Mortise Lock
Installation Instructions
A8151H
04/21
Copyright 2016, 2019, 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Sargent Manufacturing Company is prohibited.
IN
Series
IN120 Wi-Fi
IN220 PoE
Mortise Lock
Installation Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SARGENT IN Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Assa Abloy SARGENT IN Series

  • Page 1 IN220 PoE Mortise Lock Installation Instructions A8151H 04/21 Copyright 2016, 2019, 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
  • Page 2: Table Of Contents

    IN120 / IN220 Mortise Lock Table of Contents Warning ....................3 Regulatory & Power Specifications ............ 4 General Description ................5 Hardware Specifications ..............5 Technical Specifications ..............5 Parts Breakdown ................. 6 Installation Wiring ................8 Door Preparation & Lock Installation ..........12 Installation Instructions ..............
  • Page 3: Warning

    IN120 / IN220 Mortise Lock Warning Changes or modifications to this device not expressly approved by ASSA ABLOY could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4: Regulatory & Power Specifications

    IN120 / IN220 Mortise Lock Regulatory and Power Specifications Electronic Authentication Specifications (Mobile Credentials) For Mobile Credential-Enabled versions of this electronic lock (Indicated by the credential code in the product order string): • Mobile Credentials are transmitted to the lock via Bluetooth Smart or NFC ISO/IEC14443 and must use a mobile device enabled with these technologies.
  • Page 5: General Description

    9-24VDC, 300mA • HID Mobile Access (BLE & NFC) ® • Apple Wallet Seos or DESFire (NFC) ® *For specific security information, please contact your local ASSA ABLOY Door Security Solutions sales consultant or call 800-810-WIRE. 1-800-810-WIRE • www.sargentlock.com • A8151H...
  • Page 6: Parts Breakdown

    IN120 / IN220 Mortise Lock Parts Breakdown Tools Required: • #2 Phillips screwdriver • Flat head screwdriver • Security allen wrench 3a 3b* ITEM No. DESCRIPTION Outside Escutcheon Assembly Inside Mounting Plate Assembly (includes Gasket) PoE Controller Assembly Wi-Fi Controller Assembly* (batteries included) Inside Escutcheon Assembly with Privacy Button AA alkaline batteries (6) *Consult catalog for electronic replacement part numbers...
  • Page 7 IN120 / IN220 Mortise Lock Parts Breakdown (Continued) Door Position Switch (DPS) #41 Mortise cylinder Cylinder Rosette (Thumb)Turn Lock front Lever 7900 Lock body only Trim Pack Outside Trim Inside Inside Lock body (7900) Lever Rose PART NO./ORDER ITEM DESCRIPTION STRING QTY.
  • Page 8: Installation Wiring

    IN120 / IN220 Mortise Lock Installation Wiring for IN220 Power over Ethernet (PoE) Installation Wiring Overview SARGENT IN220 PoE Typical Application Network Cable Surface Mount RJ45 Network Switch (802.3af) EAC Software System A. PoE frame harness assembly B. PoE data hinge from McKinney C.
  • Page 9 IN120 / IN220 Mortise Lock IN220 (PoE) Installation Wiring (Continued) Supplied by CI Certified Integrator (CI) supplies and terminates Supplied by End User the B-Splice connector and the PoE Switch male RJ45 connector from harness to end user provided facility cable B-Splice Patch Cable Crimp Connector...
  • Page 10 IN120 / IN220 Mortise Lock IN220 (PoE) Installation Wiring (Continued) Frame Harness Installation Components and wire harness supplied by McKinney. Suggested installation: Supplied by CI Cut end / ceiling-side PoE harness: B-Splice TIA/EIA 568-B Standard Wiring Crimp Connector Wire Pair Number White/Orange Orange...
  • Page 11 IN120 / IN220 Mortise Lock IN220 (PoE) Installation Wiring (Continued) PoE Door Harness Order of installation may vary. Refer to appropriate sections for instructions. Hinge-side harness connectors: • 4-pin male Molex connector • 6-pin male Molex connector with ground wire Lock-side harness connectors: •...
  • Page 12: Door Preparation & Lock Installation

    IN120 / IN220 Mortise Lock Door Preparation & Lock Installation 1 Prepare Door A. Verify Hand and Bevel of Door Stand on outside of locked door when determining door hand. LHRB RHRB Left Hand Left Hand Right Hand Right Hand Hinges Left Reverse Bevel Hinges Right...
  • Page 13 IN120 / IN220 Mortise Lock 2 Prepare Lock Body 2A Prepare 7900 Lock Body* *If 7900 is type of lock being installed 1. Reverse Lock Hand (If Required) Red surface of locking piece must face the outside/locked side of door. To rotate locking piece (Fig.
  • Page 14 IN120 / IN220 Mortise Lock 2 Prepare Lock Body (Continued) 2B Prepare 8200 Lock Body* *If 8200 is type of lock being installed 1. Reverse Lock Hand (If Required) Red surface of locking piece must face the outside/locked side of door. To rotate locking piece (Fig.
  • Page 15: Installation Instructions

    IN120 / IN220 Mortise Lock Installation Instructions 1 Install Lock Body Note: Do not pull the lock into the pocket using the harness alone. Ensure that the wire harness is not pinched between the lock and the mortise pocket. 1. Feed the wire harness into the mortise pocket and through inside preparation hole (Fig.
  • Page 16 IN120 / IN220 Mortise Lock 2 Outside Cylinder Installation 1. Slide the spring and the rosette onto the cylinder (Fig. 2A). 2. Rotate the cylinder into cylinder hole with fingers. 3. Insert key 75% of the way and utilize the key to rotate the cylinder into the rest of the cylinder hole.
  • Page 17 IN120 / IN220 Mortise Lock 3 Assemble Outside Trim 1. With outside lever horizontal, insert the mounting posts through outside of door and lock body. Make certain the lever spindle is properly engaged inside the lock body (Fig 3A). 2. On the inside of the door, insert spindle into square hole of mortise lock (Fig 3B). 3.
  • Page 18 IN120 / IN220 Mortise Lock 4 Install Inside Rose and Inside Lever Assembly 1. Place inside rose flush against door surface and rotate first counter-clockwise to seat the threads, then clockwise to securely tighten. 2. Slide lever onto spindle until fully seated. Be sure handle is horizontal and facing the hinge side of the door.
  • Page 19 IN120 / IN220 Mortise Lock 5 Install Thumb Turn 1. Insert thumb turn into preparation hole and engage slot in lock body. 2. Orient mounting plate so screw hole is vertical and aligned with Inside of Door preparation holes. 3. Secure plate with Phillips screw provided. 4.
  • Page 20 IN120 / IN220 Mortise Lock 7 Install IN120 / IN220 Outside Reader 1. Orient the reader so the LED lens is at the top. 2. Feed the reader harness through the door (from outside to inside). 3. Install the reader to the outside of door by aligning the mounting posts with the door preparation holes. Hold the reader flush against door while ensuring proper alignment.
  • Page 21 IN120 / IN220 Mortise Lock 8 Install Mounting Plate Assembly 1. Next feed the cables/connectors through the inside mounting plate assembly and gasket*. 2. Secure the mounting assembly while ensuring proper alignment of outside reader and partially tighten the (2) through-bolts on the inside of the door to secure the reader (Fig. 8A). Gasket* NOTE: Cable lengths exaggerated for illustrative purposes.
  • Page 22 IN120 / IN220 Mortise Lock 9 Preparation of Connectors Important Note: Before you secure the connectors CAUTION - Do not touch or allow debris to enter connector contacts. (grease)* Ensure connectors are covered with silicone dielectric compound SILICONE DIELECTRIC APPLY COMPOUND FILL FILL...
  • Page 23 IN120 / IN220 Mortise Lock 10 Installation of Connectors (Continued) Important Note: If you are installing IN220 (PoE)*: E. Pull 5 1/2 inches of Ethernet cable from hole. Strip cable jacket back 3 1/2 inches. F. Separate (untwist) and straighten (8) Ethernet wires before carefully feeding through ferrite bead (Fig.
  • Page 24 IN120 / IN220 Mortise Lock 11 Installing the Controller (Continued) Important Note: Before you install the controller 1. Insert bottom tab of controller (ensure a clear path) into slot on mounting plate (Fig. 11D, E). 2. Ensure proper alignment of board-to-board connectors (Fig. 11E) while pivoting controller toward door until two tabs on top click securely into place on mounting plate (Fig.
  • Page 25 IN120 / IN220 Mortise Lock B. IN120 (WIFI) 1. Once controller is securely in place, place (6) “AA” alkaline batteries in the compartment, being care- ful to align polarity properly. 2. After batteries are installed, there is a slight delay; then an audible “beep”...
  • Page 26 IN120 / IN220 Mortise Lock 14 Inside Cover Installation 1. Assemble cover by hooking top edge on inside mounting plate taking care not to pinch gasket (top edge goes between plate and gasket). 2. Carefully press bottom of cover toward door without pinching any wires. 3.
  • Page 27: Operational Check

    IN120 / IN220 Mortise Lock Operational Check For 7976-, 7978-, 82276- and 82278-function mortise locks with cylinders: 1. Insert key into cylinder and rotate. There should be no friction against lock case, wire harness or any other obstructions. 2. Check that the key retracts the latch: the key should rotate freely.
  • Page 28 The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2016, 2019, 2021, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
