  • Page 1 Keypad Rim/Mortise Exit Devices Installation & Programming Instructions A7137E 02/21 Copyright 2014. 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
  • Page 2 Instructions for Installation of Keypad Rim & Mortise Exit Devices KP8877 / KP8878 KP8977 / KP8978 Table of Contents Regulatory Compliance ............3 Warning ...................3 General Description ..............4 Specifications ................4 Features ...................4 Parts Breakdown ..............5 Rim Installation Instructions for KP8800 Series ....7 Mortise Installation Instructions for KP8900 Series ....14 Programming Instructions ............15 Troubleshooting ..............27...
  • Page 3 Instructions for Installation of Keypad Rim & Mortise Exit Devices KP8877 / KP8878 KP8977 / KP8978 Regulatory Compliance Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 4 Instructions for Installation of Keypad Rim & Mortise Exit Devices KP8877 / KP8878 KP8977 / KP8978 General Description The SARGENT Keypad Operated Rim Exit Device is designed for areas which require standalone authorized entry. It is a self-contained microprocessor-controlled keypad with non-volatile memory. The keypad will hold a total of 99 different User Codes.
  • Page 5 KP8877/KP8878 x ET x Lever Design Keypad Operated RIM Exit Device Parts Breakdown ITEM # PART # DESCRIPTION 52-2340 *Outside Escutcheon Assembly (with keypad assy) 52-0004 *Outside Escutcheon only 52-2299 Keypad (with ribbon cable) less escutcheon 52-2303 Screw Pack (Includes 1c, 1d, 2d, 2e) 52-0033 Fire Stop Plate 01-1500...
  • Page 6 Installation Instructions Mortise Exit Device KP8977 / KP8978 ITEM # PART # DESCRIPTION 52-2340 *Outside Escutcheon Assembly (with keypad assy) 52-0004 *Outside Escutcheon only 52-2299 Keypad (with ribbon cable) less escutcheon 52-2303 Screw Pack (Includes 1c, 1d, 2d, 2e) 52-0033 Fire Stop Plate 01-1500 Fire Stop Plate screws...
  • Page 7 KP8877/KP8878 x ET x Lever Design Keypad Operated RIM Exit Device Parts Breakdown (Continued) Optional Equipment • Data Transfer Device (DTD) - used to download the user and transaction type. • Remote Unlocking - 52-2071 - used for remote unlocking of motorized “ET”...
  • Page 8 KP8877/KP8878 x ET x Lever Design Keypad Operated RIM Exit Device Rim Installation Instructions for KP8800 Series (Continued) Step #2 Install Outside & Inside Trim 1. Outside Trim 2. Inside Trim • Route “ET” harness along track cutout for wood doors and •...
  • Page 9 KP8877/KP8878 x ET x Lever Design Keypad Operated RIM Exit Device Rim Installation Instructions for KP8800 Series (Continued) Step #3 - Exterior Door Options A. Fire Stop Plate (P/N 53-0033) Fire-rated doors require a fire stop plate on the outside of the door (Fig. 4A). 1.
  • Page 10 KP8877/KP8878 x ET x Lever Design Keypad Operated RIM Exit Device Rim Installation Instructions for KP8800 Series (Continued) B. Weather Conduit* (supplied with Weatherization Kit 52-6084) Install weather conduit* on NON FIRE-RATED exterior doors only. Ensure larger conduit houses smaller conduit with attached O-ring (Fig.4B).
  • Page 11 KP8877/KP8878 x ET x Lever Design Keypad Operated RIM Exit Device Rim Installation Instructions for KP8800 Series (Continued) Step #5 Outside Keypad Escutcheon Connector & Wires go through fire stop plate Lower Fire stop Lower plate Inside Outside of door of door •...
  • Page 12 KP8877/KP8878 x ET x Lever Design Keypad Operated RIM Exit Device Rim Installation Instructions for KP8800 Series (Continued) Step #5 Inside Controller Assembly • Plug keypad connector into inside escutcheon as shown.The back Back- plate can be removed to feed the plate Keypad large connector through slot into...
  • Page 13 KP8877/KP8878 x ET x Lever Design Keypad Operated RIM Exit Device Rim Installation Instructions for KP8800 Series (Continued) Step #6 Rail Assembly Install rail according to installation instruction sheet A6770 Step #7 Battery Installation • Place (4) C size batteries into the compartment •...
  • Page 14 Installation Instructions Mortise Exit Device KP8977 / KP8978 Mortise Installation Instructions for KP8900 Series NOTE: BEFORE STARTING • Check hand of door - this device is not reversible • Door should be fitted and hung • Verify box label for size of exit device, function and hand Left Hand Right Hand Reverse Bevel...
  • Page 15 Installation Instructions Mortise Exit Device KP8977 / KP8978 Mortise Installation Instructions for KP8900 Series (Continued) 3. Cylinder Installation (KP8977 & 12-KP8977) 4. Securing Chassis to Door • Insert cylinder into “ET” control. • Position exit chassis on door so that lever arm Back out the cylinder set screw is under rear section of mortise lock lever.
  • Page 16 Installation Instructions Mortise Exit Device KP8977 / KP8978 Mortise Installation Instructions for KP8900 Series (Continued) Step #3 Apply Fire Stop Plate (Required for 12-) 5. Fire Stop Plate for 12- Devices • Fire stop plate required on all fire rated doors (12-) •...
  • Page 17 Installation Instructions Mortise Exit Device KP8977 / KP8978 Mortise Installation Instructions for KP8900 Series (Continued) B. Weather Conduit (supplied with Weatherization Kit 52-6084) O-Ring Install weather conduit on NON FIRE-RATED exterior doors* only. 1. Carefully insert weather conduit into ribbon cable hole on inside of door (Fig.
  • Page 18 Installation Instructions Mortise Exit Device KP8977 / KP8978 Mortise Installation Instructions for KP8900 Series (Continued) 6. Insert Wires and Connector • From the outside of the door through the Fire Stop Plate (if required) Wires & connector • For non 12- exit devices feed wire go through fire stop plate harness from keypad assembly through...
  • Page 19 Installation Instructions Mortise Exit Device KP8977 / KP8978 Mortise Installation Instructions for KP8900 Series (Continued) Step #5 Inside Controller Assembly • Plug Keypad connector into inside escutcheon as shown.The back Back- plate can be removed to feed the Keypad plate large connector through slot into connector the circuit board to be assured of...
  • Page 20 Installation Instructions Mortise Exit Device KP8977 / KP8978 Mortise Installation Instructions for KP8900 Series (Continued) Installation Instructions for KP8900 Series (Continued) Step #6 Rail Assembly Install Rail according to installation instruction A6705 Step #7 Battery Installation • Place (4) C size batteries into the compartment •...
  • Page 21 Instructions for Installation of Keypad Rim & Mortise Exit Devices KP8877 / KP8878 KP8977 / KP8978 Programming Instructions The KP Keypad Lock can support 99 users. Each user is assigned a User Number in addition to the code used for entry. Example: USER TYPE USER NUMBER...
  • Page 22 Instructions for Installation of Keypad Rim & Mortise Exit Devices KP8877 / KP8878 KP8977 / KP8978 Programming Instructions (Continued) All of the following procedures start with 99#. If after the last “ ” is depressed, the yellow LED does not go out, depress “ ”...
  • Page 23 Instructions for Installation of Keypad Rim & Mortise Exit Devices KP8877 / KP8878 KP8977 / KP8978 Programming Instructions All of the following procedures start with 99# (continued). If after the last “ ” is depressed, the yellow LED does not go out, depress “*” once more. To Deactivate “Beep”...
  • Page 24 Instructions for Installation of Keypad Rim & Mortise Exit Devices KP8877 / KP8878 KP8977 / KP8978 Programming Instructions Chain Programming of the KP8800 and KP8900 Series Exit Device (including 12-) When programming multiple User Numbers and Codes into the Keypad Exit Device, it is not necessary to leave and re-enter the programming Mode (50) for each entry.
  • Page 25 Instructions for Installation of Keypad Rim & Mortise Exit Devices KP8877 / KP8878 KP8977 / KP8978 All of the following procedures start with 99# (continued). If after the last “ *” is depressed, the yellow LED does not go out, depress “ *” once more. To Interrogate Transaction Log (to output last 15 entries): Hold Data Transfer Device (DTD) up to the (top right side) infrared LED as shown.
  • Page 26 Instructions for Installation of Keypad Rim & Mortise Exit Devices KP8877 / KP8878 KP8977 / KP8978 Programming Instructions All of the following procedures start with 99# (continued). If after the last “ ” is depressed, the yellow LED does not go out, depress “*” once more. To Delete a User Number: •...
  • Page 27 Instructions for Installation of Keypad Rim & Mortise Exit Devices KP8877 / KP8878 KP8977 / KP8978 Troubleshooting Instructions Note: The following tests are used to check basic functionality of the keypad and inside controller. Power On Self Test (POST) for new KP controllers only (released after 1/2021) •...
  • Page 28 The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2014. 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
