MaximalF Access Power Controllers distribute and switch power to access control systems and accessories. They

convert a 120VAC 60Hz input into sixteen (16) independently controlled 12VDC or 24VDC fuse protected outputs.

These Fail-Safe/Fail-Secure power outputs may be converted to dry form "C" contacts. The outputs are activated

by an open collector sink or normally open (NO) dry trigger input from an Access Control System, Keypad, Push

Button, REX PIR, etc. Units will route power to a variety of access control hardware devices including: Mag Locks,

Electric Strikes, Magnetic Door Holders, etc. The FACP Interface enables Emergency Egress, Alarm Monitoring, or

may be used to trigger other auxiliary devices. The fire alarm disconnect feature is individually selectable for any

or all of the sixteen (16) outputs. All interconnecting equipment must be UL Listed.

Altronix

Model

Number

Maximal3F

3.5A

Maximal5F

3.5A

Maximal7F

4.5A

The DC output for these power supplies are not power-limited. If a power-limited output is required in the end-

product application, the DC output from the power supply must be connected to a separately Listed control unit

or accessory board that provides power-limited outputs. The product(s) providing the power-limited output(s)

must be listed as appropriate for the particular end-product application (access control), and wired in accordance

with the products installation instructions. Class 1 wiring methods, separation of circuits, and proper fire-rated

enclosures all must be considered when connecting the DC output of the power supply to the end-product devices.

The auxiliary outputs of these units are power-limited.

UL Listings for

US Installations:

*ANSI/UL 294 7th Ed. Access Control Performance Levels:

Destructive Attack - I; Endurance - I; Line Security - I; Stand-by Power - II, III, IV.

UL Listings for

Canadian Installations:

ULC-S319-05 Electronic Access Control Systems will be invalidated through the use of any add-on, expansion,

memory or other module manufactured by the manufacturer or other manufacturers.

Maximal3F/Maximal5F/Maximal7F Access Power Controllers (Fused)
