Exit Device
Installation Instructions
A8185D
04/21
Copyright 2016, 2019, 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
IN
Series
IN120 Wi-Fi
IN220 PoE
Exit Device
Installation Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SARGENT IN120 Wi-Fi Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Assa Abloy SARGENT IN120 Wi-Fi Series

Summary of Contents for Assa Abloy SARGENT IN120 Wi-Fi Series

  • Page 1 IN220 PoE Exit Device Installation Instructions A8185D 04/21 Copyright 2016, 2019, 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

  • Page 2: Table Of Contents

    IN120 / IN220 Exit Device Table of Contents Warning ...................3 Regulatory & Power Specifications ........4 General Description ..............5 Hardware Specifications ............5 Technical Specifications ............5 Parts Breakdown ..............6 IN220 (PoE) Installation Wiring ..........9 Installation for 8877/8878 Rim Exit ........13 Installation for 8977/8978 Mortise Type .......19 IN120 / IN220 Installation Instructions .........25 Operational Check ..............31 1-800-810-WIRE •...

  • Page 3: Warning

    IN120 / IN220 Exit Device Warning Changes or modifications to this device not expressly approved by ASSA ABLOY could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Regulatory & Power Specifications

    IN120 / IN220 Exit Device Regulatory and Power Specifications Electronic Authentication Specifications (Mobile Credentials) For Mobile Credential-Enabled versions of this electronic lock (Indicated by the credential code in the product order string): • Mobile Credentials are transmitted to the lock via Bluetooth Smart or NFC ISO/IEC14443 and must use a mobile device enabled with these technologies.

  • Page 5: General Description

    NFC & BLE-enabled mobile phones • HID Mobile Access (BLE & NFC) ® *For specific security information, please contact your • Apple Wallet Seos or DESFire (NFC) ® local ASSA ABLOY Door Security Solutions sales consultant or call 800-810-WIRE. 1-800-810-WIRE • www.sargentlock.com • A8185D...

  • Page 6: Parts Breakdown

    IN120 / IN220 Exit Device Parts Breakdown Tools Required: • #2 Phillips screwdriver • Flat head screwdriver • Security allen wrench 3a 3b* ITEM No. DESCRIPTION Outside Escutcheon Assembly Inside Mounting Plate Assembly (includes Gasket) PoE Controller Assembly Wi-Fi Controller Assembly* (batteries included) Inside Escutcheon Assembly with Privacy Button AA alkaline batteries (6) *Consult catalog for electronic replacement part numbers...
  • Page 7 IN120 / IN220 Exit Device Parts Breakdown (Continued) 8877/8878 x ET x Lever Design IN220 Rim Exit Device ITEM PART No. DESCRIPTION REQ’D Cylinder Assembly (Reference Catalog for Available Cylinders) Lever (Reference Catalog for Available Styles) 97-4105 Exit Trim (ET) With Cylinder 97-4106 Exit Trim (ET) Without Cylinder 52-4845...
  • Page 8 IN120 / IN220 Exit Device Parts Breakdown (Continued) 8977/8978 x RT x Lever Design IN220 Mortise Exit Device ITEM PART No. DESCRIPTION REQ’D Cylinder Assembly (Reference Catalog for Available Cylinders) Lever (Reference Catalog for Available Styles) 97-4107 Exit Trim (ET) With Cylinder 97-4108 Exit Trim (ET) Without Cylinder 52-4845...

  • Page 9: In220 (Poe) Installation Wiring

    IN120 / IN220 Exit Device IN220 (PoE) Installation Wiring Overview SARGENT IN220 PoE Typical Application Network Cable Surface Mount RJ45 Network Switch (802.3af) EAC Software System: A. PoE frame harness assembly B. PoE data hinge from McKinney C. PoE door harness* from McKinney D.
  • Page 10 IN120 / IN220 Exit Device 7 IN220 (PoE) Installation Wiring (Continued) Supplied by CI Supplied by End User Certified Integrator (CI) supplies and terminates the B-Splice connector and the PoE Switch male RJ45 connector from harness to end user provided facility cable B-Splice Patch Cable Crimp Connector...
  • Page 11 IN120 / IN220 Exit Device 7 IN220 (PoE) Installation Wiring (Continued) Frame Harness Installation Components and wire harness supplied by McKinney. Suggested installation: Supplied by CI Cut end / ceiling-side PoE harness: B-Splice TIA/EIA 568-B Standard Wiring Crimp Connector Wire Pair Number White/Orange...
  • Page 12 IN120 / IN220 Exit Device 7 IN220 (PoE) Installation Wiring (Continued) PoE Door Harness Order of installation may vary. Refer to appropriate sections for instructions. Hinge-side harness connectors: • 4-pin male Molex connector • 6-pin male Molex connector with ground wire Lock-side harness connectors: •...

  • Page 13: Installation For 8877/8878 Rim Exit

    IN120 / IN220 Exit Device Installation Instructions for 8877/8878 Rim Exit 1 Prepare Door Inside A. Verify Hand and Bevel of Door • Check hand of door. The exit device is non-handed and the trim is field reversible. Left Hand Right Hand •...
  • Page 14 IN120 / IN220 Exit Device 2 Install Door Position Switch (DPS) Wood doors have 3/8” raceway to controller cutout and metal doors have 3/4” raceway to the controller cutout. Refer to template A8214. 1. Insert connector end of DPS through the raceway on the latch edge of the door (Fig. 2A). Note: For metal doors, use DPS Collar.
  • Page 15 IN120 / IN220 Exit Device 3 Mount Exit Device Chassis NOTE: Exit chassis harness consists of a 6-pin female connector and two different-sized ground lugs (Fig. 3A) 1. Feed 6-pin connector and larger ground lug straight through to outside of door (Fig.
  • Page 16 IN120 / IN220 Exit Device 4 Mount Exit Trim (ET) NOTE: For exterior applications, use ET gasket (52-0263) to seal between ET escutcheon and outside door surface. A. Connect motor harness adapter to chassis harness connector (Fig. 4A). B. For wood doors: Route ET wire harness connector through the cylinder hole, up and through the wire run channel to the controller cutout.
  • Page 17 IN120 / IN220 Exit Device 5 Install Cylinder For devices without cylinder, go to Step 6. 1. While installing the rim cylinder, support the tail piece of the cylinder, verifying its engagement with the top hub of the exit chassis. Note: Be sure ET harness is clear of cylinder and tailpiece.
  • Page 18 IN120 / IN220 Exit Device 7 Install Chassis Cover Secure chassis cover to chassis using (4) #8-32 x 5/16” oval head machine screws (Fig. 7). NOTE: Cable lengths exaggerated for illustrative purposes. Fig. 7 To complete installation, continue to Section 10 - IN120 / IN220 Installation Instructions 1-800-810-WIRE •...

  • Page 19: Installation For 8977/8978 Mortise Type

    IN120 / IN220 Exit Device Installation Instructions for Mortise Type 8977/8978 Exit Device 1 Door Preparation Inside A. Verify Hand and Bevel of Door • Check hand of door. This exit device is handed and is not reversible. Left Hand Right Hand •...
  • Page 20 IN120 / IN220 Exit Device 2 Install Door Position Switch (DPS) Wood doors have 3/8” raceway to controller cutout and metal doors have 3/4” raceway to the controller cutout. Refer to template A8215. 1. Insert connector end of DPS through the raceway on the latch edge of the door (Fig.
  • Page 21 IN120 / IN220 Exit Device 3 Mount Mortise & Exit Device Chassis 1. Slide mortise lock into door and loosely secure with (2) flat head screws. NOTE: Exit chassis harness consists of a 6-pin female connector and two different-sized ground lugs (Fig. 3A) 2.
  • Page 22 IN120 / IN220 Exit Device 4 Position Exit Trim (ET) NOTE: For exterior applications, use ET gasket (52-0263) as a seal between ET escutcheon and outside door surface. A. Connect motor harness adapter to chassis harness connector (Fig. 4A). B. For wood doors: Route ET wire harness connector through the cylinder hole, up and through the wire run channel to the controller cutout.
  • Page 23 IN120 / IN220 Exit Device 5 Install Cylinder For devices without cylinder, go to Step 6. 1. While installing the rim cylinder, support the tail piece of the cylinder, verifying its engagement with the top hub of the exit chassis. Note: Be sure ET harness is clear of cylinder and tailpiece.
  • Page 24 IN120 / IN220 Exit Device 7 Install Chassis Cover Secure chassis cover to chassis using (4) #8-32 x 5/16” oval head machine screws (Fig. 7). NOTE: Cable lengths exaggerated for illustrative purposes. Fig. 7 To complete installation, continue to Section 10 - IN120 / IN220 Installation Instructions 1-800-810-WIRE •...

  • Page 25: In120 / In220 Installation Instructions

    IN120 / IN220 Exit Device IN120 / IN220 Installation Instructions 1 Outside Reader and Mounting Plate Assembly Installation 1. Orient reader / keypad so LED lens is at the top. 2. Feed the cable/connector through door (from outside to inside). 3.
  • Page 26 IN120 / IN220 Exit Device 2 Outside Reader and Mounting Plate Assembly Installation (Continued) 1. Next feed cables/connectors through the inside mounting assembly (and gasket if required*). 2. Insert and partially tighten (2) through-bolts prior to installation of connectors. Gasket* Inside of Door NOTE: Cable lengths exaggerated for illustrative purposes Inside...
  • Page 27 IN120 / IN220 Exit Device 3 Installation of Connectors Important Note: Before you secure the connectors CAUTION - Do not allow debris to enter connector contacts APPLY (grease)* Ensure connectors are covered with silicone dielectric compound FILL FILL SILICONE DIELECTRIC COMPOUND FILL FILL...
  • Page 28 IN120 / IN220 Exit Device 3 Installation of Connectors (Continued) Important Note: If you are installing IN220 (PoE)*: E. Pull 5 1/2 inches of Ethernet cable from hole. Strip cable jacket back 3 1/2 inches. F. Separate (untwist) and straighten (8) Ethernet wires before carefully feeding through ferrite bead (Fig.
  • Page 29 IN120 / IN220 Exit Device 4 Installing the Controller (Continued) 1. Insert bottom tab of controller (ensure a clear path) into slot on mounting plate (Fig. 4D, E). 2. Ensure proper alignment of board-to-board connectors (Fig. 4E) while pivoting controller toward door until two tabs on top snap securely into place on mounting plate (Fig.
  • Page 30 IN120 / IN220 Exit Device B. IN120 (WIFI) 1. Once controller is securely in place, place (6) “AA” alkaline batteries in the compartment, being care- ful to align polarity properly. 2. After batteries are installed, there is a slight delay; then an audible “beep”...

  • Page 31: Operational Check

    IN120 / IN220 Exit Device Operational Check IMPORTANT: Be sure to test functions prior to closing door. In all cases, perform the following checks: 1. Ensure that inside exit bar retracts latch. • To test cylinder, the following checks apply: Insert key into cylinder and rotate: a.
  • Page 32 The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2016, 2019, 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. A8185D - 04/21...
