8.1
Configure Serial Port via TTY
1. To enter configuration setting for the Serial Port, login to the TTY interface and press C)onfig > pr(I)
maryPort.
2. Press the hot keys to toggle through the following options. (* Indicates default settings:)
NOTE: Default settings may not reflect the primary interface that shipped in the unit.
· Port Type: 232*, 485, 202
· Baud: 115200*, 57600, 19200, 9600, 4800, 2400, 1200
· Parity: None*, even, odd
· Stop bits: 1*, 2
3. Set the RTS head / tail if using 202. (Carrier time) Suggested settings are: head=60; tail=40; 0,0 if
using RS232.
Fig. 8.2 Serial port configuration
