GE EST iO64 Technical Reference Manual page 253

Advanced: Panel configuration menu
Adv
Panel
Config
Panel Configuration
Panel NAC
Ann. Class A<>
Annunciator
CMS Device
Printer
IP 192.168.001.001
MSK 255.255.255.000
GWY 192.168.001.100
Lock Rmt Read Yes<>
Ac Voltage 120<>
Save
Adv
Panel
Config
CMS Dev
Annunciator
Annunciator 01
Annunciator 02
Annunciator 03
Annunciator 04
Annunciator 05
Annunciator 06
Annunciator 07
Annunciator 08
Annunciator X
Type Off<>
Expanders 1
Label
Event Notification
Save
EST iO64 and iO500 Technical Reference Manual
Panel NAC
NAC
Correlation Groups
Group 01
Group 02
Group 03
...
Group 32
Save
Event Notification
Trouble
Disable
Test
Label
aaaaaaaaaaaaaaaaaaaa
aaaaaaaaaaaaaaaaaaaa
<-Save <-Back
Trouble
Printer Yes<>
Dialer Account1&2<>
NET Yes<>
CID 110
Save
Appendix C: Front panel menu flowcharts
NAC X
Class
1
Type Cont.Non Sil<>
Label
Correlation Groups
Event Notification
Save
Label
Yes<>
aaaaaaaaaaaaaaaaaaaa
Yes<>
aaaaaaaaaaaaaaaaaaaa
Yes<>
<-Save
Yes<>
Notification
Printer
Dialer Account1&2<>
NET
CID
Save
Printer
Type Supervised<>
Event Notification
Save
Trouble
Printer
Dialer Account1&2<>
NET
CID
Save
A<>
>
<-Back
Yes<>
Yes<>
110
Yes<>
Yes<>
110
243
