Altronix MaximalV Access Power/Controllers distribute and switch power to access control systems and acces-

sories . They convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into sixteen (16) indepen-

dently controlled 12VDC or 24VDC fuse protected outputs . These Fail-Safe/Fail-Secure power outputs may be

converted to dry form "C" contacts . The outputs are activated by an open collector sink or normally open (NO)

dry trigger input from an Access Control System, Keypad, Push Button, REX PIR, etc . Units will route power

to a variety of access control hardware devices including Mag Locks, Electric Strikes, Magnetic Door Holders,

etc . The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary

devices . The fire alarm disconnect feature is individually selectable for any or all of the sixteen (16) outputs .

Altronix

Output Voltage Options

Model

Power Supply 1 Power Supply 2

Number

AL400XB2V

12VDC @ 3 .5A

Maximal11V

12VDC @ 2 .7A

24VDC @ 3 .5A

AL600XB220

12VDC @ 5 .5A

Maximal33V

12VDC @ 5 .7A

24VDC @ 5 .5A

AL1012XB220

Maximal55V

12VDC @ 9 .5A

AL1012XB220

Maximal75V

12VDC @ 9 .5A

AL1024XB2V

Maximal77V

24VDC @ 9 .7A

• Sixteen (16) independently trigger controlled outputs .

Output options:

a) Sixteen (16) Fail-Safe filtered and electronically regulated power outputs .

b) Sixteen (16) Fail-Secure filtered and electronically regulated power outputs .

c) Sixteen (16) form "C" relay outputs (rated @ 5A/28VDC or VAC) .

d) Any combination of the above .

• Sixteen (16) Access Control System trigger inputs .

Input trigger options:

a) Sixteen (16) normally open (NO) dry trigger inputs .

b) Sixteen (16) open collector inputs .

c) Any combination of the above .

• Sixteen (16) unswitched filtered and electronically regulated aux . power outputs (outputs are rated @ 2 .5A) .

• ACM8 maximum current is 2 .5A per output .

• Red LEDs on ACM8 board indicate individual outputs are triggered (relays energized) .

• Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the

sixteen (16) outputs . Fire Alarm disconnect input trigger options:

a) Normally open (NO) or normally closed (NC) dry trigger input .

b) Polarity reversal input from FACP signaling circuit .

• Green LED on ACM8 board indicates FACP disconnect is triggered .

• FACP output relay indicates that FACP input is triggered (form "C" contact rated @ 1A/28VDC) .

• Power supply input options:

a) Factory installed power supplies provide common power for both ACM8 boards and all connected

access control devices .

b) An optional external access control power supply may be connected to isolate the ACM8 boards from

the access control devices (only applicable on Maximal11V).

Maximal11V / Maximal33V / Maximal55V / Maximal77V / Maximal75V Access Power Controllers (Fused)
