PVC Connections
Use the
3.
set portconfig
example, to set up a PVC on port A1 using the new VPI/VCI bit ranges (3/9), enter
SmartCell ZX # set portconfig a1
PortAdminStatus(up)
IlmiAdminStatus(enable)
IlmiAddressRegistration(enable)
IlmiConnectivity(enable)
SigType(autoConfig)
SigRole(other)
InterfaceType(private)
MaxVpiBits(0)
MaxVciBits(12)
MaxSvcVpi(7)
MinSvcVci(32)
MaxVccs(4096)
SmartCell ZX #
4. Use
show portconfig
SmartCell ZX # show portconfig a1
==================================================
Port: A1
--------------------------------------------------
Parameter
--------------------------------------------------
Sig Type
Sig Role
Interface Type
Max vpi bits
Max vci bits
Max SVC vpci
Min SVC vci
Max Vccs
--------------------------------------------------
Other parameters
--------------------------------------------------
Port Admin Status
Ilmi Admin Status
Oper State
Trans Type
Media Type
Bandwidth
SmartCell ZX #
PVCs can be configured for port A1 using VPI values from 0 to 7 and VCI values from 0 to 511.
Do not set the VCI part of the VCCMask to fewer than 5 bits.
Note
Note Do not change the VCCMask for the CPU port (B4).
4-16 SmartCell 6A000 User Guide
command to reconfigure a port to use the new values for VPI and VCI. For
:
:
:
:
:
:
:
: 3
: 9
:
:
:
to see the change to port A1.
Configured Current
autoConfig pnni10
other symmetric
private private
3 0
9 9
7 0
32 32
4096 4096
UP
Enabled AddressRegistration Connectivity
UP
STS-3c
MMF (S)
155 MB
<VPI on port A1 can now be any 3-bit number
<VCI on port A1 can now be any 9-bit number
