Switch Installation and Setup
Table 2-1
Face Plate Number
6A-IOM-29-4-LR
6A-IOM-31-1
6A-IOM-39-1
6A-IOM-39-1-LR
6A-IOM-67-4
6A-IOM-77-4
If the hardware configuration is incorrect, contact Cabletron customer support immediately.
2.2.1

DS3 and E3 I/O Module Configuration

Table 2-2 shows the pre-configured values for both the DS3 (6A-IOM-67-4) and E3 (6A-IOM-77-4) I/O modules.
These values cannot be changed. Accordingly, configure the connecting device's interface to use these values.
Table 2-2
Protocol Mode
plcp
DS3
plcp
E3
2.3

INSTALLING THE SWITCH

The SmartCell 6A000 is hot swappable, meaning that you can install and remove it without turning off or unplugging
the SmartSwitch 6000 chassis. You can install as many as five switch modules in each chassis (using the 6C205-3
power supply). In this configuration, the SmartCell 6A000 modules provide up to 75 user ports. Modules should be
connected with inter-module trunks if traffic must cross between modules. Table 2-3 shows the maximum number of
LAN and ATM switch modules that can be installed in a SmartSwitch 6000 chassis.
Table 2-3
Number of 6Exxx or 6Hxxx modules installed
Number of 6A000 modules that can be added
I/O module ID numbers (Continued)
Physical Specification
155 Mbps OC-3/STS-1, SMF-LR/SC (4 port)
622 Mbps OC-12/STM-4, MMF/SC (1 port)
622 Mbps OC-12/STM-4, SMF-IR/SC (1 port)
622 Mbps OC-12/STM-4, SMF-LR/SC (1 port)
45 Mbps DS-3, Coax/BNC (4 port)
34 Mbps E-3, Coax/BNC (4 port)
DS3 and E3 Module settings
Framing Empty Cell
cbit unassigned
G.751 unassigned
SmartSwitch 6000 contents
0
5
Timing Scrambling
internal off
internal off
1 2 3
4 3 2
Installing the Switch
Length
greater than 225 ft.
N/A
4 5
1 0
SmartCell 6A000 User Guide 2-3
