Chapter 3: Programming

Loop class programming

The loop must be programmed based on how the devices are wired
on the loop (Class A or Class B).
Default: Class B
To program loop class:
1. Access the loop configuration options menu. See "Loop
configuration options."
2. Choose Loop Class.
3. Select the loop. If you only have one loop, the loop is
automatically selected.
4. Select either Class A or Class B.
5. Choose Save.
6. Continue programming your system or press Menu to exit menu
mode.
124
Loop Configuration
