- Page 1 VoIP Bridge Server USER MANUAL Visit our website at www.dpstelecom.com for the latest PDF manual and FAQs. June 24, 2015 D-OC-UM10A.18100 Firmware Version 2.0A...
-
Page 2: Revision History
Notice The material in this manual is for information purposes and is subject to change without notice. DPS Telecom shall not be liable for errors contained herein or consequential damages in connection with the furnishing, performance, or use of this... -
Page 3: Table Of Contents
Contents Visit our w ebsite at w w w .dpstelecom .com for the latest PDF m anual and FAQs VoIP Bridge Server Overview Specifications Shipping List Optional Shipping Items Installation Tools Needed Mounting VoIP Bridge Server Back Panel Power Connection (+12 or +24VDC Build Option) Power Connection (-48 or -24VDC Build Option) LAN Connection VoIP Bridge Server Front Panel... -
Page 5: Voip Bridge Server Overview
VoIP Bridge Server Overview Your VoIP Conference Bridging Solution The VoIP Order Wire system from DPS Telecom is an effective way for technicians to communicate between sites. Sometimes, however, you need to host a "conference call" across multiple VoIP stations. - Page 6 Up to 5 VoIP Order Wire stations may connect via IP to a single VoIP Bridge Server in order to hold a conference call. Note: Firmware version 2.0A.0026 or higher could support up to 10 VoIP stations.
-
Page 7: Specifications
Specifications Protocols: Telnet, RTP, HTTP Dimensions: 1.720" H x 11.5" W x 4" D Weight: 1.5 lbs. Mounting: 19" rack or wall mount Power Input: -48VDC (-36 to -72 VDC) +24 VDC via 110VAC wall transformer (12 V to 30 VDC, Optional) -24VDC (Optional) Current Draw: 100 mA @ -24VDC... -
Page 8: Shipping List
DPS Telecom at 1-800-622-3314. VoIP Bridge Server VoIP Bridge Server User Manual D-PK-NG216 D-OC-UM10A.18100 ½-Amp GMT Fuses Lg. Power Connector (Main Pwr) -
Page 9: Optional Shipping Items
Two Standard Rack Screws Pads 1-100-12500-06 2-015-00030-00 Optional Shipping Items Small WAGO connector Long 19" Rack Ear 2-802-01020-00 (D-CS-325-10A-10) Installation Tools Needed To install the VoIP Bridge Server, you'll need the following tools: Phillips No. 2 Screwdriver Small Standard No. 2 Screwdriver PC with terminal emulator, such as HyperTerminal... -
Page 10: Mounting
Mounting The VoIP Bridge Server can be flush- or rear-mounted The dimensions (in inches) of the supplied 19" rack ears. Rack-Mounting Instructions The compact VoIP Bridge Server occupies only half the width of a standard rack unit. Unless you ordered a second "long" ear (not shown), only one rack ear is supplied with the VoIP Bridge Server. The single rack ear can be mounted on the left or right side of the unit. - Page 11 normal operation.) 2. After flanges have been attached to the VoIP Bridge Server, mount the unit in the desired location with two screws through each flange. Use the included wall mount bracket to mount the VoIP Bridge Server vertically on the wall.
-
Page 12: Voip Bridge Server Back Panel
VoIP Bridge Server Back Panel VoIP Bridge Server back panel connections... -
Page 13: Power Connection (+12 Or +24Vdc Build Option)
Power Connection (+12 or +24VDC Build Option) The VoIP Bridge Server is powered by a screw-on plug, located on the right side of the back panel. Close-up view of VoIP Bridge Server's screw-on power connector. Before you connect a power supply to the VoIP Bridge Server: 1. -
Page 14: Power Connection (-48 Or -24Vdc Build Option)
Power Connection (-48 or -24VDC Build Option) The VoIP Bridge Server can also be built with a single screw terminal barrier plug or WAGO power connector. Back panel power options To connect the VoIP Bridge Server to a power supply, follow these steps: 1. -
Page 15: Voip Bridge Server Front Panel
VoIP Bridge Server Front Panel VoIP Bridge Server Front panel connections and LEDs Craft Port DB9 RS-232 Pin # Signal Description Not connected Transmit data Recieve Data Not connected Ground Not connected Clear to send Request to send Not connected VoIP Bridge Server Front panel connections and LEDs Use the front panel craft port to connect the VoIP Bridge Server to a PC for onsite unit configuration. -
Page 16: Front And Back Panel Leds
Front and Back Panel LEDs VoIP Bridge Server LEDs Front Panel LED Descriptions Status Description Flashing Green Application is running Status Flashing Red Boot Loader is running. Solid Green 100 Mb/s 100BT 10 Mb/s Flashing Red Receiving data via craft port Craft Flashing Green Transmitting data via craft port... -
Page 17: How To Set Up The Voip Bridge Server
How to Set Up the VoIP Bridge Server The following steps are required in order to setup the VoIP Bridge Server and make your first conference call: 1. Set the VoIP Bridge Server's IP Address (using the TTY interface). 2. Add the VoIP Bridge Server to your VoIP Order Wire configuration using the "Orderwire Config" software. - Page 18 3. At the Connection Description screen, enter a 4. At the Connect To screen, select Com port name for this connection. You may also select an you'll be using from the drop down and click OK. icon. The name and icon do not affect your ability (COM1 is the most commonly used.) to connect to the unit.
-
Page 19: Add The Bridge Server To Your Order Wire Configuration
You have successfully assigned an IP address to the VoIP Bridge Server. This is the only configuration step required within the VoIP Bridge Serverself. Next, you will need to provision your VoIP Order Wire devices with the IP address of this VoIP Bridge Server. NOTE: If you changed your computer's IP earlier in order to connect to the VoIP Bridge Server, be sure to change the IP of your computer back to one that operates on your network. - Page 20 If you have additional Bridge Servers, you may use the other rows to configure them as well. Up to 8 Bridge Servers may be defined in a single Order Wire configuration. 3. Once you are satisfied with your configuration update, you must write the configuration to your VoIP Order Wire stations for it to take effect.
-
Page 21: Dial Into The Bridge Server From Order Wire Stations
Dial into the Bridge Server from Order Wire stations After giving your Bridge Server an IP address and adding it to the configuration of your Order Wire stations, you're now ready to make your first conference call using the Bridge Server. 1. -
Page 22: How To Upgrade Firmware Via Lan
How to Upgrade Firmware Via LAN The VoIP Bridge Server's web interface is used for only one purpose: upgrading firmware. To connect, type the VoIP Bridge Server's assigned IP address into the address bar of your web browser followed by /multiload (http://yourIPaddress/multiload), and press Enter. At the login prompt, use the following username and password (NOTE: The username and password cannot be modified): Username: admin... -
Page 23: Frequently Asked Questions
Here are answers to some common questions from VoIP Bridge Server users. The latest FAQs can be found on the DPS Telecom support web page, http://www.dpstele.com/support/ If you have a question about the VoIP Bridge Server, please call DPS Telecom at (559) 454-1600 or e- mail us at support@dpstele.com 10.1 General FAQs Q. -
Page 24: Technical Support
Please have your user manual and hardware serial number ready. 3. Have access to troubled equipment. Please be at or near your equipment when you call DPS Telecom Technical Support. This will help us solve your problem more efficiently. -
Page 25: End User License Agreement
DPS Telecom which arise out of or are related to the non-fulfillment of any covenant or obligation of End User in connection with this Agreement. - Page 27 Warranty DPS Telecom warrants, to the original purchaser only, that its products a) substantially conform to DPS' published specifications and b) are substantially free from defects in material and workmanship. This warranty expires two years from the date of product delivery with respect to hardware and ninety days from the date of product delivery with respect to software.
- Page 28 Free Tech Support is Only a Click Away Need help with your alarm monitoring? DPS Information Services are ready to serve you … in your email or over the Web! www.DpsTele.com Free Tech Support in Your Email: The Protocol Alarm Monitoring Ezine The Protocol Alarm Monitoring Ezine is your free email tech support alert, delivered directly to your in-box every two weeks.
