Taylor 161 Operator's Manual
  1. Manuals
  2. Brands
  3. Taylor Manuals
  4. Freezer
  5. 161
  6. Operator's manual

Taylor 161 Operator's Manual

Soft serve freezer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Original Operating Instructions
055155-M
Model 161
Soft Serve Freezer
OPERATOR'S
MANUAL
8/14/08 (Original Publication)
(Updated 7/8/14)

Advertisement

Table of Contents
loading

Related Manuals for Taylor 161

Summary of Contents for Taylor 161

  • Page 1 OPERATOR'S MANUAL Model 161 Soft Serve Freezer Original Operating Instructions 055155-M 8/14/08 (Original Publication) (Updated 7/8/14)
  • Page 2 Complete this page for quick reference when service is required: Taylor Distributor: Address: Phone: Service: Parts: Date of Installation: Information found on the data label: Model Number: Serial Number: Electrical Specs: Voltage Cycle Phase Maximum Fuse Size: Minimum Wire Ampacity: E 2008 Carrier Commercial Refrigeration, Inc.

  • Page 3: Table Of Contents

    ....... Model 161 ............
  • Page 4 Statutory Damages of up to $250,000 (17 USC 504) for infringement, and may result in further civil and criminal penalties. All rights reserved. Taylor Company a division of Carrier Commercial Refrigeration, Inc. 750 N. Blackhawk Blvd. Rockton, IL 61072 Model 161 Table of Contents...

  • Page 5: To The Installer

    DO NOT obstruct air intake and discharge openings: authorized Taylor Service Technician. The Model 161 requires 6” (152 mm) on both sides, and 0” at the rear. Install the skirt provided on the right This unit has many sharp edges that can side of the unit.

  • Page 6: Water Connections (Water Cooled Units Only)

    Please contact your local authorities. If the supply cord is damaged, it must be replaced by the manufacturer, its service FOLLOW YOUR LOCAL ELECTRICAL CODES! agent, or similarly qualified person, in order to avoid a hazard. 130319 To the Installer Model 161...

  • Page 7: Electrical Hook- Up Installation

    If burns are severe, apply ice packs and contact a physician immediately. Beater rotation must be clockwise as viewed Taylor reminds technicians to be cautious of looking into the freezing cylinder. government laws regarding refrigerant recovery, recycling, and reclaiming systems.

  • Page 8: To The Operator

    Taylor Distributor. this fact known to any technician he employs. Note: Your Taylor warranty is valid only if the parts are authorized Taylor parts, purchased from the local It should also be noted that Taylor does not warrant the authorized Taylor Distributor, and only if all required refrigerant used in its equipment.

  • Page 9: Safety

    We, at Taylor Company, are concerned about the safety of the operator when he or she comes in contact with the freezer and its parts. Taylor has gone to extreme efforts to design and manufacture built- in DO NOT operate the freezer unless it is safety features to protect both you and the service properly grounded.
  • Page 10 78 dB(A) when measured at a distance of 1.0 experience with the appliance, in particular as far as meter from the surface of the machine and at a height safety and hygiene are concerned. of 1.6 meters from the floor. 130319 Safety Model 161...

  • Page 11: Operator Parts Identification

    X58490 PANEL -SIDE LEFT 058491 GASKET-BASE PAN 055815 GASKET-HOPPER COVER 037042 TRAY-DRIP 16-7/8L X 4-5/16 020157-SP COVER A.-HOPPER X37963-SER SHIELD-SPLASH 022765 KNOB-MIX COVER 025429 PANEL-LOWER FRONT 058493 TUBE-FEED 030797 PANEL A.-FRONT *161* X58488 PANEL-REAR 058492 Model 161 Operator Parts Identification...

  • Page 12: Beater Door Assembly

    *SMALL H-RING* VALVE-DRAW-CENTER 031164 DOOR A.-3SPT 1.5QT VALOX X56906SER1 O-RING-2-3/4 OD X .139W 019998 PIN A.-PIVOT *168-SHORT* X38539 BEARING-FRONT 023262 O-RING-5/16 OD X .070W 016272 BEATER A.-*150 X24689 HANDLE-DRAW VALVE 030564 SEAL-U-CUP 080534 NUT-STUD 056802 140409 Operator Parts Identification Model 161...

  • Page 13: Accessories

    SEE NOTE *Not Shown - Note: A sample container of sanitizer is sent with the unit. For reorders, order Kay-5 part no. 041082 (200 packs) or Stera Sheen part no. 055492 (100 2 oz. packs). 110727 Model 161 Operator Parts Identification...

  • Page 14: Important: To The Operator

    = WASH To better communicate in the International arena, the words on many of our operator switches and keys have = AUTO symbols to indicate their functions. Your Taylor equipment is designed with these International = MIX LOW symbols. Important: To the Operator...

  • Page 15: Standby Key

    This will prevent mix from entering the freezing cylinder. Feed Tube Position During Standby Operation: Figure 6 IMPORTANT: The STANDBY mode must not be used in lieu of daily disassembly, cleaning, Figure 5 and sanitizing. 130703 Model 161 Important: To the Operator...

  • Page 16: Reset Button

    Turn the power switch to the ON position. Press the WASH key and observe the freezer’s performance. If the beater motor is turning properly, press the WASH key to cancel the cycle. Press the AUTO key on both Figure 8 130703 Important: To the Operator Model 161...
  • Page 17 Feed Tube Position During Standby Operation: Figure 9 130703 Model 161 Important: To the Operator...

  • Page 18: Operating Procedures

    Section 6 Operating Procedures Assembly The Model 161 is a soft serve counter model with a three spout door. Two individual flavors are available Note: When lubricating parts, use an approved food from the end spouts, and an equal combination of both is dispensed through the center spout to create a twist grade lubricant (example: Taylor Lube).

  • Page 19: Model

    With both hands, hold the sides of the freezer door and insert the baffle rods into the center of the beater assemblies. The white guide bearings must fit securely in the holes of the drive shafts. Figure 16 120501 Model 161 Operating Procedures...
  • Page 20 Slide the long pivot from the bottom until the slot in the draw valves comes pin through the far left and middle draw handles. into view. Figure 18 Figure 20 Operating Procedures Model 161...

  • Page 21: Sanitizing

    Install the front drip tray and splash shield under the SPECIFICATIONS. freezer door. Step 2 Pour one gallon (3.8 liters) of sanitizing solution into the hopper and allow it to flow into the freezing cylinder. Figure 22 Figure 24 Model 161 Operating Procedures...
  • Page 22 With sanitized hands, stand the feed tube in the corner of the mix hopper. Figure 26 Step 4 Place the power switch in the ON position. Figure 29 Repeat Steps 1 through 7 for the other side of the Figure 27 machine. Operating Procedures Model 161...

  • Page 23: Priming

    Closing Procedure it to flow into the freezing cylinder. This will force out any remaining sanitizing solution. When full strength To disassemble the Model 161, the following items will mix is flowing from the door spouts, close the draw be needed: valves.

  • Page 24: Rinsing

    Press the WASH key to cancel. Step 2 Repeat Steps 1 through 5 for the other side of the Remove the cup seals from the drive shafts of the machine. beater assemblies. Operating Procedures Model 161...
  • Page 25 Step 5 Return to the machine with a small amount of cleaning solution. With the black bristle brush, brush clean the rear shell bearings at the back of the freezing cylinders. Model 161 Operating Procedures...

  • Page 26: Section 7 Important: Operator Checklist

    Be sure to have a generous j 4. Follow all lubricating procedures as outlined in amount of cleaning solution on the brush. “Assembly”. Important: Operator Checklist Model 161...

  • Page 27: Winter Storage

    Condensers must be cleaned monthly with a soft brush. Never Your local Taylor distributor can perform this service for use screwdrivers or other metal probes to clean you. between the fins. Failure to comply may result in electrocution.

  • Page 28: Section 8 Troubleshooting Guide

    The beater motor d. Reset the freezer. overloaded, causing a loss of power to the power switch. 3. The product is too stiff. a. The control is set too cold. a. Contact service - - - technician. Troubleshooting Guide Model 161...

  • Page 29: Probable Cause

    Contact service - - - technician. worn. c. Incorrect lubricant was c. Use food grade lubricant (example: Taylor Lube). used. d. Inadequate lubrication of d. Lubricate the beater drive shaft properly. beater drive shaft. 7. The draw valve is leaking.
  • Page 30 10. Mix from one freezing a. The center draw valve a. Lubricate properly and 15 / 27 replace seal every 3 cylinder bleeds over to the seal is worn, or is months. second cylinder. improperly lubricated. Troubleshooting Guide Model 161...

  • Page 31: Section 9 Parts Replacement Schedule

    Necessary Double Ended Brush Inspect & Replace Minimum if Necessary White Bristle Brush, 1” x 2” Inspect & Replace Minimum if Necessary White Bristle Brush, 3” x 7” Inspect & Replace Minimum if Necessary 120501 Model 161 Parts Replacement Schedule...

  • Page 32: Section 10 Limited Warranty On Equipment

    Taylor, through an authorized Taylor distributor or service agency, will provide a new or re- manufactured part, at Taylor’s option, to replace the failed defective part at no charge for the part. Except as otherwise stated herein, these are Taylor’s exclusive obligations under this limited warranty for a Product failure.
  • Page 33 LEGAL REMEDIES The owner must notify Taylor in writing, by certified or registered letter to the following address, of any defect or complaint with the Product, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Product under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.

  • Page 34: Section 11 Limited Warranty On Parts

    Taylor warrants the Parts against failure due to defect in materials or workmanship under normal use and service as follows. All warranty periods begin on the date of original installation of the Part in the Taylor unit. If a Part fails due to defect during the applicable warranty period, Taylor, through an authorized Taylor distributor or service agency, will provide a new or re- manufactured Part, at Taylor’s option, to replace the failed defective Part at no...
  • Page 35 Parts or the units in which they are installed repaired or altered in any way so as, in the judgment of Taylor, to adversely affect performance, or normal wear or deterioration.
  • Page 36 LEGAL REMEDIES The owner must notify Taylor in writing, by certified or registered letter to the following address, of any defect or complaint with the Part, stating the defect or complaint and a specific request for repair, replacement, or other correction of the Part under warranty, mailed at least thirty (30) days before pursuing any legal rights or remedies.

  • Page 37: Section 12 Parts List

    Section 12 Parts List + Available Separately 140409 Model 161 Parts List...
  • Page 38 + Available Separately Parts List Model 161...
  • Page 39 + Available Separately Model 161 Parts List...
  • Page 40 + Available Separately Parts List Model 161...
  • Page 41 + Available Separately Model 161 Parts List...
  • Page 42 + Available Separately Parts List Model 161...
  • Page 43 + Available Separately Model 161 Parts List...
  • Page 44 + Available Separately Parts List Model 161...
  • Page 45 + Available Separately Model 161 Parts List...
  • Page 46 RED/WHT POWER BOARD BLK/YEL DOOR INTERLOCK RELAY BRN/WHT DOOR INTERLOCK RELAY BLU/WHT RIGHT BEATER OVERLOAD SWITCH BLK CORD BRN/WHT N. O. DOOR INTERLOCK SWITCH HPCO LEFT BEATER OVERLOAD SWITCH Taylor Company Model 161 069262-27S 07/14 2014 Carrier Commercial Refrigeration, Inc.
  • Page 47 RED/WHT POWER BOARD BLK/YEL DOOR INTERLOCK RELAY BRN/WHT DOOR INTERLOCK RELAY BLU/WHT RIGHT BEATER OVERLOAD SWITCH BLK CORD BRN/WHT N. O. DOOR INTERLOCK SWITCH HPCO LEFT BEATER OVERLOAD SWITCH Taylor Company Model 161 069262-40S 07/14 2014 Carrier Commercial Refrigeration, Inc.
