To get started

If you are just starting out, follow the items in this checklist to
prepare, install, wire, and program your fire alarm control panel.
1. Prepare the site. Make sure the installation location is free from
construction dust and debris and extreme temperature ranges
and humidity.
2. Unpack the equipment.
3. Install the cabinet box. See "Cabinet box installation" for cabinet
dimensions.
4. Install the panel electronics in the cabinet box. See "Panel
electronics installation" for more information.
5. Remove the clear protective plastic from the front panel display.
6. Install the optional panel accessories. See each component's
installation sheet instructions for more information.
7. Review the wire routing. See "Cabinet wire routing."
8. Connect the field wiring. See the appropriate wiring topics in the
installation and wiring section. Meter for opens, grounds, and
shorts before connecting.
9. Connect AC power and ground wiring. See "AC power wiring."
The panel cannot be started on batteries only.
10. Connect panel low voltage wiring. See "Panel low voltage
wiring."
11. Turn on AC power.
12. Connect the batteries. See "Battery wiring."
13. Program the panel. Refer to "Getting started" in the
programming section. If you are using the configuration utility,
refer to its Help.
14. Test the system for proper operation.
viii
WARNING: Make sure that the
AC power circuit breaker is off
before connecting wires to the
terminal block.
