Profile
PoE Mortise Lock
Installation Instructions
To view helpful video installation tips, scan the
Microsoft® Tags with your mobile phone.
Download the free mobile app at
http://getscanlife.com.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Assa Abloy Sargent Profile Series
Summary of Contents for Assa Abloy Sargent Profile Series
-
Page 1: Installation Instructions
Microsoft® Tags with your mobile phone. Download the free mobile app at http://getscanlife.com. A7764D 03/15 Copyright 2015, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited. -
Page 3: Table Of Contents
Installation Wiring Overview ...........4 Installation Wiring ..............5 Parts Breakdown ..............9 Lock Installation ..............11 Changes or modifications to this unit not expressly approved by ASSA ABLOY Inc. Warning could void the user’s authority to operate the equipment. FCC: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. -
Page 4: General Description
Profile Series v.S1 PoE Mortise Lock General Description The SARGENT Profile Series v.S1 Mortise Lock* is available with either an HID 125 kHz prox or 13.56 MHz ® iCLASS technology reader. It utilizes existing infrastructure and IEEE 802.3af PoE (Power over Ethernet) ®... -
Page 5: Installation Wiring
Profile Series v.S1 PoE Mortise Lock Installation Wiring PoE frame harness assembly (From McKinney) DPS: Door Position Switch (cylindrical and exits only) PoE data hinge (Patent Pending) (From McKinney) Profile Series v.S1 Online P1 PoE lock PoE door harness* (From McKinney) * Order of installation may vary. - Page 6 Profile Series v.S1 PoE Mortise Lock Frame Harness Installation Cut end / ceiling-side PoE harness: Supplied by CI Suggested installation of components and wire harness supplied by McKinney: B-Splice Crimp Connector TIA-568-B Standard Wiring Pair Number Wire White/Blue White/Blue Blue RJ45-M White/Orange Ceiling...
- Page 7 Profile Series v.S1 PoE Mortise Lock Door Harness Installation Ground Order of installation may vary. Ring Terminal Refer to appropriate sections for instructions. 1. Prop door open. JST 4-Pin From Hinge 2. Tape the two lock-side 4-pin connectors to the ring terminal. 3.
- Page 8 Profile Series v.S1 PoE Mortise Lock PoE Lock Wiring Ground Ring Terminal (From Hinge to Top Left Escutcheon Screw) J P 4 J P 4 T P 7 T P 7 C 2 1 C 2 1 T P 8 T P 8 R 2 1 R 2 1...
-
Page 9: Parts Breakdown
Profile Series v.S1 PoE Mortise Lock Parts Breakdown 125 kHz Prox and 13.56 MHz iCLASS *Patent Pending 1-800-810-WIRE • www.sargentlock.com • A7764D... - Page 10 Profile Series v.S1 PoE Mortise Lock Parts Breakdown 125 kHz Prox and 13.56 MHz iCLASS, continued ITEM PART NO. DESCRIPTION QTY. Outside Lever Reference 8200 Catalog for available levers Inside Lever Reference 8200 Catalog for available levers 82-0493 O/S Escutcheon only with Cylinder 82-0495 O/S Escutcheon only without Cylinder 82-0492...
-
Page 11: Lock Installation
Profile Series v.S1 PoE Mortise Lock Lock Installation 1 – Door Preparation A. Verify Hand and Bevel of Door Stand on outside of locked door when determining door hand. LHRB RHRB Left Hand Left Hand Right Hand Right Hand Hinges Left Reverse Bevel Hinges Right Reverse Bevel... - Page 12 Profile Series v.S1 PoE Mortise Lock 2 – How to Change Hand of Lockbody A. Reverse Lock Hand Red surface of locking piece must face the outside/ locked side of door. To rotate locking piece (Fig. 2A): Right Hand 1. Position lock body with red surface of locking piece Lock Shown visible.
- Page 13 Profile Series v.S1 PoE Mortise Lock 3 – Install Lock Body 1. Insert lock body into mortised cutout (Fig. 3A). Ground Wire 2. Harness exits non-cylinder side of hole. 3. Hold lock body loosely in place with (2) lock (2) 4-Pin body screws (Fig.
- Page 14 Profile Series v.S1 PoE Mortise Lock 5 – Install Gasket (for Exterior Doors) Gasket 82-0500 1. Carefully remove the backing from the gasket. 2. Apply gasket to escutcheon: Gasket • Starting in one place, press the adhesive side of the gasket firmly against the escutcheon. •...
- Page 15 Profile Series v.S1 PoE Mortise Lock 7 – Install and Secure Cylinder (Optional) 1. Thread cylinder into lockbody, rotating the cylinder clockwise (Fig. 7A). Cylinder should be flush with escutcheon. Outside of Door Note: The 43 cylinder may be used when installing this product with or without a gasket.
- Page 16 Profile Series v.S1 PoE Mortise Lock 8 – Escutcheon Wire Connections Tabs Images are shown without gasket. If gasket is necessary, refer to 5. Before the controller is attached to the door: 1. Remove the cover from the inside escutcheon by removing the security screw with the provided tool (Fig.
- Page 17 Profile Series v.S1 PoE Mortise Lock 9 – Install Inside Escutcheon Lock, DPS and raceway wire connections: Inside of Door 1. Connect the cable from the mortise lock to the bottom of the controller assembly (Fig. 9A). 2. Connect the AX/DPS connector to the 2-pin harness.
- Page 18 Profile Series v.S1 PoE Mortise Lock 10 – Install Inside Lever 1. Slide lever handle onto spindle until fully seated (Fig. 10). 2. Tighten the set screw securely with 1/8” hex wrench. Inside of Door Scan to see a video of this installation step.
- Page 19 Profile Series v.S1 PoE Mortise Lock 12 – Operational Check 1. Test the thumbturn by retracting and projecting the deadbolt. 2. Perform an operational check of the key pad by pressing each button and hearing a “beep” after each number pressed. A double beep will sound after the asterisk is pressed.
- Page 20 The company’s customer base includes commercial construction, institutional, and industrial markets. Copyright © 2015, Sargent Manufacturing Company, an ASSA ABLOY Group company. All rights reserved. Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
