Access Power Controllers
Installation Guide
Models Include:
Maximal11D
- Power Supply 1:
12VDC @ 3.5A or 24VDC @ 2.7A.
- Power Supply 2:
12VDC @ 3.5A or 24VDC @ 2.7A.
- Sixteen (16) PTC protected
Class 2 Rated power-limited outputs.
Maximal33D
- Power Supply 1:
12VDC @ 5.5A or 24VDC @ 5.7A.
- Power Supply 2:
12VDC @ 5.5A or 24VDC @ 5.7A.
- Sixteen (16) PTC protected
Class 2 Rated power-limited outputs.
Maximal55D
- Power Supply 1: 12VDC @ 9.5A.
- Power Supply 2: 12VDC @ 9.5A.
- Sixteen (16) PTC protected
Class 2 Rated power-limited outputs.
Rev. MDCB052219
Altronix Corp.
140 58th St. Brooklyn, NY
Maximal77D
- Power Supply 1:
24VDC @ 9.7A.
- Power Supply 2:
24VDC @ 9.7A.
- Sixteen (16) PTC protected
Class 2 Rated power-limited outputs.
Maximal75D
- Power Supply 1:
12VDC @ 9.5A.
- Power Supply 2:
24VDC @ 9.7A.
- Sixteen (16) PTC protected
Class 2 Rated power-limited outputs.
More than just power.
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAXIMAL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Altronix MAXIMAL Series

Summary of Contents for Altronix MAXIMAL Series

  • Page 1 Class 2 Rated power-limited outputs. Maximal55D - Power Supply 1: 12VDC @ 9.5A. - Power Supply 2: 12VDC @ 9.5A. - Sixteen (16) PTC protected Class 2 Rated power-limited outputs. Altronix Corp. 140 58th St. Brooklyn, NY More than just power. Rev. MDCB052219...

  • Page 2: Table Of Contents

    Table of Contents: MaximalD Series Overview pg. 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . MaximalD Series Configuration Chart .

  • Page 3: Maximald Series Overview

    5 .2A C22.2 250V No.205-M1983 12VDC @ 9 .5A 12VDC @ 9 .5A AL1012ULXB AL1024ULXB2 15A/ Altronix Corp. 140 58th St. Brooklyn, NY Maximal75D 2 .5A 250V 12VDC @ 9 .5A 24VDC @ 9 .5A California AL1024ULXB2 AL1024ULXB2 State Fire...

  • Page 4: Maximald Installation Instructions

    • Sixteen (16) unswitched filtered and electronically regulated aux . power outputs (outputs are rated @ 2 .5A) . • ACM8CB maximum current is 2 .5A per output . • Red LEDs on ACM8CB board indicate individual outputs are triggered (relays energized) . •...
  • Page 5 12 . Installation of tamper switch (Not Included) (Figs. 3a, 4a, 5a, pgs. 10-12): Mount UL Listed tamper switch (Altronix Model TS112 or equivalent) at the top of the enclosure . Slide the tamper switch bracket onto the edge of the enclosure approximately 2” from the right side . Connect tamper switch wiring to the Access Control Panel input or the appropriate UL Listed reporting device .

  • Page 6: Maintenance

    Maintenance: Unit should be tested at least once a year for the proper operation as follows: FACP Supervision: To ensure proper connection and operation of the Fire Alarm disconnect hookup . Please follow the appropriate procedure below: Normally Open Input: Placing a short between terminals marked [T] and [+ INP] will trigger the Fire Alarm Disconnect .

  • Page 7: Power Supply Board Terminal Identification

    Power Supply Board Terminal Identification: Terminal Legend Function/Description L, G, N Connect 115VAC 60Hz to these terminals: L to hot, N to neutral . Maximal11D - 12VDC @ 3 .5A or 24VDC @ 2 .7A to ACM8CB boards (power-limited) . Maximal33D - 12VDC @ 5 .5A or 24VDC @ 5 .7A to ACM8CB boards (power-limited) .

  • Page 8: Power Supply Board Stand-By Battery Specifications

    Power Supply Board Stand-by Battery Specifications: Altronix 20 Min. of 24 Hr. of Power Supply Board Battery 4 Hr. of Backup Model Backup Backup 12VDC/ AL400ULXB2 3 .5A 0 .5A 40AH* (Refer to Fig. 1a, pg. 9 Maximal11D for Switch [SW1] 24VDC/ 2 .7A...

  • Page 9: Power Supply Board Output Voltage Settings

    Power Supply Board Output Voltage Settings: Fig. 1a - Maximal11D and Maximal33D Power Supply Board OFF - 24V Fig. 1b ON - 12V OFF - 24V ON - 12V Access Power Controller Typical Application Diagram (for each ACM8CB): Fig. 2 Fig.

  • Page 10: Maximal11D, Maximal33D, Maximal55D Battery Hookup And Tamper Switch Installation

    Fig. 3 - Maximal11D, Maximal33D, Maximal55D Tamper Switch Power Supply Board BAT FAIL AC FAIL NC C NO NC C NO Line Neutral Wire Strap (from Power Supply Board Enclosure to Door) BAT FAIL Input AC FAIL NC C NO NC C NO 115VAC, Line...

  • Page 11: Maximal77D Battery Hookup And Tamper Switch Installation

    Fig. 4 - Maximal77D Tamper Switch Power Supply Board BAT FAIL AC FAIL NC C NO NC C NO Line Neutral Wire Strap (from Power Supply Board Enclosure to Door) BAT FAIL AC FAIL Input NC C NO NC C NO Line Neutral 115VAC,...

  • Page 12: Maximal75D Battery Hookup And Tamper Switch Installation

    Fig. 5 - Maximal75D Tamper Switch Power Supply Board BAT FAIL AC FAIL NC C NO NC C NO Line Neutral Wire Strap (from Enclosure Power Supply Board to Door) Input BAT FAIL AC FAIL NC C NO NC C NO 115VAC, Line Neutral...

  • Page 13: Nec Power-Limited Wiring Requirements For Maximal11D

    NEC Power-Limited Wiring Requirements for Maximal11D: Power-limited and non power-limited circuit wiring must remain separated in the cabinet . All power-limited circuit wiring must remain at least 0 .25” away from any non power-limited circuit wiring . Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through differ- ent conduits .

  • Page 14: Nec Power-Limited Wiring Requirements For Maximal33D And Maximal55D

    NEC Power-Limited Wiring Requirements for Maximal33D and Maximal55D: Power-limited and non power-limited circuit wiring must remain separated in the cabinet . All power-limited circuit wiring must remain at least 0 .25” away from any non power-limited circuit wiring . Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through differ- ent conduits .

  • Page 15: Nec Power-Limited Wiring Requirements For Maximal77D

    NEC Power-Limited Wiring Requirements for Maximal77D: Power-limited and non power-limited circuit wiring must remain separated in the cabinet . All power-limited circuit wiring must remain at least 0 .25” away from any non power-limited circuit wiring . Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through differ- ent conduits .

  • Page 16: Nec Power-Limited Wiring Requirements For Maximal75D

    NEC Power-Limited Wiring Requirements for Maximal75D: Power-limited and non power-limited circuit wiring must remain separated in the cabinet . All power-limited circuit wiring must remain at least 0 .25” away from any non power-limited circuit wiring . Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through differ- ent conduits .

  • Page 17: Facp/Optional Power Supply Hook-Up Diagrams

    FACP/Optional Power Supply Hook-up Diagrams: Fig. 10 Optional hook-up using two (2) isolated power supply inputs (Only applicable on Maximal11): CUT JUMPERS J1 AND J2 ISOLATED POWER INPUT 12 OR 24 VAC OR VDC (ACM8 POWER) ISOLATED POWER INPUT 12 OR 24 VAC OR VDC (LOCK POWER) Fig.

  • Page 18: Facp/Optional Power Supply Hook-Up Diagrams

    FACP/Optional Power Supply Hook-up Diagrams (cont’d): Fig. 13 Normally Open FACP Latching trigger input with reset: (This output has not been evaluated by UL) N.O. TRIGGER INPUT N.C. RESET SWITCH JUMPER Fig. 14 Normally Closed - Non-Latching FACP trigger input: N.C.
  • Page 19 Notes: Maximal11D/Maximal33D/Maximal55D/Maximal77D/Maximal75D Access Power Controllers (PTC) - 19 -...

  • Page 20: Enclosure Dimensions

    Altronix is not responsible for any typographical errors . 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www .altronix .com | e-mail: info@altronix .com | Lifetime Warranty | Made in U .S .A . MEMBER...
