- Page 1 All manuals and user guides at all-guides.com OPERATOR’S MANUAL Model 632 Combo Freezer Original Operating Instructions 03/2000 (Original Publication) 030049-M (Updated 6/28/2018)
- Page 2 Note: Only instructions originating from the factory or its authorized translation representative(s) are considered to be the original set of instructions. © 2000 Taylor Company 030049-M Any unauthorized reproduction, disclosure, or distribution of copies by any person of any portion of this work may be...
-
Page 3: Table Of Contents
Model 632 ........ - Page 4 All manuals and user guides at all-guides.com Table of Contents Section 6: Operating Procedures Set-Up for Machines with a Syrup Rail ........6-1 Soft Serve Side Freezing Cylinder Assembly .
-
Page 5: Section 1: To The Installer
Taylor machines. trained personnel. Failure to comply may result in • Only authorized Taylor service personnel should personal injury. perform installation and repairs on the machine. • Authorized service personnel should consult OSHA Standard 29CFRI910.147 or the... -
Page 6: Air-Cooled Machines
Electrical Connections Uncrate the machine and inspect it for damage. Report any damage to your Taylor distributor. This piece of equipment is made in the USA and has IMPORTANT! In the United States, this USA sizes of hardware. All metric conversions are machine is intended to be installed in accordance with approximate and vary in size. -
Page 7: Beater Rotation
(5021 of IEC 60417-1) on Note: The following procedures must be performed by the removable panel and the frame. an authorized Taylor service technician. • To correct the rotation on a three-phase machine, interchange any two incoming power supply lines at freezer main terminal block. -
Page 8: Refrigerant
Keep eyes CAUTION! In consideration of our and skin protected. If refrigerant burns should occur, environment, Taylor uses only earth-friendly HFC flush the area immediately with cold water. If burns are refrigerants. The HFC refrigerant used in this machine is severe, apply ice packs and contact a physician R404A. -
Page 9: Section 2: To The Operator
To the Operator Section 2 The freezer you have purchased has been carefully Note: Your Taylor warranty is valid only if the parts are engineered and manufactured to give you dependable authorized Taylor parts, purchased from the local operation. The Taylor Model 632, when properly operated authorized Taylor distributor, and only if all required and cared for, produces a consistent quality product. - Page 10 All manuals and user guides at all-guides.com TO THE OPERATOR Compressor Warranty Disclaimer It should also be noted that Taylor does not warrant the refrigerant used in its equipment. For example, if the The refrigeration compressor(s) on this machine are...
-
Page 11: Section 3: Safety
We at Taylor Company are concerned about the safety of the operator when they come in contact with the freezer and its parts. Taylor has gone to extreme efforts to design and manufacture built-in safety features to protect both WARNING! Avoid injury. - Page 12 Failure to follow these instructions may result in electrocution. Contact your local authorized Taylor distributor for service. IMPORTANT! Access to the service area of the machine is restricted to persons having knowledge and practical experience with the machine, in particular as far as safety and hygiene are concerned.
- Page 13 NOISE LEVEL: Airborne noise emission does not exceed 78 dB(A) when measured at a distance of 39 inches (1.0 m) from the surface of the machine and at a height of 63 inches (1.6 m) from the floor. Safety Model 632...
- Page 14 All manuals and user guides at all-guides.com SAFETY Notes: Safety Model 632...
-
Page 15: Section 4: Operator Parts Identification
All manuals and user guides at all-guides.com Operator Parts Identification Section 4 Model 632 Figure 4-1 Operator Parts Identification Model 632... - Page 16 All manuals and user guides at all-guides.com OPERATOR PARTS IDENTIFICATION Model 632 Item Description Part No. Item Description Part No. Kit A.-Cover-Hopper X65369 Screw-1/4-20X3/8 RHM-SS 011694 Tube-Feed-Shake-5/16 Hole 028967-7 034081 Caster-4" SWV 5/8 Stem w/Brake Tube A.-Feed-SS-5/32 Hole X29429-2 Panel-Service...
-
Page 17: Soft Serve Door Assembly
All manuals and user guides at all-guides.com OPERATOR PARTS IDENTIFICATION Soft Serve Door Assembly Figure 4-2 Operator Parts Identification Model 632... - Page 18 Duro (Bag of 25) O-ring-5/16 OD X .070 W 016272 (Bag of 50) Screw-Adjustment-5/16-24 055092 Pin A.-Pivot X22820 Handle A.-Draw ADJ. X55096 Door A.-1 Spout X51531-10 Gasket-Door HT 4"-Double 048926 Baffle A.-Long 4 in. w/RAD X50882 Bearing-Front 050216 Operator Parts Identification Model 632...
-
Page 19: Shake Door Assembly
Gasket-Door 5.177ID 016672 Baffle A.-19 Inch X30274 Bearing-Front 013116 Nut-Stud 021508 Beater A.-7QT-1 Pin X46233 O-ring-1-1/16 OD X.139 W 020571 (100 to Bag) Shaft-Beater 032790 Decal-Lift Plate Front 015200 Seal-Drive Shaft 032560 *Not shown. Blade-Scraper-Plastic 084950 Operator Parts Identification Model 632... -
Page 20: Accessories
OPERATOR PARTS IDENTIFICATION Accessories Figure 4-4 ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. 013071 Lubricant-Taylor 4 oz. 047518 Brush-Rear BRG 1"D X 2" LG X Pail-Mix 10 qt. 013163 013072 Brush-DBL End-Pump and Feed See note. ® Sanitizer-Stera Sheen Tube *Note: A sample container of sanitizer is sent with the machine. -
Page 21: Section 5: User Interface
If you neglect to add mix, a freeze- up may occur. Insufficient mix will cause eventual Thermistor Control damage to the beater, blades, drive shaft, and freezer Adjustable Draw Handle door. RESET Button User Interface Model 632... -
Page 22: Mix Key
Wash mode. If the beater motor is turning properly, press the WASH key to cancel the cycle. Press the AUTO key to resume normal operation. User Interface Model 632... -
Page 23: Air Tube (Soft Serve)
During sanitizing and rinsing, the flow rate can be increased by removing the pivot pin and placing the restrictive bar on the top. When drawing product, always place the restrictive bar on the bottom. User Interface Model 632... - Page 24 All manuals and user guides at all-guides.com USER INTERFACE Notes: User Interface Model 632...
-
Page 25: Section 6: Operating Procedures
Note: When lubricating parts, use an approved food These opening procedures show you how to assemble grade lubricant (example: Taylor Lube). the parts into the freezer, sanitize them, and prime the freezer with fresh mix in preparation to serve your first portion. - Page 26 If this is the case, around the beater following the helix. Push the blade contact your authorized Taylor service technician. down onto the helix as you wrap. At the back of the 6. Before assembling the freezer door, check the beater, slip the blade under the hook.
- Page 27 9. Slide the two O-rings into the grooves on the prime 12. Install the draw valve. Slide the two O-rings into the plug. Apply an even coat of Taylor Lube to the O- grooves on the draw valve, and lubricate them.
- Page 28 20. Lay the air tube (with the air orifice installed) in the two O-rings onto the other end of the air tube. bottom of the mix hopper for sanitizing. Note: The air tube for the shake side does not require O-rings or an air orifice. Figure 6-14 Operating Procedures Model 632...
-
Page 29: Shake Side Freezing Cylinder Assembly
Shake Side Freezing Cylinder Assembly Note: When lubricating parts, use an approved food grade lubricant (example: Taylor Lube). WARNING! Make sure the POWER SWITCH is in the OFF position. Failure to follow this instruction may result in severe personal injury from hazardous moving parts. - Page 30 7. Lubricate the inside of the freezer door spout, top and bottom, and insert the draw valve into the freezer Figure 6-24 door from the top. It will be necessary to rotate the draw valve to the right when assembling the door to the freezer. Operating Procedures Model 632...
-
Page 31: Sanitizing
Figure 6-26 13. Install the drip tray and splash shield. Figure 6-28 4. Place the POWER SWITCH in the ON position. Operating Procedures Model 632... - Page 32 10. Repeat steps 1 through 9 for the shake side of the freezer. Figure 6-31 7. When a steady stream of sanitizing solution flows from the prime plug opening in the bottom of the freezer door, open the draw handle. Draw off all the sanitizing solution. Operating Procedures Model 632...
-
Page 33: Priming
Figure 6-35 8. Repeat step 1 through step 7 for the other side of the freezer. 3. Lubricate the O-rings on the air tube on the end with the small hole on the side (soft serve only). Operating Procedures Model 632... -
Page 34: Closing Procedure
4. Repeat steps 1 through 3 for the other side of the close the draw handle and press the WASH key freezer. cancelling the Wash mode. 8. Repeat steps 1 through 7 for the other side of the freezer. 6-10 Operating Procedures Model 632... -
Page 35: Disassembly
If there is more than one O-ring to be removed, always remove the rear O-ring first. This will allow the O-ring to slide over the forward rings without falling into the open grooves. Operating Procedures 6-11 Model 632... - Page 36 All manuals and user guides at all-guides.com OPERATING PROCEDURES Notes: 6-12 Operating Procedures Model 632...
-
Page 37: Section 7: Important: Operator Checklist
The temperature of the mix in the mix hopper and walk-in cooler should be below 40°F (4.4°C.). Important: Operator Checklist Model 632... -
Page 38: Regular Maintenance Checks
Follow all lubricating procedures as outlined in: Your local Taylor service technician can perform this “Soft Serve Side Freezing Cylinder Assembly” on winter storage service for you. page 6-1, and “Shake Side Freezing Cylinder Wrap detachable parts of the freezer such as the beater, Assembly”... -
Page 39: Section 8: Troubleshooting Guide
Do not lubricate the hex end of the drive shaft. b. Mix and lubricant collected in the b. Brush clean the rear shell bearing 6-11 drive coupling. area regularly. Troubleshooting Guide Model 632... - Page 40 Install the air tube in the mix inlet hole, using the end with the small hole in the side. d. The air orifice is not installed (soft d. Install the air orifice in the air tube. serve). Troubleshooting Guide Model 632...
- Page 41 White Bristle Brush, 1” x 2” Inspect and replace Minimum if necessary. Black Bristle Brush, 1” x 2” inspect and replace Minimum if necessary. Double-Ended Brush Inspect and replace Minimum if necessary. *Shake scraper blade replacement is every 4 months. Parts Replacement Schedule Model 632...
- Page 42 All manuals and user guides at all-guides.com PARTS REPLACEMENT SCHEDULE Notes: Parts Replacement Schedule Model 632...
- Page 43 Taylor, through an authorized Taylor distributor or service agency, will provide a new or remanufactured part, at Taylor’s option, to replace the failed defective part at no charge for the part. Except as otherwise stated herein, these are Taylor’s exclusive obligations under this limited warranty for a Product failure. This limited warranty is subject to all provisions, conditions, limitations and exclusions listed below and on the reverse (if any) of this document.
- Page 44 LEGAL REMEDIES The owner must notify Taylor in writing, by certified or registered letter to the following address, of any defect or complaint with the Product, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Product under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies..
- Page 45 Taylor warrants the Parts against failure due to defect in materials or workmanship under normal use and service as follows. All warranty periods begin on the date of original installation of the Part in the Taylor unit. If a Part fails due to defect during the applicable warranty period, Taylor, through an authorized Taylor distributor or service agency, will provide a new or remanufactured Part, at Taylor’s option, to replace the failed defective Part at no charge for the Part.
- Page 46 Taylor. 5. Replacement of wear items designated as Class “000” Parts in the Taylor Operator’s Manual, as well as any release sheets and clips for the Product’s upper platen assembly.
- Page 47 LEGAL REMEDIES The owner must notify Taylor in writing by certified or registered letter to the following address of any defect or complaint with the Part, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Part under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.
- Page 48 All manuals and user guides at all-guides.com LIMITED WARRANTY ON PARTS Notes: 11-4 Limited Warranty on Parts Model 632...
