  • Page 1: Hardware Installation Guide

    Extreme Networks Consolidated XOS Hardware Installation Guide Extreme Networks, Inc. 3585 Monroe Street Santa Clara, California 95051 (408) 579-2800 (888) 257-3000 http://www.extremenetworks.com Published: December, 2004 Part number: 100172-00 Rev. 01...
  • Page 2 Purple Extreme Solution Partners Logo, ServiceWatch, Summit, the Summit7i Logo, and the Color Purple, among others, are trademarks or registered trademarks of Extreme Networks, Inc. or its subsidiaries in the United States and other countries. Other names and marks may be the property of their respective owners.

  • Page 3: Table Of Contents

    LAN Systems ...29 PoE Devices ...30 Power Supply Requirements...30 AC Power Cable Requirements...30 Replacing the Power Cable...31 Uninterruptible Power Supply Requirements ...31 UPS Features...31 Selecting a UPS ...32 Calculating Amperage Requirements ...32 Extreme Networks Consolidated XOS Hardware Installation Guide ...16...
  • Page 4 Supported External Compact Flash Memory Cards ...46 Installing an External Memory Card...47 Removing an External Memory Card ...48 Chapter 4: Extreme Networks 700/1200 W AC Power Supply Units ... 49 Overview ...49 Pre-Installation Requirements ...49 Installing the 700/1200 W AC PSU ...50 Removing the 700/1200 W AC PSU ...50...
  • Page 5 Chapter 9: Aspen 8810 Chassis ... 107 Aspen 8810 Chassis Architecture ...107 Aspen 8810 Chassis Front View...107 Aspen 8810 Chassis Rear View ...108 Uncrating and Unpacking the Aspen 8810 Chassis ...109 Extreme Networks Consolidated XOS Hardware Installation Guide Table of Contents...
  • Page 6 Installing an Aspen 8810 Spare PSU/Fan Controller ...142 Chapter 12: Aspen 8810 AC Power Cord Retaining Bracket ... 143 Overview ...143 Pre-Installation Requirements ...143 Installing the Aspen 8810 AC Power Cord Retaining Bracket...144 Extreme Networks Consolidated XOS Hardware Installation Guide...
  • Page 7 Power Cable - Power Supply Cords ...153 Argentina...153 Australia...153 Denmark ...153 International ...153 Japan...153 North America ...153 Switzerland...154 United Kingdom...154 Fiber Optic Ports - Optical Safety...154 Appendix B: Technical Specifications ... 155 Index ... 159 Extreme Networks Consolidated XOS Hardware Installation Guide Table of Contents...
  • Page 8 Table of Contents Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 9: Preface

    Extreme Networks switch. NOTE If the information in the release notes that shipped with your Extreme Networks switch differs from the information in this guide, follow the release notes. Extreme Networks Consolidated XOS Hardware Installation Guide thoroughly before installing any Extreme Networks switch.

  • Page 10: Conventions

    (+). Example: Press [Ctrl]+[Alt]+[Del]. Words in italicized type Italics emphasize a point of information or denote new terms at the place where they are defined in the text. Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 11: Related Publications

    ExtremeWare XOS Concepts Guide ExtremeWare XOS Command Reference Guide ExtremeWare XOS Release Notes Documentation for Extreme Networks products is available from the Extreme Networks website at the following location: http://www.extremenetworks.com/services/documentation You can select and download the following Extreme Networks documentation from the Documentation...
  • Page 12 Preface Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 13: Part 1: Site Preparation

    Site Preparation...

  • Page 15: Chapter 1: Site Preparation

    LANs. Installation, maintenance, and removal of a switch, chassis, or its components must be done by qualified service personnel only. Qualified service personnel have had appropriate technical training and experience that is necessary to be aware of the hazards to which they are exposed when performing a task and of measures to minimize the danger to themselves or other people.

  • Page 16: Planning Your Site

    Step 2: Evaluating and Meeting Cable Requirements After examining your physical site and ensuring all environment requirements are met, evaluate and compare your existing cable plant with the requirements of the Extreme Networks equipment to determine if you need to install new cables (or cabling).

  • Page 17: Operating Environment Requirements

    United States according to the Communications Act of 1934. The FCC regulates all U.S. telephone and cable systems. The address is FCC; 445 12th Street S.W.; Washington, D.C. 20554 USA. www.fcc.gov Extreme Networks Consolidated XOS Hardware Installation Guide Meeting Site Requirements...

  • Page 18: Wiring Closet Considerations

    Temperature Extreme Networks equipment generates a significant amount of heat. It is essential that you provide a temperature-controlled environment for both performance and safety. Install the equipment only in a temperature- and humidity-controlled indoor area that is free of airborne materials that can conduct electricity.

  • Page 19: Spacing Requirements

    To ensure proper airflow through an Extreme Networks switch, refer to the following recommendations when you are installing your switch: Extreme Networks switches require 3 inches (7.62 cm) around both the front and rear of the chassis for proper airflow. Extreme Networks recommends 5 inches (12.7 cm) clearance.
  • Page 20 Figure 1: Airflow through the BlackDiamond 10K system chassis Airflow through chassis Figure 2: Airflow through the Aspen 8810 chassis Airflow at power supply level Extreme Networks Consolidated XOS Hardware Installation Guide Airflow through power supplies EX_010 Airflow through fan tray ASP045...

  • Page 21: Electrostatic Discharge (Esd)

    Operating humidity should be kept between 50 to 70% relative humidity non-condensing during typical operation and 10% to 95% relative humidity (non-condensing) for short intervals to maximize equipment life. Figure 3: Ensure that you use an ESD-preventive wrist strap when handling switch components ESD ground connection...

  • Page 22: Mechanical Recommendations For The Rack

    This will insure good grounding between the chassis, rack, and earth ground. NOTE Because building codes vary worldwide, Extreme Networks strongly recommends that you consult an electrical contractor to ensure proper equipment grounding for your specific installation. Space Requirements for the Rack Provide enough space in front of and behind the switch so that you can service it easily.

  • Page 23: Securing The Rack

    WARNING! The chassis does not have a switch for turning the unit on and off. Power to the chassis is disconnected by removing the wall plug from the electrical outlet. Ensure that all plugs and electrical outlets are easily accessible.

  • Page 24: Evaluating And Meeting Cable Requirements

    Assign a unique block of sequential numbers to the group of cables that run between each pair of wiring closets. Assign a unique identification number to each distribution rack. Identify all wiring closets by labeling the front panel of your Extreme Networks equipment and other hardware. Keep accurate and current cable identification records.

  • Page 25: Installing Cable

    Unshielded twisted pair (UTP) cable can build up ESD charges when being pulled into a new installation. Before connecting any category 5 UTP cable to the switch, discharge ESD from the cable by plugging the RJ45 into a LAN Static Discharge device or use an equivalent method.

  • Page 26: Fiber Optic Cable

    Use care in dressing the optical fiber cables: provide satisfactory strain relief to support the cable and maintain an adequate bend radius at all cable turns, particularly where the cable connects to the I/O module. Extreme Networks Consolidated XOS Hardware Installation Guide Cable managers supporting...

  • Page 27: Cable Distances

    Category 5 and higher UTP cable 10BASE-T Category 3 and higher UTP cable Proprietary to Extreme Networks. Connections between two Extreme Networks 1000BASE-LX interfaces that use 10/125 µm single-mode fiber can use a maximum distance of 10,000 meters. Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 28: Rj-45 Connector Jackets

    Routing UTP cable near air conditioner units Routing UTP cable near electrical transformers In areas or applications where these situations cannot be avoided, use fiber optic cabling or shielded twisted pair cabling (STP). Extreme Networks Consolidated XOS Hardware Installation Guide Best 0.1" = 1mm actual Better 39.37% : 254%...

  • Page 29: Making Network Interface Cable Connections

    NOTE Because harmonics can appear on the neutral line of a typical three-phase power circuit, Extreme Networks recommends using a harmonics meter in new installations. Making Network Interface Cable Connections Use the appropriate type of cable to connect the ports of your switch to another switch or router.

  • Page 30: Poe Devices

    If a power source fails, it will affect only the switch power supply to which it is connected. If all switch power supplies are connected to a single power source, the entire switch is vulnerable to a power source failure.

  • Page 31: Replacing The Power Cable

    An uninterruptible power supply (UPS) is a device that sits between a power supply (such as a wall outlet) and a device (such as a switch) to prevent outages, sags, surges, and bad harmonics from adversely affecting the performance of the device.

  • Page 32: Selecting A Ups

    UPS Transition Time Transition time is the time that is necessary for the UPS to transfer from utility power to full-load battery power. For Extreme Networks products, a transition time of less than 20 milliseconds is required for optimum performance.

  • Page 33: Chapter 2: Initial Management Access

    Stop bit—1 Parity—None Flow control—XON/XOFF The terminal or PC with terminal-emulation software that you connect to an Extreme Networks switch must be configured with these settings. This procedure is described in the documentation supplied with the terminal. Appropriate cables are available from your local supplier, or you can make your own. To ensure the electromagnetic compatibility of the unit, use only shielded serial cables.
  • Page 34 9-pin to 9-pin (PC-AT) null-modem serial cable. Figure 9: PC-AT serial null-modem cable pinouts Switch Cable connector: 9-pin female Screen Shell Ground Extreme Networks Consolidated XOS Hardware Installation Guide PC/Terminal Cable connector: 25-pin male/female Screen Ground 25pin PC-AT Serial Port...

  • Page 35: Logging In For The First Time

    Logging In for the First Time After your switch has completed all power on self-tests (POSTs), it is operational. When the switch is operational, you can log in and configure an IP address for the default VLAN (named default). To manually configure the IP settings: 1 Connect a terminal or PC with terminal-emulation software to the MSM.
  • Page 36 Initial Management Access Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 37: Part 2: Common Characteristics

    Common Characteristics...

  • Page 39: Chapter 3: Overview

    Most ports on an Extreme Networks switch auto-negotiate operation. Gigabit Ethernet fiber ports and 10 Gigabit Ethernet ports operate only in full-duplex mode in accordance with technical standards.

  • Page 40: Management Ports

    VLAN and attempt to route traffic through it. Extreme Networks does not recommend that you use the management port to route traffic to any front panel port on the switch. The management port is designed for switch management purposes.
  • Page 41 Total optical system budget for the SX mini-GBIC is 11.5 dB. Extreme Networks recommends that 3 dB of the total budget be reserved for losses induced by cable splices/connectors and operating margin. While 8.5 dB remains available for cable-induced attenuation, the 1000BASE-SX standard specifies supported distances of 275 meters over 62.5 micron multimode fiber and 550 meters over 50 micron...

  • Page 42: Preparing To Install Or Replace A Mini-Gbic

    Extreme Networks, into the mini-GBIC port. If you install a mini-GBIC not certified by Extreme Networks into a switch and insert a cable to bring up the link, the port status LED remains “off” and an error specifying the use of a non-Extreme Networks-certified mini-GBIC is sent to the syslog.

  • Page 43: Installing And Removing A Mini-Gbic

    Remove the LC fiber-optic connector from the mini-GBIC prior to removing the mini-GBIC from the switch. If you see an amber blinking mini-GBIC port status LED, the mini-GBIC installed in your switch or module is not approved, supported, or certified by Extreme Networks. To correct this problem, install an Extreme Networks-certified mini-GBIC.

  • Page 44: Installing And Removing A Xenpak Module

    XENPAK module from your Extreme Networks switch without powering off the system. The module is shown in Figure 11: XENPAK module The XENPAK module is a Class 1 laser device. Use only Extreme-approved devices on all Extreme Networks switches. CAUTION The XENPAK module can emit invisible laser radiation.
  • Page 45 3 Place the dust covers back into the XENPAK module connectors. 4 Place the XENPAK module immediately into an antistatic container to protect it from ESD damage and dust. Extreme Networks Consolidated XOS Hardware Installation Guide Installing and Removing a XENPAK Module...

  • Page 46: External Compact Flash Memory Card

    You can purchase the 256 MB industrial grade compact flash card directly from Extreme Networks, or you can purchase any of the industrial grade compact flash cards listed in flash cards have been tested and are approved by Extreme Networks for use as an external compact flash memory card installed in the MSM.

  • Page 47: Installing An External Memory Card

    3 Grasp the memory card between your thumb and forefinger. For the BlackDiamond 10K switch, the side with the ridge should face to the left of the chassis. For the Aspen switch, the side with the ridge should face towards the bottom of the chassis.

  • Page 48: Removing An External Memory Card

    The card releases to an intermediate position; the card remains partially inserted but is no longer seated in the slot. 4 Using your thumb and forefinger, remove the card completely and place it in a safe location. Extreme Networks Consolidated XOS Hardware Installation Guide eject...

  • Page 49: Chapter 4: Extreme Networks 700/1200 W Ac Power Supply Units

    ESD-preventive wrist strap # 2 Phillips screwdriver 700/1200 W AC PSU(s) BlackDiamond 10K or Aspen 8810 chassis Power supply cord (either 110 V AC or 220 V AC) or applicable to country of use. Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 50: Installing The 700/1200 W Ac Psu

    Extreme Networks 700/1200 W AC Power Supply Units Installing the 700/1200 W AC PSU Follow these steps to ensure proper installation of the 700/1200 W AC PSU: 1 Attach an ESD-preventive wrist strap, that is provided, to your wrist and connect the metal end of the ESD-preventive wrist strap to the ground receptacle, which is located on the top-left corner of the chassis front panel.

  • Page 51: Specifications

    700/1200 W AC PSU(s). The BlackDiamond 10K series modules require two to four times the power of the Aspen modules. Extreme Networks recommends the 220 V AC high- line power range for 700/1200 W AC PSU(s) used in conjunction with BlackDiamond 10K series systems.

  • Page 52: Front Panel

    Extreme Networks 700/1200 W AC Power Supply Units Front Panel The front panel of the 700/1200 W AC PSU provides status LEDs. on the front panel. Table 11: 700/1200 W AC PSU front panel LED behavior Color Power Blinking Green...
  • Page 53 16. The 12V standby is used only to power the system logic circuitry. The 48V is used to power the MSM(S), I/O modules, and fan tray. Figure 16: Input/Output connectors on back of the 700/1200 W AC PSU Extreme Networks Consolidated XOS Hardware Installation Guide Specifications EX_011...

  • Page 54: Power Supply Controller Overview

    Extreme Networks 700/1200 W AC Power Supply Units Power Supply Controller Overview The BlackDiamond 10K series switch includes two power supply controllers, located in the back of the chassis, that collect data from the installed power supplies and report the results to the MSM modules via an I C interface.

  • Page 55: Installing The Power Supply Controllers

    The MGMT LED flashes until the switch successfully passes the POST. If the switch passes the POST, the MGMT LED blinks at a slow rate (one blink per second). If the switch fails the POST, the MGMT LED shows a solid yellow light.

  • Page 56: Power Supply Cords

    DC output power of 1200 W. All power supply cords provided by Extreme Networks are designed for use in the United States and Canada only. Power supply cords for use outside of United States and Canada are typically provided by a third party distribution center and must meet the following requirements: Power supply cords must be agency certified for country of use.

  • Page 57: Part 3: Blackdiamond 10K Series Switch

    BlackDiamond 10K Series Switch...

  • Page 59: Chapter 5: Blackdiamond 10K System Chassis

    Up to six power supplies (accessed from the front of the unit) Two fan trays (accessed from the back of the unit) One ESD-preventive wrist strap connector The BlackDiamond 10K series switch can support up to the following number of ports and types of port configurations: 32 switched Gigabit Ethernet ports...
  • Page 60 BlackDiamond 10K System Chassis Figure 18 shows the BlackDiamond 10K series switch installed with two MSM-1 modules and eight optional I/O modules. Figure 18: Front view of the BlackDiamond 10K series switch ESD wrist strap connector Power supplies behind grill...

  • Page 61: Blackdiamond 10K System Chassis Rear View

    The rear view of the BlackDiamond 10K series switch provides: Access to the fan units The chassis serial number The Ethernet MAC address of the switch Symbols of safety certification Access to power supply controllers Extreme Networks Consolidated XOS Hardware Installation Guide BlackDiamond 10K System Chassis Architecture EX_007...

  • Page 62: Power Socket

    The BlackDiamond 10K series switch is shipped with a pre-installed fan tray. For your safety, because of the increased weight of the chassis after components are installed and to prevent damage to the equipment, Extreme Networks strongly recommends that you install the I/O modules after you mount the chassis in a rack.
  • Page 63 Each indicator has two color-coded states, or modes: a good, white state, and a warning, red state. A smooth shipping procedure should leave all four indicators in good, white states. tilt watch and shock watch indicators on both conditions. Extreme Networks Consolidated XOS Hardware Installation Guide Installing the Chassis Shock watch...

  • Page 64: Removing The Accessories Box And Preparing The Rack

    If either the tilt watch or shock watch indicator is showing a red, warning condition, do not proceed with unpacking. Contact your shipping company or Extreme Networks and speak to a representative before continuing. Removing the Accessories Box and Preparing the Rack Before you begin unpacking the chassis from the carton, remove the accessories box from the top of the carton and install the helper bracket into the rack.
  • Page 65 5 Mount the helper bracket in the lowest available position in the rack using four appropriate screws (not provided), as shown in Figure Figure 23: Helper bracket for mounting the BlackDiamond 10K series switch BDbrackt Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 66: Unpacking The Chassis From The Carton

    You will need at least 10 feet of overhead clearance to remove the shipping carton from the chassis. To remove the carton from the chassis: 1 Remove the four v-boards from the corners of the crate, as shown in Figure Figure 24: Location of v-boards Accessory box EX_093 Extreme Networks Consolidated XOS Hardware Installation Guide...
  • Page 67 Pull the prongs toward you until the clip lock is released from the carton. d Repeat steps 2a through 2c to release each of the remaining three clip locks. Figure 26: Removing the clip locks Clip lock Extreme Networks Consolidated XOS Hardware Installation Guide Shock watch Figure 26) adjacent to the two vertical...
  • Page 68 Save the packaging, including the carton, bolts, and attached washers for future use, in case you need to return the BlackDiamond 10K series switch. 5 Have a minimum of two people grab both handles on each side of the switch and lift the switch from the pallet, as shown in...
  • Page 69 7 While holding the empty chassis, secure the chassis to the rack, as shown in Figure 29: The BlackDiamond 10K series switch chassis requires eight screws to be securely mounted in a rack 8 After you secure the chassis, remove the helper bracket.

  • Page 70: Mid-Mount Rack Installation

    2 Remove the chassis from the box, following the uncrating procedure described in Chassis from the Carton” on page 3 Secure a mid-mount kit flange to each side of the BlackDiamond 10K series switch chassis using the provided screws. Ensure you are using the appropriate flange for the left and right side, as shown in...

  • Page 71: Grounding The Blackdiamond 10K Series Switch

    4 Attach the ground lug, lock washers, and nuts (in that order) to the grounding studs on the rear of the chassis. Tighten the nuts to 125 inch/pounds of torque. Extreme Networks Consolidated XOS Hardware Installation Guide Installing the Chassis...

  • Page 72: Installing The Blackdiamond Cable Manager

    1 Press down on the latches at the top of the cover plate to remove the cover plate. Removing the cover plate exposes the six screws holding the cable guides onto the mounting base, as shown in Figure Extreme Networks Consolidated XOS Hardware Installation Guide Cable guides Three screw attachments each side...
  • Page 73 2 Remove the six screws that secure the cable guides to the mounting base. 3 Place the mounting base above the BlackDiamond 10K series switch chassis in the rack. 4 Use six screws (not supplied) to mount the base onto the rack, as shown in...
  • Page 74 Figure 35: Securing the cable guides onto the mounted cable manager base 8 Using the cable guides and cable clips (provided), slide the cables through the clips, holders, and channel to manage the cables installed on your BlackDiamond 10K series switch chassis, as shown in Figure...
  • Page 75 9 Insert the cover plate into the hinge tabs of the cable manager base and press firmly until the latches lock, as shown in Figure Figure 37: Cable manager cover plate Latches at top of closed cover Hinge tabs fit into cable manager base Top view of open/removed cover EX_078 Extreme Networks Consolidated XOS Hardware Installation Guide...
  • Page 76 BlackDiamond 10K System Chassis Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 77: Chapter 6: Blackdiamond 10K Series Management Switch Module

    MSM Activity MSM LEDs The MSM holds both the control plane and the switch fabric for the switch. One MSM is required for switch operation; adding an additional MSM increases reliability and throughput. Each MSM has two CPUs for protocol processing and network management. For full redundancy, you can install up to two MSMs in the BlackDiamond 10K series switch.
  • Page 78 The MSM consists of a printed circuit board mounted on a metal panel that acts as the insertion vehicle in a BlackDiamond 10K series switch. The module carrier also includes ejector/injector levers and captive retaining screws at each end of the module front panel.

  • Page 79: Msm Activity

    MSM experiences a soft reset and then becomes the primary MSM. For example, if you have a BlackDiamond 10K series switch with a primary MSM in slot A and a backup MSM module in slot B, and you remove the primary MSM from slot A, the backup in slot B becomes the primary.

  • Page 80: Installing And Removing Msms

    To reset the critical software error LED (amber ERR LED), use the clear log static command and reboot the switch. If you continue to have critical software errors, or the ERR LED is amber after the clear log static command and a switch reboot, contact Extreme Networks Customer Support.
  • Page 81 Figure 39: MSM prior to insertion in a BlackDiamond 10K system chassis a Slide the MSM into the appropriate lettered slot of the chassis, until it makes contact with the backplane. Extreme Networks Consolidated XOS Hardware Installation Guide Installing and Removing MSMs Figure...

  • Page 82: Verifying The Msm Installation

    Depending on the size and complexity of your network, you should install and configure a backup MSM when network disruption will be minimal. You may need to reboot your switch after you use the synchronize command. 10 Store the module packaging for future use.

  • Page 83: Removing An Msm

    1 Attach an ESD-preventive wrist strap to your wrist and connect the metal end of the ESD-preventive wrist strap to the ground receptacle that is located on the top-left corner of the switch front panel. 2 To loosen the module, unscrew the screws with a #1 Phillips screwdriver.
  • Page 84 BlackDiamond 10K Series Management Switch Module Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 85: Chapter 7: Blackdiamond 10K Series I/O Modules

    No configuration information is stored on the I/O modules; all configuration information is stored on the MSM(s). When the BlackDiamond 10K series switch is powered on, the software generates a default configuration for any slots that contain I/O modules. The default configuration allows the I/O module ports to participate in the VLAN named default.

  • Page 86: G60T Module

    The G60T module has the following LEDs: Module status Port status Port speed For information about the LEDs and their activity on the G60T module, see page Extreme Networks Consolidated XOS Hardware Installation Guide Module status LEDs RJ-45 connector ports EX_004...

  • Page 87: G60X Module

    The default configuration of the G60X module is as follows. All ports: Are added to the default VLAN as untagged Inherit the properties of the default VLAN (for example, protocol type and VLANid) Extreme Networks Consolidated XOS Hardware Installation Guide Module status LEDs Mini-GBIC...

  • Page 88: Mini-Gbic Ports

    The G60X module has the following LEDs: Module status Port status For information about the LEDs and their activity on the G60X module, see page Extreme Networks Consolidated XOS Hardware Installation Guide Maximum Distance (meters) 10,000 70,000 “Mini-GBIC Type and Hardware/...

  • Page 89: G20X Module

    The default configuration of the G20X module is as follows. All ports: Are added to the default VLAN as untagged Inherit the properties of the default VLAN (for example, protocol type and VLANid) Extreme Networks Consolidated XOS Hardware Installation Guide Module status LEDs Mini-GBIC ports Mini-GBIC ports...

  • Page 90: Mini-Gbic Ports

    The G20X module has the following LEDs: Module status Port status For information about the LEDs and their activity on the G20X module, see page Extreme Networks Consolidated XOS Hardware Installation Guide Maximum Distance (meters) 10,000 70,000 “Mini-GBIC Type and Hardware/...

  • Page 91: 10G6X Module

    The 10G6X module has the following LEDs: Module status Port status For information about the LEDs and their activity on the 10G6X module, see page Extreme Networks Consolidated XOS Hardware Installation Guide Module status LEDs 10 Gbs ports EX_006 I/O Modules...

  • Page 92: 10G2X Module

    The 10G2X module has the following LEDs: Module status Port status For information about the LEDs and their activity on the 10G2X module, see page Extreme Networks Consolidated XOS Hardware Installation Guide Module status LEDs 10 Gbs ports ASP035 “I/O Module LEDs” on...

  • Page 93: I/O Module Leds

    Link down Installing I/O Modules The BlackDiamond 10K series switch comes with eight blank front panels already installed. Use a blank front panel to fill slots not occupied by I/O modules or switch management modules. For information about how to install a blank front panel, see You can insert a BlackDiamond 10K series I/O module at any time, without causing disruption of network services.
  • Page 94 ESD surface. CAUTION To prevent ESD damage, handle the module by the metal panel edges only. Never touch the components on the PCB or pins on any of the connectors. Extreme Networks Consolidated XOS Hardware Installation Guide...
  • Page 95 To install additional I/O modules, repeat steps 3 through 9. NOTE Leave the ESD-preventive wrist strap permanently connected to the chassis so that it is always available when you need to handle ESD-sensitive components. Extreme Networks Consolidated XOS Hardware Installation Guide Figure Injector/ Open...

  • Page 96: Verifying The I/O Module Installation

    For more information about slot status information, see the ExtremeWare XOS Concepts Guide and the ExtremeWare XOS Command Reference Guide. Extreme Networks Consolidated XOS Hardware Installation Guide command to show slot <slot number>...

  • Page 97: Removing I/O Modules

    To remove additional I/O modules, repeat steps 1 through 4. NOTE Leave the ESD-preventive wrist strap permanently connected to the chassis so that it is always available when you need to touch ESD-sensitive components. Extreme Networks Consolidated XOS Hardware Installation Guide Removing I/O Modules Figure on page...

  • Page 98: Installing A Blank Front Panel

    3 Slide the blank front panel into the appropriate slot in the chassis. Ensure that the blank front panel is vertical with the blank front panel number at the top, as shown Figure Extreme Networks Consolidated XOS Hardware Installation Guide...
  • Page 99 Tighten the screws of this blank front panel before inserting additional modules or blank front panels. Otherwise, you might unseat modules or blank front panels that you have not secured. Extreme Networks Consolidated XOS Hardware Installation Guide Installing a Blank Front Panel...
  • Page 100 BlackDiamond 10K Series I/O Modules Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 101: Chapter 8: Blackdiamond 10K Series Fan Tray And Filter

    Do not cover or obstruct the fan ventilation holes at the rear of the unit. Doing so can result in overheating and possible damage to the BlackDiamond 10K series switch. Thermal sensors will shut down the BlackDiamond 10K series switch if the internal temperature exceeds 60 degrees Celsius.

  • Page 102: Removing The Blackdiamond 10K Series Fan Tray

    3 Use the finger grips to pull the fan tray out of the chassis approximately 1 inch (2.54 cm); this step disconnects the power and causes the fans to stop rotating. Figure 47: BlackDiamond 10K series fan tray Fan tray Extreme Networks Consolidated XOS Hardware Installation Guide of this guide. EX_012...

  • Page 103: Installing The Blackdiamond 10K Series Fan Tray

    Figure 9. 2 Check the connectors on the switch fan tray for dust and packing materials. 3 To support the fan tray, place one hand under the fan tray; use the other hand to guide the fan tray into the slot.

  • Page 104: Replacing The Blackdiamond 10K Series Filter

    This section describes how to replace the BlackDiamond 10K series filter. NOTE Extreme Networks recommends that you visually inspect the air filter at least once every three months. Replace or clean as necessary. To replace the filter in the BlackDiamond 10K series switch: 1 Remove the bezel from the front of the chassis using a #2 Phillips screwdriver.

  • Page 105: Part 4: Aspen Switch

    Aspen Switch...

  • Page 107: Chapter 9: Aspen 8810 Chassis

    Up to six power supplies (accessed from the front of the unit) One fan tray (accessed from the front right of the unit) One ESD-preventive wrist strap connector When two MSMs are installed, the chassis can support up to 48 Gig per slot. Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 108: Aspen 8810 Chassis Rear View

    Aspen 8810 Chassis Rear View Figure 50 Shows the rear view of the Aspen 8810 chassis. Figure 50: Rear view of the Aspen 8810 chassis Grounding lug Extreme Networks Consolidated XOS Hardware Installation Guide Fan tray I/O module slots I/O module slots ASP042...

  • Page 109: Uncrating And Unpacking The Aspen 8810 Chassis

    Do not proceed with uncrating and unpacking the chassis if either the Tilt Indicator or the Shock Indicator is displaying a red state condition. Immediately contact Extreme Networks should a red condition occur. Extreme Networks Consolidated XOS Hardware Installation Guide...
  • Page 110 Pull the prongs outward until the clip lock is released from the carton. d Repeat steps 3a through 3c to release each of the remaining clip locks. Figure 53: Clip locks located on Aspen shipping carton Clip lock Extreme Networks Consolidated XOS Hardware Installation Guide Figure ASP024 Figure...
  • Page 111 7 Gently lift the chassis off from the wood pallet onto the floor as shown in Figure 55: Correct method for lifting the Aspen chassis Extreme Networks Consolidated XOS Hardware Installation Guide Uncrating and Unpacking the Aspen 8810 Chassis Figure...

  • Page 112: Pre-Installation Requirements

    NOTE Save all packaging, bolts, washers, clip locks, and box for future use in the event that the chassis needs to be moved to another location or returned to Extreme Networks. Pre-Installation Requirements The following tools and equipment are required for assembling the Aspen 8810 mid-mount kit and...

  • Page 113: Rack Mounting The Aspen 8810 Chassis

    6 Remove the 19” helper bracket from the system rack once the chassis is secured. Extreme Networks Consolidated XOS Hardware Installation Guide Rack Mounting the Aspen 8810 Chassis Figure...

  • Page 114: Re-Crating And Re-Packing The Aspen 8810 Chassis

    4 Slowly guide the chassis out from the system rack using the 19” helper bracket. 5 Gently lift the chassis off from the 19” helper bracket onto wood pallet as shown in Figure 58: Correct method for lifting the Aspen chassis Extreme Networks Consolidated XOS Hardware Installation Guide Figure ASP017A...
  • Page 115 Repeat steps 8a through 8c to insert each of the remaining clip locks. Figure 60: Clip locks located on Aspen shipping carton Clip lock Extreme Networks Consolidated XOS Hardware Installation Guide Re-crating and Re-packing the Aspen 8810 Chassis Figure...
  • Page 116 11 Seal the top flaps of the Aspen shipping carton with packing tape. 12 Secure the Aspen shipping carton with nylon straps as shown in Figure Figure 62: Aspen shipping carton with nylon straps ASP026 Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 117: Chapter 10: Aspen 8810 Msm And I/O Modules

    The G8X MSM also has 8 data I/O ports. Refer to these ports. For full redundancy you can install up to two G8X MSMs in the Aspen 8810 switch. Each G8X MSM also contains a temperature sensor, nonvolatile random-access memory (NVRAM), and a real-time clock.

  • Page 118: Aspen 8810 Msm And I/O Modules

    Management port—The 10/100 Mbps Ethernet management port allows you to connect an Ethernet cable directly from your laptop into the management port to view and locally manage the switch configurations. Compact flash—You can insert an external compact flash memory card into this port. (Refer to Chapter 3 for more information on Extreme Networks-supported compact flash cards.)

  • Page 119: Slots For The Aspen 8810 Msm

    Slots for the Aspen 8810 MSM If you are using only one G8X MSM in the Aspen 8810 switch, install that MSM in slot 5. If you want to use two MSMs to increase reliability and throughput, install the second MSM in slot 6.

  • Page 120: Msm Leds

    The LEDs on the management Ethernet port are not labeled. The LED on the right is the link LED, and the one on the left is the activity LED. NOTE The data port LEDs on the G8X MSM operate the same as the port status LEDs on the G24X I/O module. Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 121: I/O Modules

    No configuration information is stored on the I/O modules; all configuration information is stored on the MSM(s). When the Aspen switch is powered on, the software generates a default configuration for any slots that contain I/O modules. The default configuration allows the I/O module ports to participate in the VLAN named default.

  • Page 122: G24X Module

    G24X module. Table 19: G24X media types and distances Mini-GBIC Type Media Type 1000BASE-SX multimode fiber 1000BASE-LX single-mode fiber 1000BASE-ZX single-mode fiber Extreme Networks Consolidated XOS Hardware Installation Guide Module status LEDs 1000BASE-X ports ASP041 Maximum Distance (meters) 10,000 70,000...

  • Page 123: G24X Leds

    All ports: Are added to the default VLAN as untagged. Inherit the properties of the default VLAN (for example, protocol type and VLANid). Extreme Networks Consolidated XOS Hardware Installation Guide “Mini-GBIC Type and Hardware/ Module status LEDs 10 Gbs ports...

  • Page 124: 10G4X Leds

    Inherit the properties of the default VLAN (for example, protocol type and VLANid) Operate in autonegotiation mode G48T LEDs The G48T module has the following LEDs: Module status Module diagnostics Port status Extreme Networks Consolidated XOS Hardware Installation Guide Module status LEDs 10/100/1000BASE-T ports ASP037 “I/O Module LEDs” on...

  • Page 125: G48P Module

    Inherit the properties of the default VLAN (for example, protocol type and VLANid) Operate in autonegotiation mode G48P LEDs The G48P module has the following LEDs: Module status Extreme Networks Consolidated XOS Hardware Installation Guide “I/O Module LEDs” on Module status LEDs 10/100/1000BASE-T PoE ports...

  • Page 126: I/O Module Leds

    This section describes the LEDs for the module, for the port, and for the inline power delivery status on the I/O modules on the Aspen switch. NOTE The inline power delivery apply only to the G48P ports on the Aspen switch. Module LEDs Table 20 describes the LED activity on the Aspen switch I/O modules.

  • Page 127: G48P Port Leds

    You will need the following tools and equipment to install an Aspen 8810 MSM or I/O module: ESD-preventive wrist strap #2 Phillips screwdriver Aspen 8810 chassis Aspen 8810 MSM or I/O module Extreme Networks Consolidated XOS Hardware Installation Guide Installing Aspen 8810 MSM and I/O Modules Indicates Link up Port disabled...

  • Page 128: Distinguishing An Aspen 8810 Msm From An I/O Module

    All slots on the Aspen chassis (including slots 5/A and 6/B) can accommodate an I/O module; however, only slots 5/A and 6/B can accommodate an MSM as shown in Figure 69: Aspen chassis slots for Aspen MSM and I/O modules Extreme Networks Consolidated XOS Hardware Installation Guide ASP022 Figure...

  • Page 129: Installing An Aspen 8810 Msm Or I/O Module

    Do not slide the module into the open slot if the injector/ejector handles are latched. 6 Latch the injector/ejector handles, using both hands, by simultaneously pushing both handles toward the center of the module as shown in Extreme Networks Consolidated XOS Hardware Installation Guide Installing Aspen 8810 MSM and I/O Modules Figure...
  • Page 130 Use a # 2 Phillips screwdriver as shown in Figure Figure 72: Screwdriver is shown turning captive screw one-quarter turn (90 degrees) ASP003A CAUTION Tightening the captive screws beyond 90 degrees will damage the injector/ejector handles on the modules. Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 131: Removing An Aspen 8810 Msm Or I/O Module

    3 Verify that the red line of each captive screw in both injector/ejector handles is set in a horizontal position. This position ensures that the module is unlocked as shown in Extreme Networks Consolidated XOS Hardware Installation Guide Installing Aspen 8810 MSM and I/O Modules...
  • Page 132 Aspen module’s connectors. NOTE Leave the ESD-preventive wrist strap permanently connected to the chassis so that it is always available when you need to touch ESD-sensitive components. Extreme Networks Consolidated XOS Hardware Installation Guide ASP005 Release Latch ASP006A...

  • Page 133: Installing Aspen Blank Front Panels

    The chassis ships with eight blank front panels. Slots number 4 and 5 are generally left open during shipment. Use blank front panel(s) to fill slots not occupied by MSM or I/O modules as shown in Figure Extreme Networks Consolidated XOS Hardware Installation Guide Installing Aspen Blank Front Panels 131.

  • Page 134: Removing An Aspen Blank Front Panel

    3 Loosen both captive screws, located on each end of the blank front panel, using a #2 Phillips screwdriver as shown in Figure Figure 77: Captive screw located on blank front panel Extreme Networks Consolidated XOS Hardware Installation Guide ASP019 ASP018...

  • Page 135: Installing An Aspen Blank Front Panel

    NOTE Leave the ESD-preventive wrist strap permanently connected to the chassis so that it is always available when you need to handle ESD-sensitive components. Extreme Networks Consolidated XOS Hardware Installation Guide Installing Aspen Blank Front Panels ASP020 for detailed information on MSM and I/O module...
  • Page 136 Aspen 8810 MSM and I/O Modules Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 137: Chapter 11: Aspen 8810 Fan Tray

    You need the following tools and equipment to remove the fan tray and install the spare fan tray on the Aspen chassis: ESD-preventive wrist strap #1 Phillips screwdriver #2 Phillips screwdriver Aspen 8810 spare fan tray Aspen 8810 spare PSU/fan controller Aspen 8810 chassis Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 138: Removing The Aspen 8810 Fan Tray

    Ensure that both hands are used to support the weight of the fan tray. NOTE Leave the ESD-preventive wrist strap permanently connected to the chassis so that it is always available when you need to touch ESD-sensitive components. Extreme Networks Consolidated XOS Hardware Installation Guide Fan Tray Captive Screws (x2)

  • Page 139: Installing The Aspen 8810 Spare Fan Tray

    Figure 80: Installing the fan tray into the tray slot on the Aspen chassis 6 Turn each captive screw clockwise, using a #2 Phillips screwdriver, to tighten the captive screws also shown in Figure Extreme Networks Consolidated XOS Hardware Installation Guide Installing the Aspen 8810 Spare Fan Tray Fan Tray Captive...

  • Page 140: Removing An Aspen 8810 Psu/Fan Controller

    3 Turn each captive screw counter-clockwise, using a #2 Phillips screwdriver, to loosen all eight captive screws on the access panel cover also shown in 4 Gently pull the access panel cover off from the access panel on the chassis. Extreme Networks Consolidated XOS Hardware Installation Guide Loosen Captive Screws (x8)
  • Page 141 NOTE Leave the ESD-preventive wrist strap permanently connected to the chassis so that it is always available when you need to handle ESD-sensitive components. Extreme Networks Consolidated XOS Hardware Installation Guide Removing an Aspen 8810 PSU/Fan Controller Loosen Captive Screws (x4)

  • Page 142: Installing An Aspen 8810 Spare Psu/Fan Controller

    8 Turn each captive screw clockwise, using a #2 Phillips screwdriver, to tighten all eight captive screws on the access panel cover. NOTE Leave the ESD-preventive wrist strap permanently connected to the chassis so that it is always available when you need to handle ESD-sensitive components. Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 143: Chapter 12: Aspen 8810 Ac Power Cord Retaining Bracket

    WARNING! The chassis does not have a switch for turning the unit on and off. Power to the chassis is disconnected by removing the wall plug from the electrical outlet. Ensure that all plugs and electrical outlets are easily accessible.

  • Page 144: Installing The Aspen 8810 Ac Power Cord Retaining Bracket

    4 Remove the Aspen AC power cord retaining bracket from the front of the Aspen chassis as shown in Figure Figure 84: Aspen AC power cord retaining bracket removed from the Aspen chassis Extreme Networks Consolidated XOS Hardware Installation Guide Figure REMOVE TO INSTALL POWER CORDS...
  • Page 145 7 Ensure that the AC power cord(s) are firmly plugged into the power outlet(s) as shown in Figure 87: AC power cord plugged into the Aspen chassis power outlet Extreme Networks Consolidated XOS Hardware Installation Guide Installing the Aspen 8810 AC Power Cord Retaining Bracket...

  • Page 146: Removing The Aspen 8810 Ac Power Cord Retaining Bracket

    5 Remove the end of the AC power cord(s) from the power outlet(s) on front of the Aspen chassis. NOTE Leave the ESD-preventive wrist strap permanently connected to the chassis so that it is always available when you need to touch ESD-sensitive components. Extreme Networks Consolidated XOS Hardware Installation Guide REMOVE TO INSTALL POWER CORDS ASP012A...
  • Page 147 Appendixes...

  • Page 149: Appendix A: Safety Information

    230 V (2P+T) via an isolation transformer ratio 1:1, with the secondary connection point labeled Neutral and connected directly to ground. Building codes vary worldwide; therefore, Extreme Networks strongly recommends that you consult an electrical contractor to ensure proper equipment grounding and power distribution for your specific installation.

  • Page 150: Power Supply Units (Psus)

    The unit must be connected to a grounded outlet to comply with European safety standards. WARNING! Ensure that the source outlet is properly grounded before plugging the AC power cord into Extreme Networks 700/ 1200 W AC PSU. WARNING! Ensure that the source outlet is properly grounded before plugging the AC power cord into Extreme Networks 700/1200 W AC PSU.

  • Page 151: Meeting Power Requirements

    If a power source fails, it will affect only the switch power supply to which it is connected. If all switch power supplies are connected to a single power source, the entire switch is vulnerable to a power source failure.

  • Page 152: Uninterruptible Power Supply Requirements

    UPS Transition Time Transition time is the time that is necessary for the UPS to transfer from utility power to full-load battery power. For Extreme Networks products, a transition time of less than 20 milliseconds is required for optimum performance.

  • Page 153: Power Cable - Power Supply Cords

    Power Cable - Power Supply Cords Extreme Networks 700/1200 W AC PSU(s) come with both 110 V AC and 220 V AC power supply cords. The 110 V AC power supply cord allows for a maximum DC output power of 700 W. The 220V AC power supply cord allows for a maximum DC output power of 1200 W.

  • Page 154: Switzerland

    Never look at the transmit LED/laser through a magnifying device while it is powered on. WARNING! Never look directly at a fiber port on the switch or at the ends of fiber cable when they are powered on. Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 155: Appendix B: Technical Specifications

    Temperature Range Operating Temperature Range Operating Humidity Range Storage Temperature Range Storage Humidity Range Extreme Networks Consolidated XOS Hardware Installation Guide Height: 38.5 inches (98 cm) Width: 17.3 inches (44 cm) Depth: 21.0 inches (53.3 cm) Height: 4.75 inches (12.07 cm) Width: 2.75 inches (6.99 cm)
  • Page 156 Temperature Range Operating Temperature Range Operating Humidity Range Storage Temperature Range Storage Humidity Range Extreme Networks Consolidated XOS Hardware Installation Guide Height: 24.47 inches (62.2 cm) Width: 17.51 inches (44.5 cm) Depth: 18.23 inches (46.3 cm) Height: 4.75 inches (12.07 cm) Width: 2.75 inches (6.99 cm)
  • Page 157 Extreme Networks Consolidated XOS Hardware Installation Guide...
  • Page 158 Technical Specifications Extreme Networks Consolidated XOS Hardware Installation Guide...

  • Page 159: Index

    133 blank front panel, installing, 98 building codes, 17 bundling cable, 25 cable connections, 29 cable identification records, 24 cable labeling Extreme Networks Consolidated XOS Hardware Installation Guide identification, 24 recommendations, 24 records, 24 cable manager components, 72 installing, 72...
  • Page 160 127 indicators, shipping status shock watch, 62 tilt watch, 62 industry standards, 32 initial switch log in, 35 Extreme Networks Consolidated XOS Hardware Installation Guide inline power I/O module, 125 LEDs, 127 installation Aspen 8810 MSM, 127 Aspen 8810 switch I/O modules, 127...
  • Page 161 33 LEDs, 126 management, 78 POST, 55 power cable replacing, 31 Extreme Networks Consolidated XOS Hardware Installation Guide requirements, 30 power requirements dual power supplies, 31 power cable, 30, 31 power supply, 29 power socket, 62...
  • Page 162 19 electrostatic discharge, 21 floor coverings, 18 grounding, 18 humidity, 20, 21 temperature, 18 wiring terminals, 22 Extreme Networks Consolidated XOS Hardware Installation Guide XENPAK module description, 44 hot-swapping, 44 installing, 45 removing, 45 ZX mini-GBIC, 41...

Table of Contents
