Appendix B: Worksheets
Worksheet B: Auxiliary/smoke power current load
Devices Qty
RPM
SIGA-UM or -MAB [1]
RLCD(F)
RLCD-C(F)
RLED-C(F)
LED24
Totals (mA)
(transfer totals to Battery Calculation Worksheet)
Note
[1] Enter 1 regardless of how many are installed. Only the first SIGA-UM or SIGA-MAB in the alarm state draws
current. The other ones do not because the system load sheds additional modules in alarm.
208
Standby Alarm
current (mA) current (mA)
20 270
2 17
98 113
99 115
28 62
6 34
Qty x Standby
current (mA)
