Maximalfd Series Overview; Maximalfd Series Configuration Chart; Agency Listings - Altronix Maximal3FD Installation Manual

Altronix MaximalFD Access Power/Controllers distribute and switch power to access control systems and
accessories. They convert a 120VAC 60Hz input into sixteen (16) independently controlled 12VDC or 24VDC
PTC protected protected outputs. The outputs are activated by an open collector sink or normally open (NO) dry
trigger input from an Access Control System, Keypad, Push Button, REX PIR, etc. Units will route power to a
variety of access control hardware devices including: Mag Locks, Electric Strikes, Magnetic Door Holders, etc.
The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary
devices. The fire alarm disconnect feature is individually selectable for any or all of the sixteen (16) outputs. All
interconnecting equipment must be UL Listed.
Altronix
Model
Number
Maximal3FD 3.5A
Maximal5FD 3.5A
Maximal7FD 4.5A
These units are classified as Class 2 Power-Limited stand alone power supplies with stand-by battery and they are
suitable to power: sensors, electro-mechanical devices (e.g. electric door strikes).
UL Listings for
US Installations:
*ANSI/UL 294 7th Ed. Access Control Performance Levels:
Destructive Attack - I; Endurance - I; Line Security - I; Stand-by Power - II, III, IV.
UL Listings for
Canadian Installations:
ULC-S319-05 Electronic Access Control Systems will be invalidated through the use of any add-on, expansion,
memory or other module manufactured by the manufacturer or other manufacturers.
Maximal3FD/Maximal5FD/Maximal7FD Access Power Controllers (PTC)

MaximalFD Series Overview:

MaximalFD Series Configuration Chart:

Output Voltage
[DC]
5A/ 10A/ 9.7-
250V 32V 13.2
5A/ 15A/ 9.7-
250V 32V 13.2
6.3A/ 15A/
–
250V 32V

Agency Listings:

UL 294* - UL Listed for Access Control System Units.
ULC-S319-05 - Electronic Access Control Systems Class I equipment.
CSA C22.2 No.205 - Signal Equipment.
Nominal DC
[Aux]
Maximum Supply
Outputs on Power
Supply board and
ACM8CB Access
Power Controller's
19.8- 10.03- 20.19- 12VDC @ 4.6A or
26.4 13.2 26.4
10.03-
– –
13.2
19.8- 20.28-
–
26.4 26.4
Current for
Main and Aux.
outputs (A)
16
24VDC @ 5.2A
8.6A 16
9.2A 16
10A/ 2.5A/
2.5
250V 250V
10A/ 2.5A/
2.5
250V 250V
10A/ 2.5A/
2.5
250V 250V
