Switch Administration
4.2.2

UNI Routes

Use the command to create UNI routes. For example, connect an end station adapter (with MAC address
add ATMRoute
00:11:22:33:44:55) to port A2 of the SmartCell 6A000. If the adapter does not support ILMI or its ILMI is
incompatible with the SmartCell 6A000, you must create a static UNI route between the adapter and port A2 of the
SmartCell 6A000.
1. Enter the
show netprefix
SmartCell ZX # show netprefix
PortNumber(ALL)
Port# NetPrefix
============================================================================
A2 39:00:00:00:00:00:00:00:00:00:14:59:00
SmartCell ZX #
Reconfigure the adapter with an ATM address made from the netprefix of port A2 and the adapter's
2.

MAC address: 39:00:00:00:00:00:00:00:00:00:14:59:00:00:11:22:33:44:55:00.

3. Use the
add ATMRoute
new ATM address.
SmartCell ZX # add atmroute
PortNumber(A1)
AtmAddress()
PrefixLength(152)
Index(0)
Type(Internal)
Scope(0)
MetricsTag(0)
SmartCell ZX #
4. Enter the
show ATMRoute
SmartCell ZX # show atmroute
AddressNumber(ALL)
No. Port Route Address
================================================================================
1 B4 39:00:00:00:00:00:00:00:00:00:14:41:80:00:20:d4:14:41:80
2 B4 39:00:00:00:00:00:00:00:00:00:14:41:80:00:20:d4:14:41:81
3 -- 39:00:00:00:00:00:00:00:00:00:14:59:00
4 A2 39:00:00:00:00:00:00:00:00:00:14:59:00:00:11:22:33:44:55
5 -- 39:00:00:00:00:00:00:00:00:00:28:e9:80
6 -- 39:00:00:00:00:00:00:00:00:00:28:f5:00
7 B4 47:00:79:00:00:00:00:00:00:00:00:00:00:00:a0:3e:00:00:01
8 B2 52:00:00:00:00:00:00:00:00:00:14:51:80
SmartCell ZX #SmartCell ZX #
The UNI route appears in the table as route number four (No. 4).
For UNI routes to work with certain devices, ILMI may also need to be disabled
Note
on the SmartCell 6A000. Use the
the SmartCell 6A000 on a per-port basis.
command to obtain the netprefix of port A2
: a2
command to create a static UNI route that specifies port A2 and the adapter's
: a2
: 39:00:00:00:00:00:00:00:00:00:14:59:00:00:11:22:33:44:55:00
:
:
:
:
:
command to check that the UNI route was added.
:
Type Protocol
I
I
I
I
I
I
I
I
command to disable ILMI on
set PortConfig
ATM Routing
MGMT
MGMT
PNNI
MGMT
PNNI
PNNI
MGMT
MGMT
SmartCell 6A000 User Guide 4-5
