Unconfigured alarm programming

The unconfigured alarm event can be assigned to a correlation
group and turn on an output device. When the unconfigured alarm
is assigned to a correlation group every output device in the
correlation group turns on. Event notification can also be
programmed for the unconfigured alarm.
To program the unconfigured alarm:
1. Press the Menu button.
2. Choose Program.
3. Choose Advanced Program.
4. Enter the level two password.
5. Choose Advanced Program.
6. Choose Unconfigured Alarms.
7. Choose Loop 1 Unconf Alarm or Loop 2 Unconf Alarm (displayed
if you have more than one loop).
8. Choose Correlation Groups.
9. Choose a correlation group (1 to 32).
10. Select Yes to add the unconfigured alarm to the correlation
group or No to not add the unconfigured alarm to the
correlation group.
11. Repeat steps 8 and 9 until the unconfigured alarm is added or
removed from each correlation group needed.
12. Choose Save.
13. Choose Event Notification.
14. Choose Active.
15. Set active event notification.
Printer: Yes or No - Specifies if event information is printed
Coder: 4-digit coded output, which is played in response to
alarm conditions (00-00-00-00 to 99-99-99-99)
Dialer:
Acct 1 & 2: Event information is sent to both dialer accounts
Acct 1: Event information is sent to dialer account one
Acct 2: Event information is sent to dialer account two
154
Reports
