DMP Electronics DUALCOM Series Programming And Installation Manual page 23

WPS LIST MANUAL
WIFI SETUP
ENTER SSID
SSID:
SSID FOUND
SSID:
SSID NOT FOUND
TEST
W/L SECURITY:
WPA‑PSK
W/L SECURITY:
WEP WPA NONE
W/L KEY:
*****************
W/L KEY:
‑
DHCP NO YES
LOCAL IP ADDR
192.168.0.250
DualCom Programming and Installation Guide
MANUAL
This option allows you to enter the desired network name using the keypad. When
MANUAL is selected, the current settings display. Press CMD to continue with no change.
SecureCom is the default.
Use the number keys on the keypad to enter a new or different SSID (Wi‑Fi Network
name), there is no need to press the select keys or areas. Once the SSID is entered, press
CMD and SEARCHING displays.
When an SSID is entered for the first time or changed, the panel searches for the SSID
entered to ensure communication. The keypad displays SSID FOUND or SSID NOT FOUND.
When the SSID is found, the security type is also detected.
Depending on the security type, the SSID might take several seconds to process.
Enter up to 32 characters for the SSID from the network router to identify the network
LAN. The SSID is blank by default. Use the chart to enter lowercase or special characters.
Each successive press of the select key or area gives additional options. For example, to
enter Me5%, you would press key # 5, select key or area 1 (M); press key # 2, select key or
area 2 twice (e); press key # 5 (5); press key # 7, select key or area 4 twice (%).
Key Select Key 1 Select Key
Number
1 A, a,
2 D, d
3 G, g
4 J, j
5 M, m
6 P, p
7 S, s
8 V, v
9 Y, y
0 ‑, +
While searching, the keypad displays SEARCHING. If the communicator is unable to
connect to the desired network and SSID NOT FOUND displays, press CMD to return to
the main menu and WPS LIST MANUAL displays. Press CMD again to display TEST.
Enter the Wireless Network Key for the network and press CMD to save the key.
TEST
Press the first select key or area to select TEST and the communicator will attempt to
verify connection of your system to the desired Wi‑Fi network.
WIRELESS SECURITY TYPE
When successful, W/L SECURITY displays. Select the security type based on the network
router programming. The default network security type is WPA‑PSK. Press any select key
or area to display the other security options. The available options are WEP, WPA, and
NONE.
Press the first select key or area to choose WEP, press the second select key or area for
WPA, press the third select key or area for NONE.
WIRELESS NETWORK KEY
This option displays only if Comm Type is set to Wi‑Fi and Security option is enabled? .
Enter the key provided from the network router's programming. WEP requires a network
password of 10 characters (WEP64) or 26 characters (WEP128), using a combination of
the number 0‑9 and the letters A‑F (See the chart above to enter lowercase or special
characters).
WPA/WPA‑PSK uses a custom key that allows 8 to 32 characters.
Note: Depending on the security type, the key might take several seconds to process.
DHCP MODE ENABLED
Choose YES if the communicator uses a dynamic IP address. The communicator will
operate in DHCP and will not use the local IP address number. The default is YES.
Choose NO to have the communicator use the IP address entered in local IP address.
LOCAL IP ADDRESS
Enter the local IP address for the communicator. The local IP address must be unique and
cannot be duplicated on the network. The default local IP address is 192.168.0.250.
Select Key
2 3
B, b C, c
E, e F, f
H, h I, i
K, k L, l
N, n O, o
Q, q
R, r
T, t U, u
W, w X, x
Z, z space, :
., ' *, <
Select Key
4
(, [, {
: When
Note
), ], }
\ is entered,
!, ^, ~
the keypad
displays ¥.
?, ", |
When ~ is
/, \, `
entered, ‑>
&, $
displays.
@, %
, =
_, ;
#, >
Digital Monitoring Products
21
