RECEIVER 2 PROG
NO YES
ALARM
SPV/TRBL NO YES
O/C USER NO YES
TEST RPT NO YES
FIRST IP ADDR
000.000.000.000
FIRST IP PORT
2001
SECOND IP ADDR
000.000.000.000
SECOND IP PORT
2001
DualCom Programming and Installation Guide
RECEIVER 2 PROGRAMMING
Set the options for the second receiver the communicator attempts to contact when
sending reports from the host panel and/or communicator. The communicator supports
communication up to two receivers.
Note: If you select YES for any of the receiver 2 options, you must have at least one IP
address programmed in receiver 2 programming. The receiver 2 defaults are set to NO.
ALARM REPORTS
Choose YES to enable Abort, Alarm, Alarm Restoral, Alarm Bell Silenced, Ambush, Exit
Error, and System Recently Armed reports to be sent to this receiver.
Choose NO to disable sending these reports to the receiver. The default is NO.
SUPERVISORY/TROUBLE REPORTS
Choose YES to enable Supervisory, Trouble, Trouble Restoral, Force Armed, Late to Close,
and Fault reports to be sent to this receiver.
Choose NO to disable sending these reports to the receiver. The default is NO.
OPENING/CLOSING AND USER REPORTS
Choose YES to enable Opening/Closing, Schedule and Code Changes, and Bypass reports
by user to be sent to this receiver.
Choose NO to disable sending these reports to the receiver. The default is NO.
TEST REPORT
Choose YES to enable the recall test report from the host panel and/or communicator to
be sent to the receiver.
Choose NO to disable sending this report to the receiver. The default is NO.
FIRST IP ADDRESS
Enter the first (primary) IP address where the communicator sends cell messages. Enter
all 12 digits and leave out the periods. For example, enter IP address 192.168.0.250 as
192168000250. The periods display automatically.
FIRST IP PORT
Enter the first IP port number to be used with the first IP address. The IP port identifies the
port used to communicate messages with the panel. The default IP port setting is 2001.
SECOND IP ADDRESS
Enter the second IP address where the communicator sends network messages. Enter all
12 digits and leave out the periods. The periods display automatically.
SECOND IP PORT
Enter the second IP port number to be used with the second IP address. The IP port
identifies the port used to communicate messages with the panel. The default IP Port
setting is 2001.
