Installation Instructions
Attention Installer:
Please read these instructions carefully to prevent missing important steps.
Improper installations may result in damage to the lock and void the factory warranty.
The accuracy of the door preparation is critical for proper functioning and security of this lock.
Misalignment can cause premature wear and a lessening of security.
For specific security information, please contact your local ASSA ABLOY
Door Security Solutions sales consultant or call 800-810-WIRE.
Copyright © 2020-23 Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights
reserved. Reproduction in whole or in part without the express written permission of Sargent
Manufacturing Company is prohibited. Patent pending and/or patent - www.assaabloydss.com/patents.
HID, iCLASS, and Edge are trademarks or registered trademarks of HID Global Corporation.
SN
Series
SN200 Wiegand
SN210 OSDP
Bored Lock
A8282B 01/23

Advertisement

loading
Need help?

Need help?

Do you have a question about the SARGENT SN Sereis and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Assa Abloy SARGENT SN Sereis

  • Page 1 For specific security information, please contact your local ASSA ABLOY Door Security Solutions sales consultant or call 800-810-WIRE. Copyright © 2020-23 Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
  • Page 2: Table Of Contents

    SN200/210 Bored Lock Table of Contents Regulatory Compliance ........3 Warning ..............3 Specifications ............4 Parts Breakdown ..........5 Wiring Diagrams ..........7 Installation Instructions ........11 Operational Check ..........19 A8282B • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 3: Regulatory Compliance

    SN200/210 Bored Lock Regulatory Compliance Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4: Specifications

    SN200/210 Bored Lock Specifications • UL Listed* - UL 294 Indoor Use • UL 294 Access Control Ratings: • CUL Listed - S319: Class 1 Destructive Attack Level 1 • ANSI/BHMA A156.25 Listed Grade Line Security Level 1 1 Compliant Endurance Level 4 *UL294, S319, &...
  • Page 5: Parts Breakdown

    SN200/210 Bored Lock Parts Breakdown ITEM Description Req. Reader & Harness Assembly Signo Reader Back Plate Screw Pack SN200/210 Standard Fire Kit Inside Mounting Plate Inside Escutcheon A8282B • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 6 SN200/210 Bored Lock Parts Breakdown (Continued) 11 * Adapter Plate/Spacer is only shipped with orders that specify 1-3/8” doors. ITEM DESCRIPTION REQ. Refer to SN200/210 Catalog for Available Lever Styles Refer to SN200/210 Catalog for Available Cylinders Outside Rose Spring Assembly Adapter Plate (inside/outside): Only shipped with 1-3/8"...
  • Page 7: Wiring Diagrams

    SN200/210 Bored Lock Wiring Diagrams Product 8 PIN CONNECTOR 4 PIN CONNECTOR 1-Black 2-Red 3-White 4-Green 5-Orange 6-Blue 7-Brown 8-Yellow 1-Violet 2-Gray 3-Pink 4-Tan ACCESS CONTROL DEVICES: SN200/210 Lockset, ElectroLynx wire Color / Function assignments 12VDC Communication 12/24 VDC EGND Function* (Reader) Type...
  • Page 8 SN200/210 Bored Lock Wiring Diagrams (Continued) SN200 Wiegand UL294/TAMPER Configuration Application Diagram #1 Tamper will trigger when reader is removed from door and tamper wiring is connected at the panel. 12/24VDC System Average Peak Average Peak Reader* 75mA 250mA Actuator 500mA 500mA 250mA...
  • Page 9 SN200/210 Bored Lock Wiring Diagrams (Continued) SN200 Wiegand Non-UL294 Configuration Application Diagram #2 Connect GREEN_LED input to switch controlled by panel. Shorting GREEN_LED to READER_NEG (Black) with panel switch will override reader LED to keep it green. 12/24VDC System Average Peak Average Peak...
  • Page 10 SN200/210 Bored Lock Wiring Diagrams (Continued) SN210 OSDP Application Diagram #3 (12/24VDC System) OSDP Operation Mode*: *LED/Sounder control and Tamper status communicated over OSDP serial protocol PIN 8 (Yellow – n/a) PIN 6 (Blue – RX COM) PIN 4 (Green – RS-485A) PIN 4 (Tan –DPS COM ) PIN 2 (Red –...
  • Page 11: Installation Instructions

    SN200/210 Bored Lock Installation Instructions 1 Door Preparation A. Verify Hand and Bevel of Door Stand on outside of locked door when determining door hand. Left Hand Left Hand Right Hand Right Hand Hinges Left. Reverse Bevel Hinges Right. Reverse Bevel Open Inward.
  • Page 12 SN200/210 Bored Lock 2 Concealed Door Position Switch (3287) Instructions Wiegand or OSDP Use SARGENT 3287 Concealed Door Position Switch with this Access Control System SN200/210 10-Line Product: 1. Install the 3287 Concealed Door Position Switch described in SARGENT document A7448. 2.
  • Page 13 SN200/210 Bored Lock 5 Install Reader Backplate and (Optional*) Fire Shield 1. For fire-rated doors only, install reader backplate and fire shield to door using two (2) #8-18 x 5/8” Phillips flat head self-drilling screws (Fig. 5). 2. For exterior doors, install reader backplate using two (2) #8-18 x 5/8” Phillips flat head self- drilling screws (Fig.
  • Page 14 SN200/210 Bored Lock 6 Installation of SN200/210 Reader Observe precautions for handling electrostatic sensitive devices. 1. Feed reader harness through door (Fig. 6A). 2. Hook the top of the reader on the top of the mounting plate (Fig. 6B). 3. Align the bottom of the reader with the bottom of the mounting plate. 4.
  • Page 15 SN200/210 Bored Lock 7 How to Remove Outside Lever (If Necessary) 1. Insert key, rotate 45° clockwise and hold Outside of Door (Fig. 7A, B). 2. Depress lever retainer with push pin tool (provided). 3. Reverse this procedure to reassemble. Note: Be sure spacer is installed on the back of cylinder plug.
  • Page 16 SN200/210 Bored Lock 9 Install Lock Body (Continued) C. Install Lock: 1. Feed wires into the lock body hole, from outside of door (Fig. 9B). 2. With outside lever horizontal, insert the mounting post through outside of door and lock body. Inside 3.
  • Page 17 SN200/210 Bored Lock 11 Wire Connections Do not offset connectors and ensure that they are completely seated. 1. Connect 6-pin connector from lock body to 6-pin connector on reader harness (Fig. 11A). 2. Connect 2-pin connector from lock body to 2-pin connector on reader harness (Fig. 11A). Fig.
  • Page 18 SN200/210 Bored Lock 12 Fire Plate Installation and Earth Ground Connection 1. Remove lower left screw from mounting plate. Feed screw through green/yellow ground wire ring terminal. Reinstall screw. Ensure that green/yellow wire points toward top of door in order to avoid interference with escutcheon. 2.
  • Page 19: Operational Check

    SN200/210 Bored Lock Operational Check Wiegand Test Unit The ASSA ABLOY Wiegand Test Unit verifies your installation in the field*. The test unit checks for: Feature • proper wiring 12 or 24VDC solenoid lock voltage adjustable • card reader data integrity •...
  • Page 20 SN200/210 Bored Lock Operational Check (Continued) Note: Once electrical wiring has been successfully completed according to proper application, perform the following steps: 1. Ensure lock is interfaced with Wiegand Test Unit to verify installation and wiring up to (frame side) point of hinge. 2.
  • Page 21 SN200/210 Bored Lock A8282B • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 22 SN200/210 Bored Lock A8282B • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 23 SN200/210 Bored Lock A8282B • 800-810-WIRE (9473) • www.sargentlock.com...
  • Page 24 New Haven, CT 06511 USA 800-727-5477 • www.sargentlock.com Copyright © 2020-23 Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited. Patent pending and/or patent - www.assaabloydss.com/patents.
