NETWORK OPTIONS

Network options are provided to define the network configuration for the communicator. This information will be used
during communication of messages via network.
Note: IP addresses and port numbers may need to be assigned by the network administrator. When entering
an IP, gateway, or subnet mask address, be sure to enter all 12 digits and leave out the periods. For example, IP
address 192.168.000.250 is entered as 192168000250.
NETWORK OPTIONS
WPS LIST MANUAL
TEST
SEARCHING .
WPS LIST MANUAL
SEARCHING
SIGNAL
▐▐▐▐▐▐▐
COMNET123
W/L SECURITY:
WPA‑PSK
W/L SECURITY:
WEP WPA NONE
W/L KEY:
*****************
W/L KEY:
‑
Digital Monitoring Products
20
NETWORK OPTIONS
This option is for configuring the desired network settings. Press any select key or area to
select.
WIFI SETUP
This option is for connecting to the desired Wi‑Fi network and will display only when
Communication Type is set to Wi‑Fi. Press any select key or area to select.
WPS LIST MANUAL displays. Press the first select key or area to choose WPS to
automatically connect to a WPS enabled router. Press the second select key or area to
choose LIST and see the name and signal strength of any Wi‑Fi routers in range. Press
the third or fourth select key or area to choose MANUAL and enter the name of the Wi‑Fi
router you wish to connect to. Pressing CMD displays TEST. To select TEST, press the first
select key or area to verify connection of your system to the Wi‑Fi network.
WPS
When WPS is selected, SEARCHING displays. Press the WPS button on the Wi‑Fi network
router to which you are attempting to connect. SEARCHING displays for up to two minutes
or until connected to the WPS enabled router. Refer to the router's instruction manual for
sending a security key to the communicator.
If the panel fails to connect to the WPS enabled router, WPS FAILED RETRY? NO YES
displays. Press the fourth select key or area to RETRY or press the third select key or area
to display WPS LIST MANUAL.
LIST
When LIST is selected, SEARCHING displays until any Wi‑Fi networks are found in range.
Once available Wi‑Fi networks are found the keypad displays the name of the SSID (Wi‑Fi
Network name) and signal strength of each network. Press CMD to scroll through the list of
available Wi‑Fi networks. When the desired network is displayed, press any select key or
area to connect.
Note: If the panel is unable to detect the security type, W/L SECURITY with the default
security type WPA‑PSK displays. If a different security type is required, press CMD and
WEP WPA NONE displays. Press the select key or area of the desired security type to
choose.
When connecting to the Wi‑Fi network the panel also detects the security type in use and
W/L KEY: *************** displays.
Enter the W/L KEY and the panel performs a connection test and CONNECTING displays.
When successful, CONNECTED displays on the keypad. If the panel does not connect to
the Wi‑Fi network, NOT CONNECTED displays. Press CMD to return to the Wi‑Fi SETUP
main screen.
