Maximal Access Power/Controllers distribute and switch power to access control systems and accessories . They

convert a 115VAC 60Hz input into sixteen (16) independently controlled 12VDC or 24VDC Class 2 Rated PTC

protected power-limited outputs . The outputs are activated by an open collector sink or normally open (NO) dry

trigger input from an Access Control System, Keypad, Push Button, REX PIR, etc . Units will route power to a

variety of access control hardware devices including: Mag Locks, Electric Strikes, Magnetic Door Holders, etc .

The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary

devices . The fire alarm disconnect feature is individually selectable for any or all of the sixteen (16) outputs . All

interconnecting equipment must be UL Listed .

Output Voltage Options

Altronix

Model

Power Supply 1 Power Supply 2

Number

AL400ULXB2

12VDC @ 3 .5A

Maximal11D

12VDC @ 2 .7A

24VDC @ 3 .5A

AL600ULXB

12VDC @ 5 .5A

Maximal33D

12VDC @ 5 .7A

24VDC @ 5 .5A

AL1012ULXB

Maximal55D

12VDC @ 9 .5A

AL1012ULXB

Maximal75D

12VDC @ 9 .5A

AL1024ULXB2 AL1024ULXB2

Maximal77D

24VDC @ 9 .7A

**ANSI/UL 294 7th Ed. Access Control Performance Levels:

Destructive Attack - I; Endurance - I; Line Security - I; Stand-by Power - I, IV .

• Sixteen (16) independently trigger controlled outputs .

Output options:

a) Sixteen (16) Fail-Safe filtered and electronically regulated power outputs .

b) Sixteen (16) Fail-Secure filtered and electronically regulated power outputs .

c) Sixteen (16) form "C" relay outputs (rated @ 5A/28VDC or VAC) .

d) Any combination of the above .

• Sixteen (16) Access Control System trigger inputs .

Input trigger options:

a) Sixteen (16) normally open (NO) dry trigger inputs .

b) Sixteen (16) open collector inputs .

c) Any combination of the above .

Maximal11D/Maximal33D/Maximal55D/Maximal77D/Maximal75D Access Power Controllers (PTC)
