PROGRAMMING

Before You Begin

Read this guide before you begin programming. This guide allows you to quickly learn the programming options and
operational capabilities of the DualCom communicator. The communicator contains all of its programming information
in an on‑board processor and does not require an external programmer.
In addition to this manual, you should also be familiar with the following document:
• DualCom Communicator Programming Sheet (LT‑1860)
Programming Sheet
Fill out the programming sheet included with this device before you begin programming. The programming sheet lists
the various options available for programming the communicator and allows you to keep a record of what options you
intend to enter, reducing programming errors.
Default Master Code
Universal Communicators Version 194 and higher ship with a unique four‑digit
default master code. This master code is generated with algorithm that
ensures it cannot be duplicated. The code can be modified or deleted in panel
programming. To revert the default code to 99, use the Clear All Codes option
found in the Initialization menu. Panels ship with the master code on the serial
number label in parentheses next to the serial number.

Getting Started

Initializing the Communicator
When programming a communicator for the first time or rewriting the entire program of an existing communicator,
use the initialization programming option. See Initialization. Initializing clears the communicator's memory and sets
the highest user number to user code 99.
Accessing the Programmer
To access the programmer function of the communicator:
1. Connect the keypad to the programming header.
2. Press and release the reset button.
3. Enter 6653 (PROG). The keypad displays PROGRAMMER.

Programming Menu

The following is a list of programming menu options available in the programming menu. Press CMD to advance
through the programming menu options. To select a menu option, press any select area when the desired menu
option displays on the keypad. Use this list to navigate to your desired programming menu option in this guide.
• Initialization
• Communication
• Network Options
• Remote Options
• System Reports
• System Options
• Output Options
• Area Information
• Zone Information
• Stop
• Set Lockout Code
• Z‑Wave Setup (DualComWZ Only)
