Specifications
Table A-2
Specification Value
Max I/O ports 7 for 6A000-02; 15 for 6A000-04
Switch latency 10 microseconds
CPU DRAM memory 32 MB
Buffer memory (cells) 32 K
flash memory 8 MB
Serial port RS-232c compliant; RJ-45 connector
Ethernet port IEEE 802.3 compliant; RJ-45 connector
Table A-3
Specification
Dimensions
Product weight (with max I/O modules)
Power requirements (typical)
Power dissipation (typical)
Operating temperature
Operating humidity
Table A-4
Media Port Speed
SMF-IR 155 Mbps or
622 Mbps
SMF-LR 622 Mbps
MMF 155 Mbps or
622 Mbps
Hardware Specifications (Continued)
Physical Specifications
Value
41.9 cm x 6.1 cm x 28.6 cm
16.5" x 2.4" x 11.25"
3.6 kg
8 lbs
5V, 19 amps at chassis power bus (fully
loaded)
1,008,000 BTU/s (95 watts) (fully loaded)
15 to 40 C (41 to 104 F)
5% to 90% RH, non-condensing
ATM Port Specifications
Framing Connector
STS-3 or STM-1 SC
STS-12 or STM-4
STS-12 or STM-4 SC
STS-3 or STM-1 SC
STS-12 or STM-4
Max. Rx
Max. Tx Min. Tx
power
Power power
-8 dBm -15 dBm -7 dBm
-- -3 dBm -7 dBm
-19 dBm -14 dBm -14 dBm
Technical Specifications
Min. Rx Range
power
-28 dBm 15 Km
-28 dBm 40 Km
-31 dBm 2 Km
