  • Page 1 BlackDiamond 8800 Hardware Install Guide 121139-00 Published February 2016...

  • Page 2: Legal Notice

    Copyright © 2016 Extreme Networks All rights reserved. Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.

  • Page 3: Table Of Contents

    Preface............................6 Text Conventions...................................6 Conventions..................................... 6 Providing Feedback to Us..............................7 Getting Help.....................................7 Related Publications................................8 Chapter 1: Overview of the BlackDiamond 8800 Series Switches........9 Full-Duplex Support................................10 Management Ports................................10 Compact Flash Memory Card............................10 BlackDiamond 8806 Chassis............................10 BlackDiamond 8810 Chassis............................12 Chapter 2: BlackDiamond 8000 Series Modules..............
  • Page 4 Installing a Compact Flash Memory Card......................99 Removing a Compact Flash Memory Card......................100 Initial Management Access............................101 Chapter 8: Installing BlackDiamond 8800 Series Module Options........ 103 Installing an S-POE Daughter Card..........................103 Removing an S-POE Card............................105 Installing a Port Option Card in the 8500-MSM24, 8800-MSM48c, 8800-MSM96, or 8900- MSM128....................................
  • Page 5 Table of Contents Modules for BlackDiamond 8800 Series Switches...................157 Power Supplies for BlackDiamond 8800 Series Switches................158 Connector Pinouts................................160 Index............................163 BlackDiamond 8800 Hardware Install Guide...

  • Page 6: Preface

    Italics are also used when referring to publication titles. Conventions This section discusses the conventions used in this guide. Platform-Dependent Conventions Unless otherwise noted, all information applies to all platforms supported by ExtremeXOS software, which are the following: BlackDiamond 8800 Hardware Install Guide...

  • Page 7: Providing Feedback To Us

    You can also email us directly at internalinfodev@extremenetworks.com. Getting Help If you require assistance, contact Extreme Networks Global Technical Assistance Center using one of the following methods: www.extremenetworks.com/support Phone 1-800-872-8440 (toll-free in U.S. and Canada) or 1-603-952-5000 For the Extreme Networks support phone number in your country: www.extremenetworks.com/support/contact...

  • Page 8: Related Publications

    Summit Family Switches Hardware Installation Guide for Switches Using ExtremeXOS 16 and Earlier • Summit Family Switches Hardware Installation Guide • E4G Series Routers Hardware Installation Guide • Extreme Hardware/Software Compatibility and Recommendation Matrices • Extreme Networks Pluggable Transceivers Installation Guide BlackDiamond 8800 Hardware Install Guide...

  • Page 9: Chapter 1: Overview Of The Blackdiamond 8800 Series Switches

    BlackDiamond 8810 chassis, with slots for installing one or two management modules and up to nine I/O modules Three series of modules are available for the BlackDiamond 8800 Series switches: • 8800 Series: Modules with high port density and scalability for mid-sized networks •...

  • Page 10: Full-Duplex Support

    Compact Flash Memory Card All MSMs in the BlackDiamond 8800 Series include a compact flash slot next to the console port. This slot accepts a compact flash memory card, which can be used to download a new version of ExtremeXOS and for other functions, including capturing debug information and core dump files.
  • Page 11 Overview of the BlackDiamond 8800 Series Switches The following figure shows the front of a BlackDiamond 8806 chassis equipped with two MSMs and three I/O modules. Figure 1: Front of the BlackDiamond 8806 Chassis 1 = ESD wrist strap connector...

  • Page 12: Blackdiamond 8810 Chassis

    Overview of the BlackDiamond 8800 Series Switches Figure 2: Rear Panel of the BlackDiamond 8806 Chassis 1 = Grounding point 2 = PSU/fan controller access panel The rear panel of the BlackDiamond 8806 chassis provides: • Chassis serial number •...
  • Page 13 Overview of the BlackDiamond 8800 Series Switches The following figure shows the front of a BlackDiamond 8810 chassis equipped with two MSMs and three I/O modules. Figure 3: Front of the BlackDiamond 8810 Chassis 1 = ESD wrist strap connector...
  • Page 14 Overview of the BlackDiamond 8800 Series Switches Figure 4: Rear Panel of the BlackDiamond 8810 Chassis 1 = Grounding point 2 = PSU/fan controller access panel The rear panel of the BlackDiamond 8810 chassis provides: • Chassis serial number •...

  • Page 15: Chapter 2: Blackdiamond 8000 Series Modules

    (MSMs) and I/O modules. A BlackDiamond module consists of a printed circuit board mounted on a metal panel that acts as the insertion vehicle in the BlackDiamond 8800 Series switches. The module carrier also includes ejector/injector levers and captive retaining screws at each end of the module front panel.

  • Page 16: Module Compatibility

    8800 Series with 8500 Series Caution Do not attempt to combine modules from the BlackDiamond 8800 Series and BlackDiamond 12800 series product lines. When a BlackDiamond 8800 Series switch is running, ExtremeXOS software will not recognize an installed BlackDiamond 12800 Series module.

  • Page 17: Management Switch Modules (Msms)

    10 for more information about Extreme Networks-supported compact flash cards.) Redundant MSM Activity The BlackDiamond 8800 Series switches can run with a single MSM installed. When you install an additional MSM, one MSM operates as the primary MSM and the other becomes the backup (secondary) MSM.

  • Page 18: Msm Physical Features

    1 = Slot for port option card 5 = MGMT port 2 = Module status LEDs 6 = A button 3 = Console port 7 = D button 4 = Compact flash 8 = R button BlackDiamond 8800 Hardware Install Guide...
  • Page 19 1 = Slot for port option card 5 = MGMT port 2 = Module status LEDs 6 = A button 3 = Console port 7 = D button 4 = Compact flash 8 = R button BlackDiamond 8800 Hardware Install Guide...

  • Page 20: Port Option Cards

    2 = SFP ports The S-10G1Xc port option card (see the following figure) adds one 10-gigabit XFP data port to the MSM. This data port operates the same as the ports on the 10G4Xc I/O module. BlackDiamond 8800 Hardware Install Guide...

  • Page 21: Msm Leds

    Are added to the default VLAN as untagged • Inherit the properties of the default VLAN (for example, protocol type and VLANid) For instructions to install a port option card in an MSM, see Installing BlackDiamond 8800 Series Module Options on page 103. Note...

  • Page 22: I/O Modules

    LED Meanings in I/O Modules for BlackDiamond 8800 Series Switches on page 36. I/O Modules The following series of I/O modules are available for the BlackDiamond 8800 Series switches: • BlackDiamond 8500 Series I/O modules (see BlackDiamond 8500 Series I/O modules) •...
  • Page 23 BlackDiamond 8000 Series modules. Caution When BlackDiamond I/O modules from different series (8500 Series; 8800 c-Series and e- Series; or 8900 Series) are installed in the same BlackDiamond 8800 Series chassis, limitations on feature sets may occur. See the ExtremeXOS User Guide...
  • Page 24 In the default configuration of the 8500-G48T-e I/O module, all ports: • Are added to the default VLAN as untagged • Inherit the properties of the default VLAN (for example, protocol type and VLANid) • Operate in autonegotiation mode BlackDiamond 8800 Hardware Install Guide...
  • Page 25 Module) Caution ExtremeXOS builds earlier than version 12.1 do not support the BlackDiamond 8800 c-Series modules. If you attempt to install one of these I/O modules before upgrading the software on your MSM the module will not be recognized by the software and it will not power up. The following error messages are similar to the messages that may be displayed on the console or in the log.
  • Page 26 For information about the LEDs and their activity on the G48Tc I/O module, see I/O Module LEDs page 35. G48Xc I/O Module The G48Xc I/O module (see the following figure) has 48 unpopulated SFP-based 1-gigabit Ethernet ports. BlackDiamond 8800 Hardware Install Guide...
  • Page 27 The 10G4Xc I/O module has the following LEDs: • Module status • Module diagnostics • Port status For information about the LEDs and their activity on the 10G4Xc I/O module, see I/O Module LEDs page 35. BlackDiamond 8800 Hardware Install Guide...
  • Page 28 Port status For information about the LEDs and their activity on the 10G8Xc I/O module, see I/O Module LEDs page 35. BlackDiamond 8800 e-Series I/O Modules The BlackDiamond 8800 e-Series of I/O modules includes: • G48Te2 (see G48Te2 I/O Module) Caution ExtremeXOS builds earlier than version 12.1 do not support the G48Te2 I/O module.
  • Page 29 BlackDiamond 8900 Series I/O Modules The following 8900 Series I/O modules are available: • 8900-G48T-xl (see 8900-G48T-xl I/O Module) • 8900-G48X-xl (see 8900-G48X-xl I/O Module) • 8900-G96T-c (see 8900-G96T-c I/O Module) • 8900-10G8X-xl (see 8900-10G8X-xl I/O Module) BlackDiamond 8800 Hardware Install Guide...
  • Page 30 Aspen 8810. 8900-G48T-xl I/O Module The 8900-G48T-xl I/O module (see the following figure) has 48 10/100/1000BASE-T ports using standard RJ-45 connectors. Figure 20: 8900-G48T-xl I/O Module BlackDiamond 8800 Hardware Install Guide...
  • Page 31 35. 8900-G48X-xl I/O Module The 8900-G48X-xl I/O module (see the following figure) has 48 unpopulated SFP-based 1-gigabit Ethernet ports. Figure 21: 8900-G48X-xl I/O Module 1 = 1000BASE-T ports 2 = Module and port LEDs BlackDiamond 8800 Hardware Install Guide...
  • Page 32 The 8900-G96T-c I/O module has the following LEDs: • Module status • Module diagnostics • Port status For information about the LEDs and their activity on the 8900-G96T-c I/O module, see I/O Module LEDs on page 35. BlackDiamond 8800 Hardware Install Guide...
  • Page 33 35. 8900-10G24X-c I/O Module The 8900-10G24X-c I/O module (see the following figure) has 24 unpopulated SFP+-based 10-gigabit Ethernet ports Figure 24: 8900-10G24X-c I/O Module 1 = 10 Gbps ports 2 = Module status LEDs BlackDiamond 8800 Hardware Install Guide...
  • Page 34 Depending on the specific MSMs present in the switch, the 8900-40G6X-xm module is oversubscribed in the following ratios: Table 9: BlackDiamond 8900-40G6X-xm Module Oversubscription MSM Configuration 8806 Chassis 8810 Chassis Single 8900-MSM128 module Dual 8900-MSM128 modules BlackDiamond 8800 Hardware Install Guide...
  • Page 35 I/O Module LEDs This section describes the LEDs for the module, the port, and inline power delivery status for I/O modules in the BlackDiamond 8800 Series of switches. Note Inline power delivery applies only to a G48tc, G48Te2, 8500-G48T-e, or 8900-G48T-xl I/O module with an installed S-POE card.
  • Page 36 BlackDiamond 8000 Series Modules Table 11: LED Meanings in I/O Modules for BlackDiamond 8800 Series Switches Color and State Meaning PoE Present Amber The optional PoE card is installed on the module but is malfunctioning. Green The optional PoE card is installed on the module and is active.
  • Page 37 8900-G48T-xl I/O module with an installed S-POE card Port LEDs on these modules indicate the status of the inline power delivered through the ports. The following table describes the LED meanings for each port on the PoE-capable I/O modules. BlackDiamond 8800 Hardware Install Guide...
  • Page 38 Port disabled or Link down Blinking amber/green Power fault or insufficient power Port with power disabled Solid green Link up Slow green blinking Port disabled Green blinking Activity Link down Blinking amber/green Power fault or insufficient power BlackDiamond 8800 Hardware Install Guide...

  • Page 39: Chapter 3: Power Supplies For Blackdiamond 8800 Series Switches

    Extreme Networks 1200 W DC Power Supply The BlackDiamond 8800 Series switches can be powered by either AC or DC power supplies (PSUs). AC power supplies in the BlackDiamond 8800 Series switches are fully fault tolerant and load-sharing in an N+1 configuration.
  • Page 40 700/1200 W AC power supply to Extreme Networks for repair or replacement LEDs The front panel of the Extreme Networks 700/1200 W AC power supply provides the status LEDs listed the following table. BlackDiamond 8800 Hardware Install Guide...

  • Page 41: Power Supply Cords

    Power Supply Cords The Extreme Networks 700/1200 W AC power supply can be used with either a 110 V AC or a 220 V AC power supply cord. If you use a 110 V AC power supply cord, the maximum DC output power of the power supply is 700 W.

  • Page 42: Extreme Networks 600/900 W Ac Power Supply

    Extreme Networks 600/900 W AC Power Supply The following figure shows the Extreme Networks 600/900 W AC UL-listed accessory power supply unit (Model number 41050/PS 2431). This power supply is compatible with the BlackDiamond 8806 switch. The power supply bay can accommodate up to six hot-swappable 600/900 W AC power supplies.
  • Page 43 The AC input is located on the switch directly below each installed power supply. Note The Extreme Networks 600/900 W AC power supply can be used in combination with an Extreme Networks 700W/1200W AC power supply in the same BlackDiamond 8806 system.

  • Page 44: Extreme Networks 1200 W Dc Power Supply

    Fuse The Extreme Networks 600/900 W AC power supply line and neutral legs are both fused. Power to the system may still be live if the neutral fuse is open. This is not a field operator replaceable fuse. In the event of failure, immediately return the Extreme Networks 600/900 W AC power supply for a complete replacement.
  • Page 45 Power Supplies for BlackDiamond 8800 Series Switches Figure 28: 1200 W DC Power Supply Airflow enters from the front vents on the 1200 W DC power supply and exits to the rear vents of the switch. Airflow through the 1200 W DC power supply is independent of the airflow that exists through the rest of the switch.
  • Page 46 1200 W DC power supply to Extreme Networks for repair or replacement. Minimum Software Required The MSM installed in your BlackDiamond 8800 Series switch must be running ExtremeXOS version 11.3 or later for the system to recognize the DC power supply.

  • Page 47: Chapter 4: Site Preparation

    Evaluating and meeting cable requirements After examining your physical site and verifying that all environment requirements are met, evaluate and compare your existing cable plant with the requirements of the Extreme Networks equipment to determine if you need to install new cables.

  • Page 48: Building And Electrical Codes

    Commission that regulates all interstate and foreign 445 12th Street SW electrical communication systems that originate in the Washington, DC 20554 United States according to the Communications Act of 1934. The FCC regulates all U.S. telephone and cable systems. BlackDiamond 8800 Hardware Install Guide...

  • Page 49: Wiring Closet Considerations

    Temperature Extreme Networks equipment generates a significant amount of heat. It is essential that you provide a temperature-controlled environment for both performance and safety. Install the equipment only in a temperature- and humidity-controlled indoor area that is free of airborne materials that can conduct electricity.

  • Page 50: Chassis Spacing Requirements

    To ensure proper airflow through a BlackDiamond switch, refer to the following recommendations when you install the switch: • BlackDiamond 8800 Series switches require a minimum of 1.5 inches (4 cm) around both the left and right sides of the chassis from any cabinet wall or other obstruction for proper airflow. •...

  • Page 51: Electrostatic Discharge

    Use electrostatically safe equipment and the ESD-preventive wrist strap that is provided with your equipment. All switches have ESD-preventive wrist strap connectors and are shipped with an ESD- preventive wrist strap as shown in the following figure. Figure 31: Using an ESD-preventive Wrist Strap BlackDiamond 8800 Hardware Install Guide...

  • Page 52: Rack Specifications And Recommendations

    Use a rack grounding kit and a ground conductor that is carried back to earth or to another suitable building ground. All Extreme Networks switches are designed with mounting brackets that provide solid metal-to-metal connection to the rack. If you do not use equipment racks, you can attach wiring terminals directly to the mounting brackets for appropriate grounding.

  • Page 53: Space Requirements For The Rack

    Figure 32: Properly Secured Rack Brace open equipment racks if the channel thickness is less than 1/4 inch (6.4 mm). BlackDiamond 8800 Hardware Install Guide...

  • Page 54: Cable Requirements

    Assign a unique block of sequential numbers to the group of cables that run between each pair of wiring closets. • Assign a unique identification number to each distribution rack. • Identify all wiring closets by labeling the front panel of your Extreme Networks equipment and other hardware. • Keep accurate and current cable identification records. •...
  • Page 55 Proprietary to Extreme Networks. Connections between two Extreme Networks 1000BASE-LX interfaces that use 10/125 µm single-mode fiber can use a maximum distance of 10,000 meters.

  • Page 56: Cable Installation

    MRJ21-to-RJ-45 patch panel such as the AMP NETCONNECT part number 1435971-1 Figure 34: Typical Cables for Connection to the 8900-G96T-c Module You can order MRJ21 cables and accessories for the 8900-G96T-c module from Extreme Networks or from your local supplier.
  • Page 57 Unshielded twisted pair (UTP) cable can build up ESD charges when being pulled into a new installation. Before connecting any category 5 UTP cable to the switch, discharge ESD from the cable by plugging the RJ-45 connector into a LAN Static Discharge device or use an equivalent method. BlackDiamond 8800 Hardware Install Guide...
  • Page 58 Use care in dressing the optical fiber cables: provide satisfactory strain relief to support the cable and maintain an adequate bend radius at all cable turns, particularly where the cable connects to the I/O module. BlackDiamond 8800 Hardware Install Guide...

  • Page 59: Power Requirements

    When connecting power over Ethernet (PoE) devices to a PoE switch, all connections between the PoE device and the switch must remain within the same building and must use a low-voltage power distribution system per IEEE 802.3af. BlackDiamond 8800 Hardware Install Guide...

  • Page 60: Power Supply Requirements

    AC power input cords are not provided with BlackDiamond power supplies. To purchase a power cord for your product and for your specific country, contact your local Extreme Networks Channel Account Manager or Sales Manager, or purchase a cord from your local supplier.

  • Page 61: Uninterruptible Power Supply Requirements

    3 Add together the VA from all the pieces of equipment to find the total VA requirement. To determine the minimum volt-amperage requirements for your UPS, we recommend that you add 30% to the total. BlackDiamond 8800 Hardware Install Guide...

  • Page 62: Applicable Industry Standards

    UPS Transition Time Transition time is the time that is necessary for the UPS to transfer from utility power to full-load battery power. For Extreme Networks products, a transition time of less than 20 milliseconds is required for optimum performance.

  • Page 63: Chapter 5: Installing The Blackdiamond 8800 Series Chassis

    Grounding the BlackDiamond 8800 Series Chassis The BlackDiamond 8800 Series chassis fits into a standard 19-inch (48.26 cm) rack. You can install the switch either flush against the back of the rack or in a mid-mount position to give you more access behind the rack.
  • Page 64 Installing the BlackDiamond 8800 Series Chassis Cut the straps around the shipping carton (see the following figure). Figure 37: Cutting the Straps Around the Carton 2 Open the flaps and remove the contents from the upper shipping carton (see the following figure).
  • Page 65 Installing the BlackDiamond 8800 Series Chassis 3 Lift the BlackDiamond 8810 shipping carton up and off the chassis (see the following figure). Remove the inside corner braces. Figure 39: Removing the Shipping Carton 4 At each corner, remove the restraining bolt that holds the BlackDiamond 8810 chassis to the...
  • Page 66 Installing the BlackDiamond 8800 Series Chassis 5 At each side of the chassis, place one hand in an empty power supply bay and the other hand in the recessed hand-hold on the back panel of the BlackDiamond 8810 chassis (see the following figure).

  • Page 67: Unpacking The Blackdiamond 8806 Chassis

    Installing the BlackDiamond 8800 Series Chassis Verify that the following items are included in the shipping carton: • BlackDiamond 8810 chassis with eight installed blank front panels • Power cord retainer • 19-inch support bracket • BlackDiamond documentation pack with ESD-preventive wrist strap The ESD-preventive wrist strap is required for installing modules in the chassis.
  • Page 68 Installing the BlackDiamond 8800 Series Chassis 2 On each side of the shipping carton, remove the clip lock at the bottom (see Figure 44: Clip Locks on the BlackDiamond 8806 Chassis Shipping Carton on page 68). a Using your thumb and index finger, squeeze the prongs together to release the clip lock.
  • Page 69 Installing the BlackDiamond 8800 Series Chassis 5 At each side of the chassis, place one hand in an empty power supply bay and the other hand in the recessed hand-hold on the back panel of the chassis (see the following figure).

  • Page 70: Pre-Installation Requirements

    Phillips screwdriver. Attaching the Mid-Mount Brackets The BlackDiamond 8800 Series chassis has attached rack-mounting flanges for a front-mount rack installation. To install the chassis in a mid-mount position in the rack, attach the optional mid-mount brackets as described in this section.
  • Page 71 Installing the BlackDiamond 8800 Series Chassis 2 Identify the locations for the mid-mount brackets. Note The BlackDiamond 8806 chassis has two possible positions for attaching the mid-mount brackets. 3 Match the left and right brackets to the correct side of the chassis.

  • Page 72: Rack-Mounting The Chassis

    Rack-Mounting the Chassis To install the BlackDiamond 8800 Series chassis in a rack: Locate the 19-inch support bracket that is shipped with the BlackDiamond 8800 series chassis. 2 Identify the rack location where the chassis will be installed. 3 Using four rack mounting screws, attach the support bracket to the equipment rack immediately...
  • Page 73 Installing the BlackDiamond 8800 Series Chassis 4 Lift the back of the empty chassis onto the support bracket. 5 Slowly guide the chassis into the rack until the mounting brackets are against the rack uprights. 6 Secure the chassis to the rack using eight rack mounting screws. (Screws are not provided.) Be sure that the screws are tight.

  • Page 74: Grounding The Blackdiamond 8800 Series Chassis

    Save the bracket for future use if you need to remove the chassis from the rack. Grounding the BlackDiamond 8800 Series Chassis Although grounding the BlackDiamond 8800 Series chassis is optional, it is recommended. A grounding point with integrated pem-nuts is provided on the back of the chassis.
  • Page 75 Installing the BlackDiamond 8800 Series Chassis Locate the grounding pad on the back of the chassis (see the following figure Figure 54: Back of BlackDiamond 8810 Chassis on page 75). Figure 53: Back of BlackDiamond 8806 Chassis Figure 54: Back of BlackDiamond 8810 Chassis 2 Strip 0.5-inch (1.2-cm) of insulation from the stranded copper wire cable.
  • Page 76 Installing the BlackDiamond 8800 Series Chassis 6 Connect the other end of the wire to a known reliable earth ground point at your site. BlackDiamond 8800 Hardware Install Guide...

  • Page 77: Chapter 6: Installing Power Supply Units (Psus)

    Extreme Networks for repair or replacement. Power Supply Compatibility The BlackDiamond power supply units are intended for use in specific BlackDiamond switches. following table lists the BlackDiamond 8800 Series switches and their compatible power supply units. BlackDiamond 8800 Hardware Install Guide...

  • Page 78: Combining Different Ac Power Supply Models

    We do not recommended using the 1200 W DC power supply in combination with any Extreme Networks AC power supply in the same BlackDiamond 8800 Series system. We recommend that DC and AC power supply units not be used together in the same BlackDiamond switch.

  • Page 79: Power Supply Cords For Ac Power Supplies

    • 1200 W DC power supply For the system to recognize the 1200 W DC power supply, the MSM in your BlackDiamond 8800 Series switch must be running ExtremeXOS version 11.3 or later. Power Supply Cords for AC Power Supplies The AC power supplies used with the BlackDiamond 8800 Series switches can use either 110 V AC or 220 V AC power supply cords.

  • Page 80: Installing The Power Supply

    Installing Power Supply Units (PSUs) The power supply bay in the BlackDiamond 8800 Series switch can accommodate up to six hot- swappable AC power supplies. Note In a BlackDiamond 8806 system, the 700/1200 W AC power supply can be combined with a 600/900 W AC power supply in the same chassis.

  • Page 81: Removing Or Replacing An Ac Power Supply

    BlackDiamond AC Power Cord Retainers on page 109 Removing or Replacing an AC Power Supply Caution The AC power supply may be hot to the touch; use thermal protective gloves when handling the power supply during removal. BlackDiamond 8800 Hardware Install Guide...

  • Page 82: Installing An Extreme Networks 1200 W Dc Power Supply

    Field operators must not attempt to open the 1200 W DC power supply enclosure for any reason; the power supply does not contain user-serviceable parts. In the event of failure, return the defective 1200 W DC power supply to Extreme Networks for repair or replacement. Note AC input connections on the chassis are not used when DC power supplies are installed.

  • Page 83: Installing A 1200 W Dc Power Supply

    Be sure that the grounding pad on the back of the switch chassis is securely connected to earth ground. For information about grounding the switch, see Grounding the BlackDiamond 8800 Series Chassis on page 74. To install an Extreme Networks 1200 W DC power supply: BlackDiamond 8800 Hardware Install Guide...
  • Page 84 Note Do not connect the input DC cable to the DC power supply before you install the DC power supply in the chassis. Figure 59: Locking Handle on the 1200 W DC Power Supply BlackDiamond 8800 Hardware Install Guide...
  • Page 85 85 to install additional power supplies. 4 Verify that the DC power is turned off at the source. Caution Always verify that the DC circuit is de-energized before you connect the input cable to the 1200 W DC power supply. BlackDiamond 8800 Hardware Install Guide...

  • Page 86: Removing A Dc Power Supply

    The DC power supply may be hot to the touch; use thermal protective gloves to handle the power supply during removal. To remove an Extreme Networks 1200 W DC power supply: De-energize the DC circuit for the 1200 W DC power supply that will be removed.
  • Page 87 5 Wearing thermal protective gloves, place both hands underneath the power supply to support the weight as it is pulled out from the switch. To remove additional DC power supplies, repeat steps on page 86 through on page 87. BlackDiamond 8800 Hardware Install Guide...

  • Page 88: Chapter 7: Installing Modules And Establishing Initial Management Access

    Removing a Compact Flash Memory Card Initial Management Access This chapter describes how to install the MSMs and I/O modules in the BlackDiamond 8800 Series switches and how to set up initial management access for the switch. All module types are hot- swappable.

  • Page 89: Distinguishing An Msm From An I/O Module

    The color of the release latch is different on the injector/ejector handle of BlackDiamond 8000 Series MSMs and I/O modules. Orange injector/ejector release latches indicate that the module is a BlackDiamond MSM, and green injector/ejector release latches indicate that the module is a BlackDiamond I/O module (see the following figure). BlackDiamond 8800 Hardware Install Guide...

  • Page 90: Installing A Blackdiamond 8000 Series Module

    Caution Although they appear physically similar, BlackDiamond 12800 Series modules are not compatible with BlackDiamond 8800 Series hardware. Do not try to install a BlackDiamond 12800 Series module in a BlackDiamond 8810 or 8806 chassis. When you handle modules, optical devices, or other modular accessories, use an ESD-preventive wrist strap to reduce the risk of electronic damage to the equipment.
  • Page 91 6 Keep the injector/ejector handles in the open position as you slide the module into the chassis slot. Caution Do not slide the module into the open chassis slot if the injector/ejector handles are in the latched position. BlackDiamond 8800 Hardware Install Guide...
  • Page 92 (see the following figure). Caution Two different styles of ejector/injector handles are on the BlackDiamond 8800 Series modules. Pay careful attention to the instructions in the next step. Figure 65: Injector/ejector Handles in the Latched Position 8 Using a #2 Phillips screwdriver, lock the module into place (see...

  • Page 93: Connecting Network Interface Cables

    93 through on page 93 for the remaining cables on this or other switches or I/O modules. 6 Dress and secure the cable bundle to provide appropriate strain relief and protection against bends and kinks. BlackDiamond 8800 Hardware Install Guide...

  • Page 94: Installing A Backup Msm

    Displaying Slot Status Information Assuming the module has no problems, the command show slot slot (where slot is the number of the slot where you installed the module) displays information about the module including: general BlackDiamond 8800 Hardware Install Guide...

  • Page 95: Removing A Blackdiamond 8000 Series Module

    Guide. Removing a BlackDiamond 8000 Series Module Caution BlackDiamond 8800, and 8900 Series modules have two styles of ejector/injector levers. Pay careful attention to the instructions in step on page 96. This section describes how to remove modules from a BlackDiamond 8800 Series switch.
  • Page 96 Be sure to turn each captive screw only 90 degrees or one-quarter turn counter- clockwise. Loosening the captive screws beyond 90 degrees will damage the injector/ ejector handles on the module. Figure 68: Unlocking a Module BlackDiamond 8800 Hardware Install Guide...

  • Page 97: Blank Front Panels

    Caution All unoccupied slots in a BlackDiamond 8800 Series switch must have blank front panels correctly installed to ensure conformance to FCC requirements as well as to maintain adequate airflow through the switch.

  • Page 98: Removing A Blank Front Panel

    Verify that the EMI gasket is on the top of the front panel and the stenciled part number is right side Figure 70: Blank Front Panels in a BlackDiamond 8800 Series Chassis 3 Use a #2 Phillips screwdriver to tighten the captive screws at each end of the blank front panel.

  • Page 99: Installing A Compact Flash Memory Card

    3 Remove the blank front panel from the front of the BlackDiamond switch (see the following figure). Figure 72: Removing a Blank Front Panel from a BlackDiamond 8800 Series Switch 4 Install an I/O module or MSM in the open slot as described in Installing a BlackDiamond 8000 Series Module on page 90.

  • Page 100: Removing A Compact Flash Memory Card

    2 Locate the compact flash slot on the MSM (see the following figure). Figure 73: Typical Compact Flash Slot Location (BlackDiamond 8800 Series MSM) 3 Hold the memory card between your thumb and forefinger. The side with the ridge faces toward the bottom of the chassis.

  • Page 101: Initial Management Access

    Parity—None • Flow control—XON/XOFF The terminal or PC with terminal-emulation software that you connect to an Extreme Networks switch must be configured with these settings. This procedure is described in the documentation supplied with the terminal. Appropriate cables are available from your local supplier, or you can make your own. To ensure the electromagnetic compatibility of the unit, use only shielded serial cables.
  • Page 102 The configuration is saved to the configuration database of the MSM modules in the switch. Note For more information about saving configuration changes, see the ExtremeXOS User Guide. 8 When you are finished with these tasks, log out of the switch by typing: logout BlackDiamond 8800 Hardware Install Guide...

  • Page 103: Chapter 8: Installing Blackdiamond 8800 Series Module Options

    G48Te2 • 8500-G48T-e • 8900-G48T-xl You must remove the I/O module from the BlackDiamond 8800 Series switch before you install the S- POE card. You need the following tools and equipment to install an S-POE card: • ESD-preventive wrist strap •...
  • Page 104 Installing BlackDiamond 8800 Series Module Options 3 Identify the daughter card connectors on the I/O module (see the following figure). Figure 74: Daughter Card Connectors on the BlackDiamond G48Tc, G48Te2, or 8500-G48T-e I/O Module 4 Remove the S-POE card from its anti-static packaging.

  • Page 105: Removing An S-Poe Card

    (see the following figure) Figure 76: Securing the S-POE Card to the I/O Module 7 Re-install the I/O module in the BlackDiamond 8800 Series switch following the instructions in Installing a BlackDiamond 8000 Series Module on page 90. Removing an S-POE Card To remove an S-POE card: Attach the ESD-preventive wrist strap to your bare wrist.

  • Page 106: Installing A Port Option Card In The 8500-Msm24, 8800-Msm48C, 8800-Msm96, Or 8900-Msm128

    Installing BlackDiamond 8800 Series Module Options Installing a Port Option Card in the 8500-MSM24, 8800-MSM48c, 8800-MSM96, or 8900-MSM128 The 8500-MSM24, 8800-MSM48c. 8800-MSM96, and 8900-MSM128 modules each have a slot for one of the following port option cards: • S-G8Xc, which adds eight 1-gigabit SFP data ports to the MSM •...

  • Page 107: Removing A Port Option Card

    Installing BlackDiamond 8800 Series Module Options 5 At the edge of the module, rotate the hot-swap prevention latch up and hold it out of the way. Slide the card the rest of the way into the slot (see the following figure).
  • Page 108 Attach an ESD-preventive wrist strap to your bare wrist. If the metal end is not already connected, connect it to the ground receptacle at the top left corner of the chassis. 2 Remove the MSM from the BlackDiamond 8800 Series switch as described in Removing a BlackDiamond 8000 Series Module on page 95.

  • Page 109: Chapter 9: Blackdiamond Ac Power Cord Retainers

    BlackDiamond 8810 AC Power Cord Retainer BlackDiamond 8806 AC Power Cord Retainer The AC power cord retainers for BlackDiamond 8800 Series switches hold the power connectors in the power sockets and prevent accidental disconnection due to earthquakes, vibration, or other disturbances.
  • Page 110 Figure 83: AC Power Cord Plugged into the BlackDiamond 8810 Switch Power Outlet 4 Align the AC power cord retainer over the AC power cord ends (see the following figure). Figure 84: AC Power Cord Retainer Correctly Aligned BlackDiamond 8800 Hardware Install Guide...

  • Page 111: Blackdiamond 8806 Ac Power Cord Retainer

    You need a #2 Phillips screwdriver to install or removing the BlackDiamond 8806 AC power cord retainer: • ESD-preventive wrist strap • #2 Phillips screwdriver Installing the BlackDiamond 8806 AC Power Cord Retainer To install the BlackDiamond 8806 AC power cord retainer: BlackDiamond 8800 Hardware Install Guide...
  • Page 112 2 Hold the AC power cord retainer (see the following figure). Figure 87: BlackDiamond 8806 AC Power Cord Retainer 3 Place the retainer against the switch (see the following figure). Tighten the captive screw at each end of the retainer. BlackDiamond 8800 Hardware Install Guide...

  • Page 113: Removing The Blackdiamond 8806 Ac Power Cord Retainer

    Removing the BlackDiamond 8806 AC Power Cord Retainer To remove the BlackDiamond 8806 AC power cord retainer: Use a #2 Phillips screwdriver to loosen the captive screw located on each end of the AC power cord retainer. BlackDiamond 8800 Hardware Install Guide...
  • Page 114 BlackDiamond AC Power Cord Retainers 2 Remove the retainer from the switch. BlackDiamond 8800 Hardware Install Guide...

  • Page 115: Chapter 10: Blackdiamond Psu Covers

    BlackDiamond PSU Covers BlackDiamond 8810 PSU Cover BlackDiamond 8806 PSU Cover Covers are available to mask the front panels of the installed power supplies in the BlackDiamond 8800 Series switches. BlackDiamond 8810 PSU Cover The BlackDiamond PSU cover fits onto the AC power cord management bracket and snaps into place on the front of the BlackDiamond 8810 switch.
  • Page 116 Align and tighten the captive retaining screws. 4 Set the feet on the base of the cover into the square openings on the top of the AC cord retainer (see the following figure). Figure 92: Setting the PSU Cover in Place BlackDiamond 8800 Hardware Install Guide...

  • Page 117: Blackdiamond 8806 Psu Cover

    BlackDiamond 8806 switch. The PSU cover kit includes the following parts (Figure 94: BlackDiamond 8806 PSU Cover Kit on page 118): • PSU cover • AC power cord management bracket with captive retaining screws BlackDiamond 8800 Hardware Install Guide...

  • Page 118: Installing The Blackdiamond 8806 Psu Cover

    3 Attach the AC power cord retainer to the switch: a Place the retainer against the front of the switch as shown in see the following figure. Make sure that the retainer engages all the power cord connectors. BlackDiamond 8800 Hardware Install Guide...
  • Page 119 Align and tighten the captive retaining screws. 4 Set the feet on the base of the cover into the square openings on the top of the power cord retainer (see the following figure). Figure 96: Setting the PSU Cover in Place BlackDiamond 8800 Hardware Install Guide...

  • Page 120: Removing The Blackdiamond 8806 Psu Cover

    Press down on the latching tab at each side of the top. 2 With the latching tabs pressed down, pull outward on the top edge of the cover to disengage it from the switch chassis. 3 Lift the cover off the AC cord retainer. BlackDiamond 8800 Hardware Install Guide...

  • Page 121: Chapter 11: Blackdiamond Cable Management

    Cable Holders and Cable Clips When you use the cable holders and the cable clips, Extreme Networks recommends the following: • Attach the cables to the holders by slipping the cable through the opening.

  • Page 122: Connecting Cable Holders

    Each cable holder holds up to 12 separate cables, with 6 on each side. Connect cable holders end to end as needed to accommodate the number of cables you need to organize. To connect the cable holders: BlackDiamond 8800 Hardware Install Guide...

  • Page 123: Connecting Cable Clips

    4 To disconnect the holders, grasp one in each hand firmly and carefully pull them apart. Connecting Cable Clips To connect the cable clips: Hold two clips next to each other with the split sides facing the same way (see Figure 101: Connecting Cable Clips on page 124). BlackDiamond 8800 Hardware Install Guide...
  • Page 124 Figure 102: Cable Clip Chain 4 Connect as many cable clips together as you need to manage your cable bundles. 5 To disconnect the cable clips, push on the bottom ring while holding the top ring steady. BlackDiamond 8800 Hardware Install Guide...

  • Page 125: Chapter 12: Replacing Blackdiamond 8800 Series Chassis Components

    BlackDiamond 8806 switch Replacing the Fan Tray The BlackDiamond 8800 Series switch has one fan tray that is accessible from the front of the switch. Note To avoid long periods of operation without forced air cooling, make sure you have the replacement fan tray ready before you start the replacement procedure.
  • Page 126 Replacing BlackDiamond 8800 Series Chassis Components 2 Using a #2 Phillips screwdriver, loosen each captive screw (see the following figure Figure 104: Removing the Fan Tray from the BlackDiamond 8806 Switch on page 126). Figure 103: Removing the Fan Tray from the BlackDiamond 8810 Switch...

  • Page 127: Installing The Replacement Fan Tray

    Installing the Replacement Fan Tray To install a replacement fan tray into the BlackDiamond 8800 Series switch: Support the bottom of the fan tray with one hand as you lift the fan tray by the handle using the other hand.
  • Page 128 Replacing BlackDiamond 8800 Series Chassis Components Figure 105: Installing the Fan Tray in the BlackDiamond 8810 Switch Figure 106: Installing the Fan Tray in the BlackDiamond 8806 Switch 3 Use a #2 Phillips screwdriver to tighten the screws. BlackDiamond 8800 Hardware Install Guide...

  • Page 129: Replacing The Psu/Fan Controller

    Replacing BlackDiamond 8800 Series Chassis Components Replacing the PSU/Fan Controller The BlackDiamond 8800 Series switch has two PSU/fan controllers behind an access panel on the rear of the switch chassis. Note The PSU/fan controllers are installed in the switch chassis before it is shipped to customers.
  • Page 130 Replacing BlackDiamond 8800 Series Chassis Components 2 Locate the eight captive screws on the PSU/fan controller access cover at the back of the switch (see the following figure Figure 108: Removing the Access Cover from the BlackDiamond 8806 Switch on page 131).
  • Page 131 Replacing BlackDiamond 8800 Series Chassis Components Figure 108: Removing the Access Cover from the BlackDiamond 8806 Switch 3 Using a #2 Phillips screwdriver, loosen all eight captive screws on the PSU/fan controller access cover. 4 Pull the access cover away from the back of the switch.
  • Page 132 ESD-sensitive components. Installing the Replacement PSU/Fan Controller To install a replacement PSU/fan controller in the BlackDiamond 8800 Series switch: Attach the ESD-preventive wrist strap to your bare wrist and connect the metal end to the ground receptacle on the front top-left corner of the switch.

  • Page 133: Chapter 13: Repacking A Blackdiamond 8800 Series Chassis

    This chapter describes how to remove a BlackDiamond 8800 Series chassis from an equipment rack and repack the chassis for shipping back to Extreme Networks. To repack a BlackDiamond 8800 Series chassis, use the original shipping crate or box and packing materials.

  • Page 134: Repacking The Blackdiamond 8810 Chassis

    Attach the ESD-preventive wrist strap to your bare wrist and connect the metal end to the ground receptacle on the chassis front panel. 2 Remove all modules and power supplies from the chassis. Follow correct Extreme Networks procedures for removing components.
  • Page 135 Repacking a BlackDiamond 8800 Series Chassis 7 At each corner, attach a restraining bolt to the shipping bracket, securing the BlackDiamond 8810 chassis to the shipping pallet (see the following figure). Figure 111: Recrating the BlackDiamond 8810 Chassis 8 Set a corner brace at each corner of the chassis, and slide the shipping carton down over the chassis (see the following figure).
  • Page 136 Repacking a BlackDiamond 8800 Series Chassis 9 Set the packing foam in place on top of the chassis (see the following figure). Figure 113: Packing Foam for the BlackDiamond 8810 Chassis 10 Close the top flaps on the shipping carton and seal them with packing tape.

  • Page 137: Repacking The Blackdiamond 8806 Chassis

    Repacking a BlackDiamond 8800 Series Chassis 11 Secure the BlackDiamond 8810 shipping carton with nylon straps (see the following figure). Figure 114: BlackDiamond 8810 Shipping Carton with Nylon Straps Repacking the BlackDiamond 8806 Chassis To repack the BlackDiamond 8806 chassis: Attach the ESD-preventive wrist strap to your bare wrist and connect the metal end to the ground receptacle on the chassis front panel.
  • Page 138 Repacking a BlackDiamond 8800 Series Chassis 6 Carefully lift the chassis off the support bracket and lower it onto the foam cushion in the shipping carton base (see Figure 115: Setting the BlackDiamond 8806 Chassis onto the Foam Cushion page 138.) To lift the chassis, on each side of the chassis, place one hand in the empty power supply bay and the other hand in the recessed hand-hold on the back panel of the chassis.
  • Page 139 Repacking a BlackDiamond 8800 Series Chassis 7 Set a corner brace at each corner of the chassis, and slide the shipping carton down over the chassis (see the following figure). Figure 116: Placing the Carton over the BlackDiamond 8806 Chassis 8 Insert the clip locks at the base of the shipping carton.
  • Page 140 Figure 118: BlackDiamond 8806 Chassis Shipping Carton with Nylon Straps Note Nylon straps are optional but are recommended by Extreme Networks for extra security during shipment. Installing nylon straps requires a crimping tool. If you do not have nylon straps and a crimping tool available to secure the carton, the chassis can be shipped without the straps;...

  • Page 141: Appendix A: Safety Information

    Failure to follow this safety information can lead to personal injury or damage to the equipment. Only trained service personnel should perform service to Extreme Networks switches and their components. Trained service personnel have read all related installation manuals, have the technical training and experience necessary to be aware of the hazards to which they are exposed in performing a task, and are aware of measures to minimize the danger to themselves or other persons.

  • Page 142: Maintenance Safety

    EMC regulations. • Do not attempt to repair a chassis, power supply, module, or other component. In the event of failure, return the defective unit to Extreme Networks for repair or replacement, unless otherwise instructed by an Extreme Networks representative. •...

  • Page 143: Cable Routing For Poe Devices

    BlackDiamond 8800 Series Switches on page 158 or the data sheet for the power supply at www.extremenetworks.com. Warning Be sure to satisfy the requirements listed in this section when you install Extreme Networks power supplies. When you install any power supply: •...

  • Page 144: Selecting Power Supply Cords

    • Extreme Networks AC power supplies do not have switches for turning the unit on and off. Remove all wall plugs from the electrical outlet to disconnect the power. Make sure that these connections are easily accessible.

  • Page 145: Battery Replacement And Disposal

    Dispose of the battery in accordance with the battery manufacturer’s recommendation. Fiber Optic Ports—Optical Safety The following safety warnings apply to all optical devices used in Extreme Networks equipment that are removable or directly installed in an I/O module or chassis system. Such devices include but are not...

  • Page 146: Sicherheitshinweise

    Never alter, modify, or change an optical device in any way other than suggested in this document. Note Extreme Networks optical modules are tested to work in all supported Extreme Networks switches. We recommend that all customers use Extreme Networks optical modules in their Extreme Networks switches.

  • Page 147: Hinweise Zur Installation

    Richtlinien und anderen internationalen Richtlinien. Der Gerätebetrieb unterliegt den folgenden Voraussetzungen: (1) Das Gerät kann schädliche Interferenzen verursachen, und (2) das Gerät muss jede empfangene Interferenz zulassen, einschließlich einer Interferenz, die einen unerwünschten Betrieb verursachen kann. BlackDiamond 8800 Hardware Install Guide...

  • Page 148: Installation Von Netzteilen

    Folgende Anforderungen müssen unbedingt erfüllt sein: • Wenn der mit Wechsel- oder Gleichstrom betriebene Switch von Extreme Networks mit einem externen grünen/gelben Erdungskabel ausgestattet ist, dann muss zunächst dieses Erdungskabel zwischen der Grundplatte und einem geeigneten Erdungspunkt angeschlossen werden, bevor andere Verbindungen zum Gerät hergestellt werden;...
  • Page 149 Das Gleichstromkabel des 325 W DC-Netzteils muss von einem qualifizierten, zugelassenen Elektriker an die Gleichspannungsquelle in Ihrem Gebäude angeschlossen werden. Extreme Networks 325 W AC Netzteile haben keinen An- Aus Schalter. Die Stromzufuhr zu einem Extreme Networks 325 W AC Netzteil wird durch das Ziehen des Netzkabels unterbrochen.

  • Page 150: Allgemeine Sicherheitsvorkehrungen

    Networks entweder nur mit einem 110-VAC-Kabel oder mit einem 110-VAC-Kabel und einem 208/220- VAC-Kabel geliefert. Die von Extreme Networks gelieferten Stromkabel sind nur für den Einsatz in den Vereinigten Staaten und Kanada ausgelegt und zugelassen. Stromkabel für den Einsatz außerhalb der Vereinigten Staaten und Kanada werden normalerweise von einem Drittanbieter geliefert und müssen...
  • Page 151 WARNUNG! Vor dem Anschließen des Wechselstromkabels an ein Netzteil muss sichergestellt werden, dass die Steckdose vorschriftsgemäß geerdet ist. Note NOTIZ: Hinweis: Die Bauvorschriften sind weltweit verschieden; Extreme Networks empfiehlt daher ausdrücklich, einen Elektroinstallateur zu beauftragen, um die sachgemäße Geräteerdung und Stromverteilung für Ihre spezifische Installation sicherzustellen.

  • Page 152: Appendix B: Technical Specifications

    BlackDiamond 8810 Switch BlackDiamond 8806 Switch Modules for BlackDiamond 8800 Series Switches Power Supplies for BlackDiamond 8800 Series Switches Connector Pinouts This appendix includes technical specifications for the BlackDiamond 8810 and 8806 switches as well as for associated modules, power supplies, and connector pinouts.
  • Page 153 Note: These standards are module- IEEE 802.3z 1000BASE-X specific and may not apply to every IEEE 802.3ab 1000BASE-T module in the series. IEEE 802.3ac VLAN Tag IEEE 802.3ad Link Aggregation IEEE 802.3ae 10GBASE-X IEEE 802.3aef Power over Ethernet BlackDiamond 8800 Hardware Install Guide...

  • Page 154: Blackdiamond 8806 Switch

    Depth: 18.12 inches (46.0 cm) Weight (empty): 63.75 lb (29.0 kg) Weight (fully loaded): 153 lb (69.5 kg) BlackDiamond 8806 fan tray Weight: 4.75 lb (2.2 kg) Minimum fan speed: 500 RPM Maximum fan speed: 6000 RPM BlackDiamond 8800 Hardware Install Guide...
  • Page 155 Criteria C 2004/108/EC EMC Directive International CISPR 22:2005+A1:2005 Class A (International Emissions) CISPR 24:1997_A1:2001+A2:2002 (International Immunity) VCCI, 2010-04, Class A (Japan) ACMA, AS/NZS CISPR22:2009 (Australia) KCC Mark, KN22, KN24 (Korea) BSMI, CNS 13438:1997 Class A (Taiwan) BlackDiamond 8800 Hardware Install Guide...
  • Page 156 Packaged sinusoidal vibration: 5 to 62 Hz, 5 mm/s velocity, 62 to 200 Hz, 0.2 g Tilt: 22.5 degrees and return to position 14 drops minimum on sides & corners @ 39.4" <20 lb (9 kg) modules @ 19.7" <80 lb (36 kg) chassis BlackDiamond 8800 Hardware Install Guide...

  • Page 157: Modules For Blackdiamond 8800 Series Switches

    GR-63 Issue 2 Normal: 64 dBA front side @ 0.6m High: 66 dBA left side @ 0.6m Modules for BlackDiamond 8800 Series Switches Table 35: Specifications for BlackDiamond 8000 Series Modules All Modules Dimensions: 1.63 inches high by 15.26 inches wide by 15.25 inches deep (4.1 cm by 38.8 cm by 38.7 cm)

  • Page 158: Power Supplies For Blackdiamond 8800 Series Switches

    Dimensions: 1.25 inches H by 14.31 inches W by 4.81 inches D (3.18 cm by 36.35 cm by 12.22 Weight: 0.80 lb (0.36 kg) Power Supplies for BlackDiamond 8800 Series Switches Table 36: Specifications for the AC SSI PS Model # 60020/PS2336 (700/1200 W AC...
  • Page 159 18 AWG (0.75 mm2) up to 6 feet or 2 meters or 16 AWG (1.0 mm2) over 6 feet Operating conditions Operating temperature: 0°C to 40°C (32°F to 104°F) Storage temperature: –40°C to 70°C Operating humidity: 10% to 90% relative humidity, non-condensing Operational shock: 30 m/s2 (3 g) BlackDiamond 8800 Hardware Install Guide...

  • Page 160: Connector Pinouts

    Maximum in-rush current: Not more than 80 A for 5 ms Input circuit protection: 50 A Wire harness provided by Extreme Networks with each power supply: Extreme Part Number 4340-00028 Wire type: 8 AWG (10 mm2) listed tray cable, copper-stranded rated @ 90 C...
  • Page 161 Figure 119: Null-modem Cable Pinouts The following figure shows the pinouts for a 9-pin to 9-pin (PC-AT) null-modem serial cable. Figure 120: PC-AT Serial Null-modem Cable Pinouts The following figure shows the port assignments for the MRJ21 connector. BlackDiamond 8800 Hardware Install Guide...
  • Page 162 Technical Specifications Figure 121: Port-to-Pin Assignments in the MRJ21 Connector BlackDiamond 8800 Hardware Install Guide...

  • Page 163: Index

    BlackDiamond 8000 Series modules, see I/O modules 8800-MSM96 module BlackDiamond 8500 Series I/O modules, see I/O modules front panel 18–20 BlackDiamond 8800 c-Series I/O modules, see I/O modules LEDs 21 BlackDiamond 8806 switch 8806 switch, see BlackDiamond 8806 switch attaching mid-mount brackets 70 8810 switch, see BlackDiamond 8810 switch bandwidth 10...
  • Page 164 AC power 60 removing 105 bend radius 56, 58 DB-9 console connector bundling 56 pinouts 160 category 5 56 DC power supply clips 121, 123 installing 82, 83 connecting 93 removing 86 connecting and disconnecting 94 replacing 86 connecting to power supply 80, 83 tools for installing 82 distances 55 wiring 82 BlackDiamond 8800 Hardware Install Guide...
  • Page 165 G48Te2 28 fuse G48Xc 26 600/900 W AC 44 hot-swapping 95 700/1200 W AC 41 installing 90 LEDs 35 removing 95 slot assignments 88 G24Xc I/O module software requirements 23, 25, 28, 29 features 25 specifications 157 LEDs 35 verifying installation 94 G48Tc I/O module identification records features 26 cables 54 BlackDiamond 8800 Hardware Install Guide...
  • Page 166 PoE 28, 103, 105 memory card, see external memory card PoE devices mid-mount brackets 70 cable routing 143 module status LEDs 35 I/O modules 30 modules, see I/O modules port LEDs 37 mounting holes 52 BlackDiamond 8800 Hardware Install Guide...
  • Page 167 (RFI) BlackDiamond 8810 switch 12 and UTP cable 59 settings patch panel installation 56 for console port 101 preventing 59 show slot command 94 problems caused by 59 slot assignments 88 removing software requirements AC power supply 81 1200 W DC 46 BlackDiamond 8800 Hardware Install Guide...
  • Page 168 PSU 79, 80 installing PSU cover 115, 117 repacking 133 replacing fan tray 125 replacing PSU/fan controller 129 transition time UPS 62 transportation conditions 152, 154 tray, see fan tray troubleshooting installing external memory card 99 over-current conditions 41, 44 radio frequency interference (RFI) 59 BlackDiamond 8800 Hardware Install Guide...

Table of Contents
