Altronix Maximal Rack Mount Series units distribute and switch power to access control systems and accessories.
They convert a 115VAC, 50/60Hz input into eight (8) or sixteen (16) independently controlled 12VDC and/or
24VDC fuse protected outputs. Outputs are activated by a normally open (NO) or normally closed (NC) dry trigger
input from an Access Control System, Card Reader, Keypad, Push Button, PIR, etc. Units will route power to a
variety of access control hardware devices including: Mag Locks, Electric Strikes, Magnetic Door Holders, etc.
Outputs will operate in both Fail-Safe and/or Fail-Secure modes. The FACP Interface enables Emergency Egress,
Alarm Monitoring, or may be used to trigger other auxiliary devices. The fire alarm disconnect feature is individually
selectable for any or all of the outputs (see chart below).

Maximal Rack Mount Series Configuration Chart:

Altronix Supply 1
Model Number (8 outputs)
12VDC @ 4A
Maximal1RH
24VDC @ 3A
12VDC @ 4A
Maximal1R
24VDC @ 3A
12VDC @ 6A
Maximal3RH
24VDC @ 6A
12VDC @ 6A
Maximal3R
24VDC @ 6A
12VDC @ 6A
Maximal33R
24VDC @ 6A
12VDC @ 6A
Inputs:
• Normally closed [NC] or normally open [NO]
dry contact inputs (switch selectable).
Outputs:
• Individually selectable Mag Lock/Strike (Fail-Safe,
Fail-Secure) solid state fuse protected power outputs.
• Thermal and short circuit protection with auto reset.
Fire Alarm Interface:
• Fire Alarm disconnect (latching with reset or
non-latching) is individually selectable for any or
all of the outputs.
• Remote reset capability for latching Fire Alarm
Interface mode.
• Fire Alarm disconnect input options:
a) Normally open [NO] or normally closed [NC]
dry contact input.
b) Polarity reversal input from
FACP signaling circuit.
Visual Indicators:
• Individual output status LEDs located on the
front panel.
Maximal Rack Access Power Controllers (Fused) Installation Guide
Power Power
Supply 2
(8 outputs)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
12VDC @ 6A
24VDC @ 6A
24VDC @ 6A

Specifications:

Overview:

Total Fuse
Output Protected
Current Outputs
4A
8
3A
4A
16
3A
6A 8
6A 16
12A 16
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries
(A separate enclosure is required for batteries).
• Maximum charge current 0.7A.
• Automatic switch over to stand-by battery
when AC fails.
• Zero voltage drop when unit switches over to
battery backup (AC failure condition).
Supervision:
• AC fail supervision (form "C" contact).
• Low battery supervision (form "C" contact).
Additional Features:
• Removable terminal blocks with locking
screw flange.
• 3-wire line cord.
• Illuminated master power disconnect circuit breaker
with manual reset.
Rack Dimensions (H x W x D):
3.25" x 19.125" x 8.5"
(82.6mm x 485.8mm x 215.9mm).
Maximum 115VAC
Current 50/60Hz
Per Input
ACM8R-M (current
Output draw)
2.5A 1.9A
2.5A 1.9A
2.5A 1.9A
2.5A 1.9A
2.5A 3.8A
Power
Supply
Board
Input Fuse
Rating
5A/250V
5A/250V
3.5A/250V
3.5A/250V
3.5A/250V
