  • Page 1  NetworX Series NX-8E Control Panel Installation and Startup...
  • Page 2 GE Interlogix, Gladewater, Texas, USA. This document contains proprietary information of GE Interlogix, USA and is furnished to its customer solely to assist that customer in the installation, testing, operations, and/or maintenance of the equipment described.

  • Page 3: Table Of Contents

    Table of Contents GENERAL DESCRIPTION...........................3 ORDERING INFORMATION ........................3 III. GLOSSARY..............................4 PROGRAMMING THE LED KEYPADS .......................8 PROGRAMMING THE CONTROL......................10 ENTERING THE PROGRAM MODE ....................10 SELECTING THE MODULE TO PROGRAM..................10 PROGRAMMING A LOCATION......................10 EXITING A LOCATION ........................10 EXITING THE PROGRAM MODE .....................10 PROGRAMMING DATA ..........................12 NUMERICAL DATA..........................12 FEATURE SELECTION DATA......................12...
  • Page 4 SAFETY SYMBOL LEGEND Indicates a procedure, practice, condition, or statement that, if not strictly observed, could result in personal injury. Warning * This symbol indicates electrical warnings and cautions. Indicates a procedure, practice, condition, or statement that, if not strictly observed, could result in damage to or destruction of equipment or property.

  • Page 5: General Description

    GENERAL DESCRIPTION The NetworX NX-8E represents a new approach to security systems design. Drawing on our experience in the world market as the largest exporter of USA manufactured controls, we have developed the most flexible, durable, and user- friendly control ever seen in our industry. Featuring sophisticated software, which allows up to 240 users to interface with 192 zones, 8 partitions, and a host of integrated fire, access, verification, and input/output modules, all reported with the most comprehensive and fast SIA and Contact ID formats.

  • Page 6: Glossary

    III. GLOSSARY Abort - If enabled, the NX-8E will wait the programmed number of seconds in location 40 prior to sending an alarm. During this delay time, the "Cancel" LED will flash. To abort the report, type in a code and press the [Cancel] key. The LED will extinguish.
  • Page 7 Code Required Options- The NX-8E can be programmed to require a code for bypassing zones and/or initiating a download using the [r]-[9]-[8] or [r]-[9]-[9] function. (See locations 23 and 41, pages 18 and 23) Communication Formats- The NX-8E can report in multiple formats. It is recommended that you use Contact ID or SIA formats if possible.
  • Page 8 Group Bypass - A designated group of zones can be programmed to bypass by pressing [Bypass]- [0]-[Bypass]- [Bypass] prior to arming. (See locations 111-169, pages 33-37) NOTE: For UL installations, this feature shall be disabled. Immediate Restore By Zone- The NX-8E can be programmed to send alarm and restore reports as soon as they occur, or wait until the siren time has expired.
  • Page 9 Siren Blast For Arming- The NX-8E can be programmed to give a one-second siren blast when the panel is armed, at the end of the exit delay, or when the central station receiver acknowledges the closing report. It can also give one blast for remote (keyswitch) arming and two blasts for remote disarming.

  • Page 10: Programming The Led Keypads

    PROGRAMMING THE LED KEYPADS This section describes how to program the address and partition of each keypad as well as the options that are available. The address of the keypad is important because this is how the panel supervises the keypads. The factory default for the Master code is [1]-[2]-[3]-[4] when using a 4-digit code or [1]-[2]-[3]-[4]-[5]-[6] for a 6-digit code.
  • Page 11 CHANGING USER CODES: 1) Enter [r]-[5]-[master code] - The "Ready" LED will flash. 2) Enter the 3 digit user number (i.e. “003 for user 3). Maximum number of users is 240. 3) Enter the new user code designated for that individual - The "Ready" LED will flash indicating that the code was accepted.

  • Page 12: Programming The Control

    PROGRAMMING THE CONTROL ENTERING THE PROGRAM MODE To enter the Program Mode, press [r]-[8]. At this time, the five function LEDs (Stay, Chime, Exit, Bypass, & Cancel) will begin to flash. Next, enter the "Go To Program Code" (FACTORY DEFAULT IS [9]-[7]-[1]-[3]). If the "Go To Program Code"...
  • Page 13 PROGRAMMING EXAMPLE TO BE INSERTED HERE. NX-8E CONTROL...

  • Page 14: Programming Data

    PROGRAMMING DATA Programming data is always one of two types. One type of data is numerical and can take on values from 0 to 15 or 0 to 255 depending on the location's segment. The other type of data is a feature selection type. Feature selection data is used to turn features on or off.

  • Page 15: Programming Locations

    PROGRAMMING LOCATIONS LOCATION 0 - PHONE NUMBER 1 (20 segments, numerical data) The first telephone number is programmed in location 0. A "14" indicates the end of the phone number. Delays of four seconds can be programmed at any point in the phone number by programming a "13" in the appropriate segment. If tone dialing is desired, program a "15"...

  • Page 16: Reporting Events To Phone Number 1

    number of attempts have been made to Phone #1. If a "2" is programmed in this segment, it will cause the NX-8E to make the dial attempts in increments of two. The first two attempts will be made to Phone #1, the next two attempts to Phone #2, then repeating until the total number of attempts designated in Segment 1 is completed.

  • Page 17: Reporting Events To Phone Number 2

    LOCATION 8 - COMMUNICATOR FORMAT FOR PHONE # 2 (1 segment, numerical data) Location 8 contains the communicator format used to transmit to the receiver connected to Phone #2. Consult the instruction manual for your central station receiver to determine which format is compatible, and select from Table X-1 COMMUNICATOR FORMAT SELECTIONS on page 13.

  • Page 18: Reporting Events To Phone Number 3

    LOCATION 11 - PARTITIONS REPORTED TO PHONE #2 (1 segment, feature selection data) Location 11 is used when events to be reported to a phone number are based upon the partition regardless of the event. If this location is used, location 10 should be "0". Segment 1: 1 = Partition #1 3 = Partition #3...
  • Page 19 LOCATION 16 - EVENTS REPORTED TO PHONE #3 (2 segments, feature selection data) Segment 1: 1 = Alarms and Alarm Restores. 2 = Opening and Closings. 3 = Zone Bypass and Bypass Restores. 4 = Zone Trouble and Trouble Restores. 5 = Power Fail, Low Battery, Power Restore, and Low Battery Restore.
  • Page 20 LOCATION 21 - DOWNLOAD CONTROL (1 segment, feature selection data) Location 21 contains the feature selections for the controlling of download sessions. The following features can be enabled or disabled using this location. (See the feature definitions beginning on page 3) Segment 1: On enables two call answering machine defeat.

  • Page 21: Default Zone Types (Configurations)

    Segment 4: 1 – On enables Late to Close / Early to Open. 2 – On enables Auto Arm in Stay Mode. 3 – On disables the door delays in Night mode. (Applies to NX1208E / NX1248E) 4 - 8 Reserved. Segment 5: Reserved LOCATION 24 - ENTRY / EXIT TIMERS (6 segments, numerical data)
  • Page 22 DATA DESCRIPTION OF DEFAULT ZONE TYPES INTERIOR FOLLOWER WITH GROUP BYPASS ENABLED - This zone will be instant when the system is armed and no entry or exit delays are being timed. It is delayed during entry/exit delay times. This zone will bypass when the "Group Bypass"...
  • Page 23 LOCATION 27 - ZONES 9-16 ZONE TYPE (8 segments, numerical data) Location 27 contains the Zone Type for zones 9 -16. Segment 1 is for zone 9; Segment 8 is for zone 16. Default Zone Types are found in the table on page 19. To customize a Zone Type, see page 33. LOCATION 28 - PARTITION SELECT, ZONES 9-16 (8 segments, feature selection data) Location 28 is used to select the partition(s) that zones 9-16 reside in.
  • Page 24 LOCATION 35 - ZONES 41-48 ZONE TYPE (8 segments of numerical data) Location 35 contains the Zone type for zones 41-48. Segment 1 is for zone 41 Segment 8 is for zone 48. Default Zone Types are found in the table on page 19. To customize a Zone Type, see page 33. LOCATION 36 - PARTITION SELECT, ZONES 41-48 (8 segments, feature selection data) Location 36 is used to select the partition or partitions that zones 41-48 reside in.
  • Page 25 Segment 6: 1 = Enable 2 wire smoke. 2 = Reserved. 3 = Enable for Zone Activity in Hours (not Days) 4 = Enable Daylight Savings Time (DST) 5 = Reserved 6 = On to disable Clean Me report (Clean Me report is enabled at default) 7-8 = Reserved.
  • Page 26 LOCATION 42 - GO TO PROGRAM CODE (6 segments, numerical data) Location 42 contains the "Go To Program Code". This location contains either a 4 or 6-digit code. If the 6-digit code option is enabled in Location 41, THIS CODE MUST CONTAIN SIX (6) DIGITS. If this option is not enabled in location 41, the last 2 segments (digits) will be ignored.
  • Page 27 LOCATION 47 - AUXILIARY OUTPUT #1, EVENT AND TIME (2 segments, numerical data) Segment 1: Use the chart on page 25 to select the event that will activate Auxiliary Output 1. Segment 2: Program the timing from 0-255 (minutes or seconds, depending on data programmed in Segment 1, Location 46).
  • Page 28 LOCATION 51 - AUTOTEST CONTROL (4 segments, numerical data) Program a "1" if the interval is to be in hours; Program a "0" if in days. Add a A2" to suppress Segment 1: the daily test or a A3" to suppress the hourly test if any report has been sent. Segment 2: Program the Autotest interval from 1-255 hours/days.
  • Page 29 SLOW COMMUNICATOR FORMAT CODES LOCATIONS 56- 83 ARE ONLY USED WHEN REPORTING EVENTS TO A PAGER OR USING A SLOW FORMAT SUCH AS 4+2. WHEN USING CONTACT ID OR SIA, THERE IS NO NEED TO PROGRAM THESE LOCATIONS. The digit programmed in each of the following locations will be sent as the upper HEX digit in place of the alarm event code.
  • Page 30 SLOW COMMUNICATOR FORMAT CODES LOCATION 64 - KEYPAD AUXILIARY 2 COMMUNICATOR CODE (2 segments, numerical data) Location 64 contains the digits that will be sent for a 4+2 format if the keypad "Auxiliary 2" (Medical) is enabled in the partition feature selection. Refer to the box at the top of page 27. LOCATION 65 - KEYPAD PANIC COMMUNICATOR CODE (2 segments, numerical data) Location 65 contains the digits that will be sent for a 4+2 format if the keypad "Panic"...
  • Page 31 SLOW COMMUNICATOR FORMAT CODES LOCATION 74 - EXPANDER TROUBLE / EXPANDER TROUBLE RESTORE COMMUNICATOR CODES (4 segments, numerical data) Location 74 contains the digits for a 4+2 format that will be sent if "Expander Trouble Reporting" is enabled. Segments 1 & 2 contain the digits of the "Expander Trouble Reporting". Segments 3 & 4 contain the digits of the "Expander Trouble Restore".
  • Page 32 LOCATIONS 88-109 ARE FOR PROGRAMMING DIFFERENT ACCOUNT CODES AND/OR FEATURES FOR EACH PARTITION. IF A LOCATION IS LEFT UNPROGRAMMED, THE FEATURE FOR PARTITION 1 AND ACCOUNT CODE FOR THE PHONE NUMBER WILL BE USED. LOCATION 88 - ACCOUNT CODE FOR PARTITION 1 (6 segments, numerical data) Location 88 contains the account code sent when partition 1 is reported.
  • Page 33 LOCATION 95 - ACCOUNT CODE FOR PARTITION 4 (6 segments, numerical data) The account code sent when partition 4 is reported is programmed in location 95. If location 95 is left unprogrammed (all A10") then the account code corresponding to the Phone number dialed will be used. If the account code is less than six digits, program a A10"...
  • Page 34 LOCATION 103 - PARTITION 6 ENTRY EXIT TIMERS (6 segments, numerical data) Location 103 is used to enter in seconds the Entry and Exit times. There are 2 separate entry and exit times. Valid entries are 10-255 seconds. If all segments are A0", the entry and exit times for partition 1 will be used. Segment 1, Entry Time 1: Entry time that will be used when a Delay 1 zone type initiates an entry delay.
  • Page 35 LOCATIONS 110-169 ARE USED TO CHANGE THE ZONE TYPES (Configurations) AS LISTED IN THE TABLE ON PAGE 19. THESE LOCATIONS ARE CONSIDERED ADVANCED PROGRAMMING AND SHOULD ONLY BE CHANGED WITH A THOROUGH UNDERSTANDING OF THE OPERATION OF EACH BIT. LOCATION 110 - ZONE TYPE 1 ALARM EVENT CODE (1 segment, numerical data) Location 110 contains the event code sent for a Contact ID or SIA report.
  • Page 36 LOCATION 116 - ZONE TYPE 4 ALARM EVENT CODE (1 segment, numerical data) Location 116 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on page 70. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 33 for details.
  • Page 37 LOCATION 132 - ZONE TYPE 12 ALARM EVENT CODE (1 segment, numerical data) Location 132 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on page 70. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 33 for details.
  • Page 38 LOCATION 146 - ZONE TYPE 19 ALARM EVENT CODE (1 segment, numerical data) Location 146 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on page 70. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 33 for details.
  • Page 39 LOCATION 160 - ZONE TYPE 26 ALARM EVENT CODE (1 segment, numerical data) Location 160 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on page 70. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 33 for details.
  • Page 40 LOCATION 173 - PARTITION SELECT, ZONES 57-64 (8 segments of feature selection data) Location 173 is used to select the partition(s) that zones 57-64 reside in. A zone may reside in any combination of the 8 partitions. If a burglary zone resides in more than 1 partition, it will only be active when all partitions are armed.
  • Page 41 LOCATION 181 - PARTITION SELECT, ZONES 89-96 (8 segments of feature selection data) Location 181 is used to select the partition(s) that zones 89 - 96 reside in. A zone may reside in any combination of the 8 partitions. If a burglary zone resides in more than 1 partition, it will only be active when all partitions are armed.
  • Page 42 Segments 1 - 8: 1 = Partition #1 3 = Partition #3 5 = Partition #5 7 = Partition #7 2 = Partition #2 4 = Partition #4 6 = Partition #6 8 = Partition #8 LOCATION 190 - ZONES 129-136 ZONE TYPE (8 segments, numerical data) Location 190 contains the Zone Type for zones 129-136.
  • Page 43 LOCATION 198 - ZONES 161-168 ZONE TYPE (8 segments, numerical data) Location 198 contains the Zone Type for zones 161-168. Segment 1 is for zone 161; Segment 8 is for zone 168. Default Zone Types are found in the table on page 19. To customize a Zone Type, see page 33. LOCATION 199 - PARTITION SELECT, ZONES 161-168 (8 segments of feature selection data) Location 199 is used to select the partition(s) that zones 161-168 reside in.
  • Page 44 LOCATION 206 – AUTO DISARM DAY SELECTOR (8 segments of feature selection data) Location 206 selects which days each partition will auto disarm. Segment 1 is for partition 1, and segment 8 is for partition 8. If a zone is faulted when the panel tries to auto disarm, the zone will be bypassed. Segments 1-8: 1 - Auto Disarming on Sunday.
  • Page 45 LOCATION 211 - PROGRAMMING THE COMMAND/REQUEST ENABLES (4 segments of feature selection data) The NX-8E has the ability to perform a variety of commands asked of it by the home automation system. For example, it is possible to allow arming and disarming of the security system, programming of the security system, or bypassing of zones by the home automation system.
  • Page 46 LOCATION 212 - PROGRAMMING THE LCD KEYPAD ADDRESS (1 segment of numerical data) Certain commands in the NX-8E require it to know the location of at least 1 LCD keypad (if one exists in the system). If your system has an LCD keypad it is recommended that it be placed in partition 1 keypad 1. This will allow location 212 to be left at the factory default.

  • Page 47: Programming Worksheets

    XII. PROGRAMMING WORKSHEETS (Factory defaults for segments are in bold italics text and "Quick Start" locations are identified with the L symbol.) DESCRIPTION DEFAULT PROGRAMMING DATA PHONE #1 14-14-14-14-14-14-14-14-14- __ __ __ __ __ __ __ __ __ __ 14-14-14-14-14-14-14-14-14- __ __ __ __ __ __ __ __ __ __ 14-14 PHONE #1, ACCOUNT CODE...
  • Page 48 DESCRIPTION DEFAULT PROGRAMMING DATA PHONE #3, REPORTING FORMAT PHONE #3, DIAL ATTEMPTS BACKUP CONTROL PHONE #3, SELECTING EVENTS TO REPORT TO PHONE #3 Segment #1 (Circle Numbers To Program) Segment #2 (Circle Numbers To Program) Alarms and Restores Tampers Open/Close Short Circuit &...
  • Page 49 DESCRIPTION DEFAULT PROGRAMMING DATA PARTITION #1, FEATURE SELECTION Segment #1 1 = Quick Arm 5 = Audible Panic 2 = Re-Exit 6 = Auxiliary 1 3 = Auto Bypass 7 = Auxiliary 2 4 = Silent Panic 8 = Multi Keypress Tamper Segment #2 1 = LED extinguish enable 5 = Enables bypass toggle...
  • Page 50 DESCRIPTION DEFAULT PROGRAMMING DATA ZONES 17-24, ZONE TYPES 6-6-6-6-6-6-6-6 _ _ _ _ _ _ _ _ ZONES 17-24, PARTITION SELECTION (Segment 1=Zone 17 thru Segment 8=Zone 24) Segments Partition #1 Partition #2 Partition #3 Partition #4 Partition #5 Partition #6 Partition #7 Partition #8 ZONES 25-32, ZONE TYPES...
  • Page 51 DESCRIPTION DEFAULT PROGRAMMING DATA SIREN AND SYSTEM SUPERVISION Segment #1 (Circle numbers to program) Siren sounds for telephone line cut while armed. Siren sounds for telephone line cut while disarmed. Siren blast at arming. Siren blast at exit delay expiration. Siren blast at closing kissoff.
  • Page 52 DESCRIPTION DEFAULT DATA SWINGER SHUTDOWN COUNT KEYPAD SOUNDER CONTROL Segment #1 (Circle numbers to program) Keypad sounds for Telephone Line Cut when in the Armed state. Keypad sounds for Telephone Line Cut when in the Disarmed state. Keypad sounds upon AC Power Failure. Keypad sounds upon Low Battery Detection.
  • Page 53 DESCRIPTION DEFAULT DATA Segment #2 (Circle numbers to program) Enables "Go To Program Code" for partition #1. Enables "Go To Program Code" for partition #2. Enables "Go To Program Code" for partition #3. Enables "Go To Program Code" for partition #4. Enables "Go To Program Code"...
  • Page 54 DESCRIPTION DEFAULT DATA OPENING TIME Segment #1: Program the hour of the opening time. Segment #2: Program the minutes after the hour of the opening time. CLOSING TIME / AUTO ARMING TIME Segment #1: Program the hour of the closing time / auto arming time.
  • Page 55 DESCRIPTION DEFAULT DATA BYPASS COMMUNICATOR CODE, SLOW SPEED FORMATS ONLY Segment #1: Partition #1 Bypass code Segment #2: Partition #2 Bypass code Segment #3: Partition #3 Bypass code Segment #4: Partition #4 Bypass code Segment #5: Partition #5 Bypass code Segment #6: Partition #6 Bypass code Segment #7: Partition #7 Bypass code Segment #8: Partition #8 Bypass code...
  • Page 56 DESCRIPTION DEFAULT DATA LOW BATTERY / LOW BATTERY RESTORE 0-0-0-0 _ _ _ _ POWER SHORT / POWER SHORT RESTORE 0-0-0-0 _ _ _ _ BELL TAMPER / BELL TAMPER RESTORE 0-0-0-0 _ _ _ _ TELEPHONE LINE CUT / LINE CUT RESTORE 0-0-0-0 _ _ _ _ GROUND FAULT / GROUND FAULT RESTORE...
  • Page 57 DESCRIPTION DEFAULT DATA PARTITION 2 ENTRY/EXIT TIMERS Segment #1 (Entry Time #1) Segment #2 (Exit Time #1) Segment #3 (Entry Time #2) Segment #4 (Exit Time #2) Segment #5 & #6 RESERVED PARTITION 3, ACCOUNT CODE 10-10-10-10-10-10 _ _ _ _ _ _ PARTITION 3, FEATURE AND REPORTING SELECTION Segment #1 Quick Arm...
  • Page 58 DESCRIPTION DEFAULT DATA PARTITION 4, ENTRY/EXIT TIMERS Segment #1 (Entry Time #1) Segment #2 (Exit Time #1) Segment #3 (Entry Time #2) Segment #4 (Exit Time #2) Segment #5 & #6 RESERVED PARTITION 5, ACCOUNT CODE 10-10-10-10-10-10 _ _ _ _ _ _ PARTITION 5, FEATURE AND REPORTING SELECTION Segment #1 Quick Arm...
  • Page 59 DESCRIPTION DEFAULT DATA PARTITION 6, ENTRY/EXIT TIMERS Segment #1 (Entry Time #1) Segment #2 (Exit Time #1) Segment #3 (Entry Time #2) Segment #4 (Exit Time #2) Segment #5 & #6 RESERVED PARTITION 7, ACCOUNT CODE 10-10-10-10-10-10 _ _ _ _ _ _ PARTITION 7, FEATURE AND REPORTING SELECTION Segment #1 Quick Arm...
  • Page 60 DESCRIPTION DEFAULT DATA PARTITION 8, ENTRY/EXIT TIMERS Segment #1 (Entry Time #1) Segment #2 (Exit Time #1) Segment #3 (Entry Time #2) Segment #4 (Exit Time #2) Segment #5 & #6 RESERVED ZONE TYPE 1 ALARM EVENT CODE ZONE TYPE 1 CHARACTERISTIC SELECT Segment #1 (Circle numbers to program) Fire (enable for fire zone).
  • Page 61 DESCRIPTION DEFAULT DATA ZONE TYPE 11 ALARM EVENT CODE ZONE TYPE 11 CHARACTERISTIC SELECT 3-0-0-0-0 __ __ __ __ __ ZONE TYPE 12 ALARM EVENT CODE ZONE TYPE 12 CHARACTERISTIC SELECT 457-125-45678-0-0 __ __ __ __ __ ZONE TYPE 13 ALARM EVENT CODE ZONE TYPE 13 CHARACTERISTIC SELECT 0-12458-5678-0-0 __ __ __ __ __...
  • Page 62 DESCRIPTION DEFAULT DATA 37 ZONES 57-64, ZONE TYPES 6-6-6-6-6-6-6-6 _ _ _ _ _ _ _ _ ZONES 57-64, PARTITION SELECTION (Segment 1=Zone 57 thru Segment 8=Zone 64) Segments Partition #1 Partition #2 Partition #3 Partition #4 Partition #5 Partition #6 Partition #7 Partition #8 38 ZONES 65-72, ZONE TYPES...
  • Page 63 DESCRIPTION DEFAULT DATA 38 ZONES 89-96, ZONE TYPES 6-6-6-6-6-6-6-6 _ _ _ _ _ _ _ _ ZONES 89-96, PARTITION SELECTION (Segment 1=Zone 89 thru Segment 8=Zone 96) Segments Partition #1 Partition #2 Partition #3 Partition #4 Partition #5 Partition #6 Partition #7 Partition #8 39 ZONES 97-104, ZONE TYPES...
  • Page 64 DESCRIPTION DEFAULT DATA 39 ZONES 121-128, ZONE TYPES 6-6-6-6-6-6-6-6 _ _ _ _ _ _ _ _ ZONES 121-128, PARTITION SELECTION (Segment 1=Zone 121 thru Segment 8=Zone 128) Segments Partition #1 Partition #2 Partition #3 Partition #4 Partition #5 Partition #6 Partition #7 Partition #8 40 ZONES 129-136, ZONE TYPES...
  • Page 65 DESCRIPTION DEFAULT DATA 40 ZONES 153-160, ZONE TYPES 6-6-6-6-6-6-6-6 _ _ _ _ _ _ _ _ ZONES 153-160, PARTITION SELECTION (Segment 1=Zone 153 thru Segment 8=Zone 160) Segments Partition #1 Partition #2 Partition #3 Partition #4 Partition #5 Partition #6 Partition #7 Partition #8 41 ZONES 161-168, ZONE TYPES...
  • Page 66 DESCRIPTION DEFAULT DATA 41 ZONES 185-192, ZONE TYPES 6-6-6-6-6-6-6-6 _ _ _ _ _ _ _ _ ZONES 185-192, PARTITION SELECTION (Segment 1=Zone 185 thru Segment 8=Zone 192) Segments Partition #1 Partition #2 Partition #3 Partition #4 Partition #5 Partition #6 Partition #7 Partition #8 DAYS OF THE WEEK "AUTO DISARMING"...
  • Page 67 NX-584 COMMAND/REQUEST ENABLE Segment #1 Segment #2 1 = Reserved 1 = System Status Request 2 = Interface Configuration Request 2 = Send X-10 Message 3 = Reserved 3 = Log Event Request 4 = Zone Name Request 4 = Send Keypad Text Message 5 = Zone Status Request 5 = Keypad Terminal Mode Request 6 = Zones Snapshot Request...

  • Page 68: Nx-8E Wiring Diagram

    XIII. NX-8E WIRING DIAGRAM NX-8E CONTROL...

  • Page 69: Terminal Descriptions

    XIV. TERMINAL DESCRIPTIONS TERMINAL DESCRIPTION House Telephone Ring (Grey). Telephone Ring (Red). Telephone Tip (Green). House Telephone Tip (Brown). EARTH Earth Ground. Connect to a cold water pipe or a 6 to 10 foot driven rod. AC input. Connect to a 16.5V, 40VA or 50 VA Class ll U.L. approved transformer. If used as a siren output (default), the speaker rating should be 15 watt at 8 or 16 ohm, or 30/40 watt at 4, 8, or 16 ohms.
  • Page 70 ZONE WORKSHEET NX-8E CONTROL...
  • Page 71 APPENDIX 1 REPORTING FIXED CODES IN CONTACT ID AND SIA The table lists the event codes sent for the following reports (if enabled) when using CONTACT ID or SIA formats. REPORT CONTACT ID MANUAL TEST AUTOTEST OPEN (user number) CLOSE (user number) CANCEL (user number) DOWNLOAD COMPLETE START PROGRAM...
  • Page 72 XVI. APPENDIX 2 REPORTING ZONE CODES IN SIA OR CONTACT ID The NX-8E has the ability to report SIA level 1 transmissions to either or both phone numbers. Each report in SIA consists of an Event Code and a Zone or User ID. The Zone ID will be the zone number that is in alarm. The event code will come from the chart below and be programmed in the zone type event code.
  • Page 73 XVII. APPENDIX 3 EXPANDER NUMBERS FOR REPORTING EXPANDER TROUBLE The tables below list the device numbers that will be reported for trouble conditions. Device Device # reported NX-8E Control Panel See page 69 for possible report codes. NX-534E Two Way Listen-In NX-540E “Operator”...
  • Page 74 XVIII. APPENDIX 4 USER ID OR ZONE ID HEX DIGIT FOR 4+2 FORMATS The following appendix applies only to slow formats (locations 56- 83 lower digit). The digit programmed in the locations will be sent as the upper HEX digit in place of the alarm event code. The zone ID or user ID will always be reported as the lower HEX digit (1-F) as shown in the chart below.

  • Page 75: Telephone Company Interface Information

    XIX. TELEPHONE COMPANY INTERFACE INFORMATION TELEPHONE CONNECTION REQUIREMENTS Except for telephone company provided ringers, all connections to the telephone network shall be made through standard plugs and standard telephone company provided jacks or equivalent in such a manner as to allow for immediate disconnection of the terminal equipment.

  • Page 76: Notices

    NOTICES Network Compatibility Declaration (Applies to products which have the CE mark We declare under our sole responsibility that this product attached) is designed to work with the networks in the countries marked with a check ( ) and may have interworking problems with the countries that are not checked.

  • Page 77: Underwriters Laboratories Information

    XXI. UNDERWRITERS LABORATORIES INFORMATION The NetworX NX-8E holds the following listings from Underwriters Laboratories (US and Canadian): UL609 Local Grade A Mercantile, Police Station Connect with Basic Line Security CAN/ULC-S303-M91 * requires #NX-003-C enclosure UL985 Household Fire CAN/ULC-S545-M89 UL1023 Household Burglary ORD-C1023-1974 UL1610 Grade B &...
  • Page 78 • If the Late to Close/Early to Open feature is enabled, the Opening and Closing reports shall be enabled (Loc. 23, Seg. 4, Option 1 and Loc. 23, Seg. 3, Option 1). • For Canadian installations, the class II transformer secure tab shall not be employed. MINIMUM SYSTEM CONFIGURATIONS FOR UL INSTALLATIONS (Residential Fire, Residential Burglary, Commercial Burglary) •...

  • Page 79: Board Installation

    XXII. BOARD INSTALLATION Inside the can, several 2-holed insertion points have been constructed. This allows for either vertical or horizontal placement of the modules. Notice that each insertion point has two sizes of holes -a larger hole and a smaller hole. Diagram 1: The black plastic PCB guides are grooved on one edge where the PC board will be seated.

  • Page 80: Specifications

    Dimensions 6.4" Wide 5.3" High 1.0" Deep METAL ENCLOSURE DIMENSION 11.25" Wide 11.25" High 3.50" Deep SHIPPING WEIGHT 9 lbs. GE INTERLOGIX 1420 NORTH MAIN STREET GLADEWATER, TEXAS 75647 www.caddx.com Main 800-727-2339 Technical Support 800-727-2339 Outside the US 903-845-6941 Tech Support Fax...
