Specifications
Table A-6
Management Protocol
SNMPv2c
Table A-7
RJ-45 Pin
1
4
5
Management Standards and Specifications
Supported MIBs
MIB II (RFC 1213)
Interface Table MIB (RFC 1573)
AToM MIB (RFC 1695)
AToM2 MIB (pre-standard)
LANE MIB (ATM Forum)
ILMI 4.0 MIB (ATM Forum)
IP over ATM MIB (pre-standard)
PNNI MIB
Switch hardware MIB
RJ-45 to DB-9 Adapter (PC Serial Port Adapter)
RJ-45 Color
Blue
Red
Green
DB-9 Pin
2
3
5
Technical Specifications
DB-9 Description
Receive
Transmit
Ground
SmartCell 6A000 User Guide A-5
