Original Operating Instructions
059060- M
Model C707
Soft Serve Freezer
OPERATOR'S
MANUAL
May, 2003 (Original Publication)
(Updated 2/25/15)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C707 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Taylor C707

Summary of Contents for Taylor C707

  • Page 1 OPERATOR’S MANUAL Model C707 Soft Serve Freezer Original Operating Instructions 059060- M May, 2003 (Original Publication) (Updated 2/25/15)
  • Page 2 Complete this page for quick reference when service is required: Taylor Distributor: Address: Phone: Service: Parts: Date of Installation: Information found on the data label: Model Number: Serial Number: Electrical Specs: Voltage Cycle Phase Maximum Fuse Size: Minimum Wire Ampacity: E 2003 Carrier Commercial Refrigeration, Inc.

  • Page 3: Table Of Contents

    ............Model C707 Single Spout Door and Beater Assembly .
  • Page 4 Statutory Damages of up to $250,000 (17 USC 504) for infringement, and may result in further civil and criminal penalties. All rights reserved. Taylor Company a division of Carrier Commercial Refrigeration, Inc. 750 N. Blackhawk Blvd. Rockton, IL 61072 Table of Contents Model C707...

  • Page 5: To The Installer

    DO NOT obstruct air intake and discharge openings: questions. The Model C707 air cooled unit requires a minimum of Care should be taken to ensure that all basic safety 6” (152 mm) of clearance on both sides and 0” in the practices are followed during the installation and rear of the unit.
  • Page 6 FOLLOW YOUR LOCAL ELECTRICAL CODES! gap of at least 3 mm installed in the external installation. To the Installer Model C707...
  • Page 7 If burns are severe, apply ice packs and contact a physician immediately. Beater rotation must be clockwise as viewed Taylor reminds technicians to be cautious of looking into the freezing cylinder. government laws regarding refrigerant recovery, Note: The following procedures should be recycling, and reclaiming systems.

  • Page 8: To The Operator

    It is the unit owner’s responsibility to make this fact known to any technician he employs. Note: Your Taylor warranty is valid only if the parts are authorized Taylor parts, purchased from the local authorized Taylor Distributor, and only if all required...

  • Page 9: Safety

    We, at Taylor Company, are concerned about the safety of the operator when he or she comes in contact with the freezer and its parts. Taylor has gone to extreme efforts to design and manufacture built- in DO NOT operate the freezer unless it is safety features to protect both you and the service properly grounded.
  • Page 10 DO NOT obstruct air intake and discharge openings: DO NOT put objects or fingers in the door The Model C707 air cooled unit requires a minimum of spout. This may contaminate the product 6” (152 mm) of clearance on both sides and 0” in the and cause severe personal injury from blade rear of the unit.

  • Page 11: Operator Parts Identification

    Section 4 Operator Parts Identification Model C707 ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. KIT A.- COVER- HOPPER X65368 PANEL A.- SIDE- RIGHT X64151 PAN- DRIP 11- 5/8 LONG 027503 PANEL- REAR 056077- SP1 PIN- RETAINING- HOPPER CVR 043934...

  • Page 12: Model C707 Single Spout Door And Beater Assembly

    Model C707 Single Spout Door and Beater Assembly ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. DOOR A.- W/BAFFLE X56071- SER O- RING- 7/8 OD X .103W 014402 (100 TO BAG) BAFFLE A.- LONG 4 IN X50882 NUT- STUD- LONG 058765 HANDLE A.- DRAW- WELDED...

  • Page 13: Brushes

    PART NO. ITEM DESCRIPTION PART NO. BRUSH- REAR·BRG·1 D X 2 LG 013071 BRUSH- MIX·PUMP·BODY- 3 X 7 023316 BRUSH- DOUBLE·ENDED 013072 BRUSH- END- DOOR- SPOUT 039719 BRUSH- DRAW·VALVE·1 X 2 X 17 013073 150225 Model C707 Operator Parts Identification...

  • Page 14: Important: To The Operator

    ITEM DESCRIPTION MIX LOW INDICATOR LIGHT AUTO KEY MIX OUT INDICATOR LIGHT RESET BUTTON - BEATER MOTOR MIX REFRIGERATION KEY POWER SWITCH (TOGGLE) STANDBY KEY HOPPER TEMPERATURE INDICATOR WASH KEY FLAVOR BURST JACK 140618 Important: To the Operator Model C707...

  • Page 15: Symbol Definitions

    When the MIX REF key is pressed, the light comes on symbols have replaced words on many of our operator indicating the mix hopper refrigeration system is switches, function, and fault indicators. Your Taylor operating. The MIX REF function cannot be cancelled equipment is designed with these International unless the AUTO or STANDBY modes are cancelled symbols.

  • Page 16: Wash Key

    Figure 2 Adjustable Draw Handle WASH Key The Model C707 features an adjustable draw handle to provide the best portion control. The draw handle should be adjusted to provide a flow rate of 5 to 7- 1/2 When the WASH key is pressed, the light comes on.

  • Page 17: Feed Tube Assembly

    Note: The air orifice is used to meter a certain amount of air into the freezing cylinder. The air orifice maintains overrun and allows enough mix Figure 5 to enter the freezing cylinder after a draw. 130709 Model C707 Important: To the Operator...

  • Page 18: Operating Procedures

    Section 6 Operating Procedures The C707 unit stores mix in a hopper. It has a 3.4 quart Fill the inside portion of the seal with 1/4” more (3.2 liter) capacity freezing cylinder and a 20 quart lubricant and lubricate the flat side of the seal that fits onto the rear shell bearing.
  • Page 19 Slide the beater the remainder of the way into the freezing cylinder and over the end of the drive shaft. The beater should fit snugly but not so tightly that the beater cannot be turned slightly to engage the drive shaft. Figure 11 Model C707 Operating Procedures...
  • Page 20 Secure with pivot pin. Figure 13 Slide the two o- rings into the grooves on the prime plug. Apply an even coat of Taylor Lube to the o- rings and shaft. Figure 16 Note: This unit features an adjustable draw handle to provide the best portion control.
  • Page 21 Slide the rear drip pan into the hole in the side panel. Figure 18 Slide the small o- ring into the groove of the air orifice. Do not lubricate the o- ring. Figure 19 Figure 21 140618 Model C707 Operating Procedures...

  • Page 22: Sanitizing

    Place the power switch in the ON position. sensing probe on the front wall and the bottom of the hopper, the mix hopper, and the feed tube. Figure 23 Figure 26 080715 Operating Procedures Model C707...
  • Page 23 When a steady stream of sanitizing solution is flowing from the prime plug opening in the bottom of the freezer door, pull the draw handle down. Draw off all of the sanitizing solution. Figure 31 140618 Model C707 Operating Procedures...

  • Page 24: Priming

    Closing Procedure To disassemble your unit, the following items will be needed: Two cleaning pails Sanitized stainless steel rerun can with lid Necessary brushes (provided with freezer) Cleaner Single service towels Figure 33 140618 Operating Procedures Model C707...

  • Page 25: Draining Product From The Freezing Cylinder

    Once the cleaning solution stops flowing from the door With a pail beneath the door spout, raise the prime plug spout, raise the draw handle and press the WASH key, and press the WASH key. cancelling the WASH mode. 140717 Model C707 Operating Procedures...

  • Page 26: Disassembly

    Step 3 overnight. From the freezer door remove the gasket, front bearing, pivot pin, adjustable draw handle, draw valve, Step 7 and prime plug. Remove all o- rings. Wipe clean all exterior surfaces of the freezer. 110915 Operating Procedures Model C707...

  • Page 27: Important: Operator Checklist

    When using rerun, skim off the foam and discard. Mix the rerun with fresh mix in a ratio of 50/50 during the j 5. Follow all lubricating procedures as outlined in days operation. “Assembly”. 080401 Model C707 Important: Operator Checklist...

  • Page 28: Winter Storage

    7. If your machine is equipped with an auxiliary Your local Taylor Distributor can perform this winter refrigeration system, check the auxiliary storage service for you. condenser for accumulation of dirt and lint. Dirty...

  • Page 29: Troubleshooting Guide

    The mix hopper cover is b. Place the cover in position. not in position. c. The MIX REF light is not c. Press the MIX REF key. lit. Model C707 Troubleshooting Guide...
  • Page 30 Inadequate lubrication of b. Lubricate properly. draw valve o- rings. c. Wrong type of lubricant is c. Use the proper lubricant (example: Taylor Lube). being used (example: petroleum base lubricant). 10. No freezer operation after a. Unit is unplugged.

  • Page 31: Parts Replacement Schedule

    White Bristle Brush, 1/2” x 1/2” Inspect & Replace Minimum if Necessary White Bristle Brush, 3/16” x 1” Inspect & Replace Minimum if Necessary White Bristle Brush, 3” x 1/2” Inspect & Replace Minimum if Necessary 110915 Model C707 Parts Replacement Schedule...

  • Page 32: Section 10 Limited Warranty On Equipment

    Taylor, through an authorized Taylor distributor or service agency, will provide a new or re- manufactured part, at Taylor’s option, to replace the failed defective part at no charge for the part. Except as otherwise stated herein, these are Taylor’s exclusive obligations under this limited warranty for a Product failure.
  • Page 33 LEGAL REMEDIES The owner must notify Taylor in writing, by certified or registered letter to the following address, of any defect or complaint with the Product, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Product under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.

  • Page 34: Limited Warranty On Parts

    Taylor warrants the Parts against failure due to defect in materials or workmanship under normal use and service as follows. All warranty periods begin on the date of original installation of the Part in the Taylor unit. If a Part fails due to defect during the applicable warranty period, Taylor, through an authorized Taylor distributor or service agency, will provide a new or re- manufactured Part, at Taylor’s option, to replace the failed defective Part at no...
  • Page 35 Parts or the units in which they are installed repaired or altered in any way so as, in the judgment of Taylor, to adversely affect performance, or normal wear or deterioration.

  • Page 36: Taylor Company

    LEGAL REMEDIES The owner must notify Taylor in writing, by certified or registered letter to the following address, of any defect or complaint with the Part, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Part under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.
  • Page 37 6-STBY DIS 7-INTERVAL 8-INTERVAL JMPR SWITCH INTERVAL SHAKE TEMP. MFG DATE MODEL C706 TIME S.S.VISCOSITY STANDBY MIX PUMP MOTOR RESET SWITCH (SEE FIG.4) GRN/YEL MIX PUMP MOTOR RELAY PUMP MOTOR Taylor Company Model C707 064288-27 06/14 2014 Carrier Commercial Refrigeration, Inc.
  • Page 38 TIME S.S.VISCOSITY S.S.VISCOSITY STANDBY STANDBY MIX PUMP MOTOR MIX PUMP MOTOR RESET SWITCH RESET SWITCH MIX PUMP MIX PUMP MOTOR MOTOR (SEE FIG.3) RELAY PUMP RELAY PUMP MOTOR MOTOR Taylor Company Model C707 064288-33 06/14 2014 Carrier Commercial Refrigeration, Inc.
  • Page 39 6-STBY DIS 7-INTERVAL 8-INTERVAL GRN/YEL JMPR SWITCH INTERVAL SHAKE TEMP. MFG DATE TIME S.S.VISCOSITY STANDBY MODEL C706 MIX PUMP MOTOR RESET SWITCH (SEE FIG.4) MIX PUMP MOTOR Taylor Company Model C707 RELAY PUMP MOTOR 064288-40 06/14 2014 Carrier Commercial Refrigeration, Inc.
  • Page 40 COMP BTR PUMP FAN RED/WHT GRN/YEL ORN/WHT GRN/YEL GRN/YEL GRN/YEL CABINET FAN (WATER COOLED ONLY) GRA/WHT CONDENSER FAN (AIR COOLED) MODEL C706/C707 DRAW MIX 1 FAN MIX 2 PUMP PROBE SOFTECH CONTROL BARREL LIQUID SET POINT MIX LOW MIX OUT SOLENOID TAYLOR CO.
