A7765C
01/18
Copyright 2018, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
v.S1
Profile
PoE Exit Device

Installation Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sargent Profile Series and is the answer not in the manual?

Questions and answers

Related Manuals for Assa Abloy Sargent Profile Series

Summary of Contents for Assa Abloy Sargent Profile Series

  • Page 1: Installation Instructions

    Profile PoE Exit Device Installation Instructions A7765C 01/18 Copyright 2018, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

  • Page 2: Table Of Contents

    Parts Breakdown Mortise 8977/8978 ........11 Installation Instructions for Rim 8877/8878 ......13 Installation Instructions for Mortise 8977/8978 ....10 Operational Check ..............28 Changes or modifications to this unit not expressly approved by ASSA ABLOY Inc. Warning could void the user’s authority to operate the equipment. FCC: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules.

  • Page 3: General Description

    Profile Series v.S1 PoE Exit Device General Description The SARGENT Profile Series v.S1 exit device is available with either an HID 125 kHz prox or 13.56 MHz ® iCLASS technology reader. It utilizes existing infrastructure and IEEE 802.3af PoE (Power over Ethernet) ®...

  • Page 4: Installation Wiring

    Profile Series v.S1 PoE Exit Device Installation Wiring PoE frame harness assembly (From McKinney) DPS: Door Position Switch (cylindrical and exits only) PoE data hinge (Patent Pending) (From McKinney) Profile Series v.S1 Online P1 PoE lock PoE door harness* (From McKinney) * Order of installation may vary.
  • Page 5 Profile Series v.S1 PoE Exit Device Installation Wiring (Continued) Frame Harness Installation Components and wire harness supplied by McKinney: Suggested installation. Supplied by CI Cut end / ceiling-side PoE harness: TIA-568-B Standard Wiring B-Splice Crimp Connector Pair Number Wire White/Blue White/Blue Blue White/Orange...
  • Page 6 Profile Series v.S1 PoE Exit Device Installation Wiring (Continued) PoE Door Harness Order of installation may vary. Refer to appropriate sections for instructions. 1. Prop door open. 2. Tape the two lock-side 4-pin connectors to the ring terminal. 3. Using the ring terminal, carefully fish the assembly through the door channel to the lock. 4.
  • Page 7 Profile Series v.S1 PoE Exit Device Installation Wiring (Continued) Door Position Switch 1. Prep door according to proper template (Fig. D1). 2. Insert connector end of DPS through the raceway on the latch edge of the door (Fig. D2). 3. Note: Only use collar when installing in a metal door. 4.
  • Page 8 Profile Series v.S1 PoE Exit Device Installation Wiring (Continued) PoE Lock Wiring (v.S1) Ground Ring Terminal 4-Pin From Hinge Ground Ring Terminal (From Hinge to Top Left Escutcheon Screw) J P 4 J P 4 T P 7 T P 7 C 2 1 C 2 1 T P 8...

  • Page 9: Parts Breakdown Rim 8877/8878

    Profile Series v.S1 PoE Exit Device Parts Breakdown Profile Series 125 kHz Prox or 13.56 MHz iCLASS Rim Exit Device ® (8877/8878 x ET x Lever Design) 1-800-810-WIRE • www.sargentlock.com • A7765C...

  • Page 10: Installation Instructions For Mortise 8977/8978

    Profile Series v.S1 PoE Exit Device Profile Series 125 kHz Prox or 13.56 MHz iCLASS Rim Exit Device, Continued ® (8877/8878 x ET x Lever Design) ITEM PART NO. DESCRIPTION REQ’D S1-777-8-HAND-FINISH ’S’ Series ET Trim - With Cylinder S1-778-8-HAND-FINISH ’S’...

  • Page 11: Parts Breakdown Mortise 8977/8978

    Profile Series v.S1 PoE Exit Device Profile Series 125 kHz Prox or 13.56 MHz iCLASS Mortise Exit Device ® (8977/8978 x ET x Lever Design) 1-800-810-WIRE • www.sargentlock.com • A7765C...
  • Page 12 Profile Series v.S1 PoE Exit Device Parts Breakdown for Profile Series 13.56 MHz iCLASS Rim Exit Device (Continued) ® (8977/8978 x ET x Lever Design) ITEM PART NO. DESCRIPTION REQ’D S1-777-HAND-FINISH ’S’ Series ET Trim - With Cylinder S1-778-HAND-FINISH ’S’ Series ET Trim - Without cylinder ET Lever Reference 8900 Series Catalog for Available Levers 68-1397...

  • Page 13: Installation Instructions For Rim 8877/8878

    Profile Series v.S1 PoE Exit Device Installation for Profie Series v.S1 With 8877/8878 Rim Exit Device Step #1 – Prepare Door Inside A. Verify Hand and Bevel of Door • This device is non-handed. • Door should be fitted and hung. •...
  • Page 14 Profile Series v.S1 PoE Exit Device 3 – Secure Inside Trim and Chassis 1. Route ET harness through wire run channel for wood doors (Fig. 3A) and through access hole for metal doors (not shown). Note: Make sure no wires are pinched. 2.
  • Page 15 Profile Series v.S1 PoE Exit Device Step #4 – Install Cylinder For devices without cylinder, skip this step. 1. Insert cylinder into ET trim (Fig. 4A). 2. Mate cylinder tailpiece into hub of exit device chassis. 3. Make sure ET harness is clear of cylinder and cylinder tailpiece. Fig.
  • Page 16 Profile Series v.S1 PoE Exit Device Step #7 – Install Door Position Switch (DPS) If it is not installed, install the door position switch: 1. Prep door according to proper template (A7992). 2. Insert DPS into the raceway on the latch edge of the door by pushing wires down raceway towards the lock.
  • Page 17 Profile Series v.S1 PoE Exit Device Step #9 – Connect and Position Outside Escutcheon Wires Images shown represent installation without gasket. If gasket is necessary, refer to Step #8. Before the controller is attached to the door: 1. Attach the outside escutcheon reader assembly ribbon cable to the inside face of the controller assembly (side that faces towards the door when mounted (P1).
  • Page 18 Profile Series v.S1 PoE Exit Device Step #11 – Additional Wiring Connections Inside of Door Chassis, DPS and raceway wire connections: Ground Ring Terminal 1. Connect RX rail connector from ET to chassis harness. 2. Attach connector from ET to the controller assembly (TB1). (2) 4-Pin Connectors Tuck ferrite bead under circuit board.
  • Page 19 Profile Series v.S1 PoE Exit Device Step #13 – Install Inside Escutcheon 1. Insert #8-32 x 1-1/4” screws through inside escutcheon and thread into outside escutcheon. Make sure the topf of the screw routes through the ground ring terminal. 2. Tuck wires safely under space below controller assembly.
  • Page 20 Profile Series v.S1 PoE Exit Device Installation for Profie v.S1 With 8977/8978 Mortise Exit Device Inside Step #1 - Prepare Door A. Verify Hand and Bevel of Door • Check handing of door - this device is not reversible • Door should be fitted and hung Left Hand Right Hand...
  • Page 21 Profile Series v.S1 PoE Exit Device Step #4 – Secure Inside Trim and Chassis 1. Route ET harness through wire route slot for wood doors (Fig. 4A) and access hole for metal doors (not shown). Note: Make sure no wires are pinched. 2.
  • Page 22 Profile Series v.S1 PoE Exit Device Step #5 - Install Exit Chassis 1. Route ET harness through wire run channel for wood doors (Fig. 5A) and through access hole for metal doors (not shown). 2. Mount exit chassis carefully. Do not pinch harness wires. 3.
  • Page 23 Profile Series v.S1 PoE Exit Device Step #7 – Door Options A. Fire Stop Plate (P/N 52-0033) Fire-rated doors require a fire stop plate on Ribbon Cable Hole the outside of the door (Fig.7A). 1. If not present, drill (2) 1/8" x 1-1/4" deep holes in the door.
  • Page 24 Profile Series v.S1 PoE Exit Device Step #9 – Attach Gasket and Install Outside Escutcheon For exterior applications, use a gasket (part number 82-0500) between escutcheon and outside door surface. To apply weatherseal gasket: Gasket 82-0500 Carefully remove the backing from the gasket (Fig. 9A). 2A.
  • Page 25 Profile Series v.S1 PoE Exit Device Step #10 – Connect and Position Outside Escutcheon Wires Images shown represent installation without gasket. If gasket is necessary, refer to Step #9. Before the controller is attached to the door: 1. Attach the reader assembly ribbon cable to the inside face of the controller assembly (side that faces towards the door when mounted (P1).
  • Page 26 Profile Series v.S1 PoE Exit Device Step #12 – Additional Chassis Wiring Connections Chassis, DPS and raceway wire connections: Ground Ring Terminal 1. Connect RX rail connector from ET to chassis harness. 2. Attach connector from ET to the controller assembly (TB1). (2) 4-Pin Connectors Tuck ferrite bead under circuit board.
  • Page 27 Profile Series v.S1 PoE Exit Device Step #14 – Install Inside Escutcheon 1. Place chassis cover over chassis. 2. Fasten with side screws from chassic screw pack. 3. Insert #8-32 x 1-1/4” screws through inside escutcheon and thread into outside escutcheon. 4.

  • Page 28: Operational Check

    The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2018, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
