (.1)
ADisplay (.3)
APoint (.4)
AState (.6)
