Rack Mechanical Drawing and Dimensions
Fig. 15
Fig. 15a
(ON)
Terminal Legend
0.75" (19.1mm)
Altronix is not responsible for any typographical errors.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty
IIMaximal Rack Mount Series
- 12 -
3.25" x 19.125" x 8.5" (82.6mm x 485.8mm x 215.9mm)
Top and Bottom
Fig. 15b
3-Wire
Line Cord
Rear
17.625" (447.7mm)
Front
19.125" (485.8mm)
K05U
Maximal Rack Access Power Controllers (Fused) Installation Guide
Fig. 15c
Removable Terminal
Block
MEMBER
